SERVICE MANUAL
SERVICE MANUAL
AV RECEIVER
MODEL TX-SR707 (B)/(S)/(G)
Black, Silver and Gold models
BMDC
120V AC 60Hz
BMDF
BMMP,SMMP
220-240V AC 50/60Hz
BMMO,SMMO
BMMA,SMMA
BMMQ
GMMR
SAFETY-RELATED COMPONENT
WARNING!!
COMPONENTS IDENTIFIED BY MARK
SCHEMATIC DIAGRAM AND IN THE PARTS LIST ARE
CRITICAL FOR RISK OF FIRE AND ELECTRIC SHOCK.
REPLACE THESE COMPONENTS WITH ONKYO
PARTS WHOSE PART NUMBERS APPEAR AS SHOWN
IN THIS MANUAL.
MAKE LEAKAGE-CURRENT OR RESISTANCE
MEASUREMENTS TO DETERMINE THAT EXPOSED
PARTS ARE ACCEPTABLY INSULATED FROM THE
SUPPLY CIRCUIT BEFORE RETURNING THE
APPLIANCE TO THE CUSTOMER.
Ref. No. 4153
RC-742M
ON THE
TX-SR707
072009
