Onkyo TX-SR703/E Service Manual

SERVICE MANUAL SERVICE MANUAL
AV RECEIVER
MODEL
STANDBY/ON
STANDBY
ZONE 2
POWER
ON OFF
PURE AUDIO MULTI CH DVD VIDEO 1 VIDEO 2
Black, Golden and Silver models
BMDD,BMDC,SMDC
BMPP,SMPP,BMPA,GMPA
GMWT
GMGK,GMGQ,GMGR
SAFETY-RELATED COMPONENT
WARNING!!
THE MARK
PARTS INDICATES THE CRITICAL FOR RISK OF
FIRE AND ELECTRIC SHOCK.
WHEN REPLACING, BE SURE TO USE PARTS OF
IDENTICAL DESIGNATION.
MAKE LEAKAGE-CURRENT OR RESISTANCE
MEASUREMENTS TO DETERMINE THAT EXPOSED
PARTS ARE ACCEPTABLY INSULATED FROM THE
SUPPLY CIRCUIT BEFORE RETURNING THE
APPLIANCE TO THE CUSTOMER.
