80) Ref Level (lowest byte)
3
81) Scale per div (highest byte)
82) Scale per div
83) Scale per div
84) Scale per div (lowest byte)
85) Frequency Marker 1
86) Frequency Marker 1 (lower byte)
87) Frequency Marker 2 (higher byte)
88) Frequency Marker 2 (lower byte)
89) Frequency Marker 3 (higher byte)
90) Frequency Marker 3 (lower byte)
91) Frequency Marker 4 (higher byte)
92) Frequency Marker 4 (lower byte)
93) Frequency Marker 5 (higher byte)
94) Frequency Marker 5 (lower byte)
95) Frequency Marker 6 (higher byte)
96) Frequency Marker 6 (lower byte)
5
97) Single Limit (highest byte)
98) Single Limit
99) Single Limit
100) Single Limit (lowest byte)
101) Multiple Upper Limit 1 Start X (Frequency in Hz) (highest byte)
102) Multiple Upper Limit 1 Start X (Frequency in Hz)
103) Multiple Upper Limit 1 Start X (Frequency in Hz)
104) Multiple Upper Limit 1 Start X (Frequency in Hz) (lowest byte)
105) Multiple Upper Limit 1 Start Y (Power Level
106) Multiple Upper Limit 1 Start Y (Power Level)
107) Multiple Upper Limit 1 Start Y (Power Level)
108) Multiple Upper Limit 1 Start Y (Power Level) (lowest byte)
109) Multiple Upper Limit 1 End X (Frequency in Hz) (highest byte)
110) Multiple Upper Limit 1 End X (Frequency in Hz)
111) Multiple Upper Limit 1 End X (Frequency in Hz)
112) Multiple Upper Limit 1 End X (Frequency in Hz) (lowest byte)
113) Multiple Upper Limit 1 End Y (Power Level
114) Multiple Upper Limit 1 End Y (Power Level)
115) Multiple Upper Limit 1 End Y (Power Level)
116) Multiple Upper Limit 1 End Y (Power Level) (lowest byte)
117-260) Multiple Upper Limits 2-5, Multiple Lower Limits 1-5 (see bytes 101-116 for format)
261) RBW Setting (Frequency in Hz) (highest byte)
262) RBW Setting (Frequency in Hz)
263) RBW Setting (Frequency in Hz)
264) RBW Setting (Frequency in Hz) (lowest byte)
265) VBW Setting (Frequency in Hz) (highest byte)
266) VBW Setting (Frequency in Hz)
3 "value" sent as (value * 1,000)
4 Display/Data Point
To convert from "point" to frequency:
((span / (#data points-1)) * point) + start frequency
where span is stored in bytes 69-72 and #data points is stored in bytes 55-56
5 "value" sent as (value in dBm * 1,000) + 270,000
6 "value" sent as (value in dBm * 1,000) + 270,000
7 "value" sent as (value in dBm * 1,000) + 270,000
