For Models: A10-207 • A10-217
Stainless Steel Combination, Stove & Gas Grill
For questions regarding performance, assembly, operation, parts, or returns,
contact the experts at MAGMA by calling (562) 627-0500 7:00 a.m. - 5:00 p.m.
Pacific Time Monday thru Friday or e-mail us at mail@MagmaProducts.com
Read these instructions carefully before use. Familiarize yourself with the appliance before
connecting it to its gas container. Keep these instructions for future reference.
OWNER'S MANUAL
®
U.S. PATENTS
4,788,962
5,330,154
5,414,090
D 292,163
Other Patents and
Design Patents Pending

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the A10-207 and is the answer not in the manual?

Questions and answers

Related Manuals for Magma A10-207

Summary of Contents for Magma A10-207

  • Page 1 Design Patents Pending For questions regarding performance, assembly, operation, parts, or returns, contact the experts at MAGMA by calling (562) 627-0500 7:00 a.m. - 5:00 p.m. Pacific Time Monday thru Friday or e-mail us at mail@MagmaProducts.com Read these instructions carefully before use. Familiarize yourself with the appliance before...

  • Page 2: Important Safety Warnings

    • USE PROPANE GAS ONLY. FUEL STORAGE SHOULD BE IN COMPLIANCE WITH THE AMERICAN BOAT AND YACHT COUNCIL (ABYC) STANDARDS A-1 (9), MARINE LIQUIFIED PETROLEUM GAS (LPG) SYSTEMS. • FOR NATURAL GAS APPLICATION CONTACT MAGMA. • ALWAYS LIGHT GRILL WITH LID OPEN.
  • Page 3 Flat Surface 1 Select and install appropriate Magma mount in your desired location. Prior to installing the grill, check that mount does not easily move with a reasonable force applied. 2 Next, decide if gas control valve will be easier to access from the center right side or center left side of grill.
  • Page 4 7 Install radiant plate & dome over burner on fire pan ridge. 8 Install grill grate by rotating grate so that both grill grate tabs slide under the holding clips (8a), locking grate and all internal components in correct position. 9 Insert the turbo venturi tube into the threaded pipe on the bottom of the grill body and firmly tighten the threaded nut so nut doesn't turn while rotating the turbo venturi tube.

  • Page 5: Operating Procedures

    • DO NOT CONNECT A HIGH-PRESSURE SUPPLY HOSE FROM A NON-REGULATED TANK DIRECTLY TO GRILL. Magma's grills are designed for use with small disposable propane canisters or with pre-regulated low-pressure propane and optional low-pressure valves. Running high-pressure propane fuel supply lines on a boat is in violation of American Boat &...
  • Page 6 USING THE MARINE KETTLE AS A STOVE Magma’ s patented, unique design of the Marine Kettle allows it to be used as a conventional stove. This permits you to fry, saute, boil, wok, etc. • Remove the grill grate. • Remove the radiant dome •...

  • Page 7: Maintenance

    All valves are set and tested at our factory. Do not attempt to adjust or disassemble the valve. Call Magma if you suspect it is not adjusted properly. Clean valve with a cloth and remove any debris obstructing the orifice.

  • Page 8: Replacement Parts

    REPLACEMENT PARTS A10-217 A10-207 Party Size Original Size 10-453 10-153 Cooking Grill Cooking Grill 10-665 10-765 Radiant Plate Radiant Plate & Dome & Dome 10-657 10-657 Burner Burner 10-658 10-758 Fire Pan Fire Pan 10-651 10-651 Complete Handle Complete Handle Assembly &...

  • Page 9: Troubleshooting Guide

    TROUBLE SHOOTING GUIDE Problem Possible Cause Possible Solution Burner will not Electrode covered with grease Clean electrode light with igniter or residue Electrode not directly under Adjust burner so burner ground strap is burner ground strap directly above electrode Electrode wire loose, Clean, adjust &...

  • Page 10: Limited Warranty

    All implied warranties, including the implied warranties of merchantability and fitness for a particular purpose, are limited in duration to the express warranty periods specified herein for the parts described herein. Some states do not allow limitations on how long an implied warranty lasts, so the above limitation may not apply to you. Neither Magma dealers, nor the retail establishment selling this product has any authority to make any warranties or to promise remedies in addition to or inconsistent with those stated above.
  • Page 11 • A10-215NZ-3 • A10-217NZ-3 For pre-regulated, low pressure, LPG systems. This brass control valve is designed to allow use of the Magma Marine Kettle Grills in residential, marine, and R.V. LPG applications. It is designed to tap into the low pressure side of the regulator.
