Once in remote mode, the Spectrum Master stops sweeping. A Remote Mode Indicator appears on the LCD.
The Spectrum Master sends its model and software version numbers to the computer. The Spectrum Master is now able to
take multiple control bytes. It waits for the next control byte.
Bytes to Follow: 0 bytes
Spectrum Master Returns: 13 bytes
1-2) Model # (unsigned integer, 16h for Spectrum Master MS2711D)
3-9) Extended Model # (7 bytes in ASCII)
10-13) Software Version (4 bytes in ASCII)
Write Protect Setup – Control Byte #71 (47h)
Description: Makes a saved setup either read-only or write-able.
Setup numbers as follows:
255 = All Setups in the Specified Mode
1 – 10 = Saved setups for Spectrum Analyzer/Transmission Measurement modes
1 – 5 = Saved setups for Power Meter mode (Option 29 only)
Bytes to Follow: 3 bytes
1) Measurement Mode
2) Setup Number
3) Write-Protect Status (00h = Allow Writes (default), 01h = Lock Setup (i.e., "read only"))
Spectrum Master Returns: 1 byte
1) 255 (FFh) Operation Complete Byte
224 (E0h) Parameter Error
238 (EEh) Time Out Error
Clear Setup Memory Location – Control Byte #72 (48h)
Description: Clears a setup memory location such that it appears as <EMPTY> in the Recall Setup list.
Setup numbers as follows:
255 = All Setups in the Specified Mode
1 – 10 = Saved setups for Spectrum Analyzer/Transmission Measurement modes
1 – 5 = Saved setups for Power Meter mode (Option 29 only)
Bytes to Follow: 2 bytes
1) Measurement Mode
2) Setup Number
Spectrum Master Returns: 1 byte
1) 255 (FFh) Operation Complete Byte
224 (E0h) Parameter Error
238 (EEh) Time Out Error
336 Refer to Control Byte #3 "Select Measurement Mode" for valid measurement modes.
337 Refer to Control Byte #3 "Select Measurement Mode" for valid measurement modes.
