LS SV008iS5-2 Instruction Manual

Frequency drives
Hide thumbs
Table of Contents

Advertisement

Quick Links

Thank you for purchasing LS Variable Frequency Drives!
To prevent injury and property damage, follow these
instructions. Incorrect operation due to ignoring instructions
will cause harm or damage. The seriousness of which is
indicated by the following symbols.
DANGER
WARNING
CAUTION
■ The meaning of each symbol in this manual and on your equipment is as
follows.
This is the safety alert symbol.
Read and follow instructions carefully to avoid dangerous situation.
This symbol alerts the user to the presence of "dangerous voltage"
inside the product that might cause harm or electric shock.
■ After reading this manual, keep it in the place that the user always can
contact easily.
■ This manual should be given to the person who actually uses the products
and is responsible for their maintenance.
SAFETY INSTRUCTIONS
This symbol indicates the instant death or
serious injury if you don't follow instructions
This symbol indicates the possibility of
death or serious injury
This symbol indicates the possibility of
injury or damage to property
I
