- Page 1 MANUAL SM6-G/-W, SMB6-G/-W SM6V-G/-W, SMB6V-G/-W SM6VP-G/W, SMB6VP-G/-W INFO@APART-AUDIO.COM...
-
Page 2: Safety Precaution
• This apparatus should only be serviced by qualified personnel. If not warranty might be void. • The speaker grill is fixed, removing it will damage the speaker. • Use cable of the right gauge, certainly for long runs. • Use cables with clear color indication and maintain polarity throughout the WWW.APART-AUDIO.COM... -
Page 3: Features And Benefits
• Take notice that this speaker is intended for indoor use only. Do not expose the speaker to rain or moisture. Features and benefits MODEL Colour Mounting Volume 24V priority Back bracket control relay plate SM6-G grey SM6-W white SM6V-G grey SM6V-W white SM6VP-G grey SM6VP-W white SMB6-G... -
Page 4: Connecting The Speakers
1.5W Amplifier power must be equal higher than total power of all speakers Connecting the SM6; SM6V; SMB6; SMB6V Common 100V speaker wire 6W 100V speaker connection 3W 100V speaker connection 1,5W 100V speaker connection WWW.APART-AUDIO.COM... - Page 5 24V - negative wire for the priority relais Optionally you can select the power tapping from the transformer: The factory setting is 6W, but you select any other power tap of 3W, 1.5W and 0.75W INFO@APART-AUDIO.COM...
- Page 6 Using the volume control on the versions: SM6V(P), SMB6V(P) 1.Remove the speaker grill with the included grill removal tool: 2. Once the grill is removed, you need to flip-off the volume-control cover using a flat screw driver. WWW.APART-AUDIO.COM...
- Page 7 3. Change the volume to your desired level: 4. Remount the volume knob cover 5. Remount the grill by gently pushing it back into place, avoid using to much force in the centre of the grill to avoid grill deformation INFO@APART-AUDIO.COM...
- Page 8 3. Drill holes and fix the SM range speaker to your mounting place 4. Remount the grill by gently pushing it back into place, avoid using to much force in the centre of the grill to avoid grill deformation WWW.APART-AUDIO.COM...
-
Page 9: Specifications
SPL1m / max rated power 99dB Dispersion at 1kHz, 4kHz, 8kHz 180°, 80°, 40° Color White or grey Chassis type Grill construction Metal Dimensions 202x142x72mm Max wire size diameter 2,5mm2 Net weight From 0.8kg to 1kg Gross weight From 0.9kg to 1.1kg INFO@APART-AUDIO.COM... -
Page 10: Warranty Info
* bracket is included with the SMB6 versions only. Warranty info APart-Audio warrants this product to be free of defects in material and workmanship for a period of one year for parts and for a period of one year for labor from the date of original end-user purchase. - Page 11 Notes INFO@APART-AUDIO.COM...
- Page 12 Send your ideas or suggestions to suggestions@apart-audio.com Company names, product names, and names of formats etc. are the trademarks or registered trademarks of their respective owners. © 2010 APart-Audio specifications subject to change without notice. developed by Audioprof nv Industriepark Brechtsebaan 8 bus 1...
