Pyle PDWM4540 Wireless Microphone System, UHF Quad Channel
Fixed Frequency, 2 Handheld Microphones, 2 Body-Pack Transmitters,
2 Headset & 2 Lavalier Mics, Rack Mountable
UHF Band Receiver System
Quad Frequency Channel Design (Channel 1, 2, 3, 4)
Broad Frequency Response Range & Low Distortion
High Signal/Noise Ratio Performance
RF Signal & AF Signal LED Indicators
Radio Frequency and Audio Frequency
Independent Channel Adjustable Volume Controls
Detachable Dual Antennas
Rack Mountable System
Includes (2) Handheld Microphones, (2) Body-Pack Transmitters,
(2) Headset & (2) Lavalier Mics
4 XLR Output Connector Jacks
System Receiver:
Image & Spurious Rejection: >70dB
Receiving Sensitivity: -105dBm
Signal/Noise Ratio: >105dB
Border Upon Channel Rejection: >70dB
T.H.D.: <1%
Audio Output Level: 0-300mV
Power Requirements: 13-15V DC nominal 1000mA
Dimensions (L x W x H): 15.51'' x 9.25'' x 2.16''
Microphones:
RF Power Output: >10dBm
Modulation Type: FM
Max. Deviation: +/- 40kHz
Nominal Power Current: <55mA
Spurious Emission: >55dBc
Battery Powered: 2 x 'AA' Batteries (Included)
Batteries Included
Weight: 180g
Transmitters:
RF Power Output: >10dBm
Modulation Type: FM
Max. Deviation: +/- 40kHz
Nominal Power Current: <40mA
Spurious Emission: >53dBc
Battery Powered: 2 x 'AA' Batteries (Included)
Batteries Included
Weight:60g
Bodypack transmitters require 2 'AA' batteries
13
Pyle PDWM4560 Wireless Microphone System, UHF Quad Channel
Fixed Frequency, 4 Body-Pack Transmitters, 4 Headset & 4 Lavalier
Mics, Rack Mountable
UHF Band Receiver System
Quad Frequency Channel Design (Channel 1, 2, 3, 4)
Broad Frequency Response Range & Low Distortion
High Signal/Noise Ratio Performance
RF Signal & AF Signal LED Indicators
Radio Frequency and Audio Frequency
Independent Channel Adjustable Volume Controls
Detachable Dual Antennas
Rack Mountable System
Includes (4) Body-Pack Transmitters, (4) Headset & (4) Lavalier Mics
4 XLR Output Connector Jacks
System Receiver:
Image & Spurious Rejection: >70dB
Receiving Sensitivity: -105dBm
Signal/Noise Ratio: >105dB
Border Upon Channel Rejection: >70dB
T.H.D.: <1%
Audio Output Level: 0-300mV
Power Requirements: 13-15V DC nominal 1000mA
Dimensions (L x W x H): 15.51'' x 9.25'' x 2.16''
Transmitters:
RF Power Output: >10dBm
Modulation Type: FM
Max. Deviation: +/- 40kHz
Nominal Power Current: <40mA
Spurious Emission: >53dBc
Dimensions (H x L x W): 4.13'' x 2.55'' x 1.18''
Battery Powered: 2 x 'AA' Batteries (Included)
Batteries Included
Weight: 60g
Bodypack transmitters require 2 'AA' batteries
