- Page 1 • PDWM8325 • PDWM8350 • PDWM8374 PDWM8374 PDWM8325 - PDWM8350 - PDWM8374 8 Mic Professional Handheld VHF Wireless Microphone System...
-
Page 2: Main Features
FOREWORD Please read these instructions carefully before operating this product and retain them for future reference. MAIN FEATURES • Uses multilevel high frequency and midfrequency narrowband lters to avoid interference. • Quartz crystal oscillating circuits guarantee a steady frequency. • Audio compression and expansion technology to increase the dynamic range and lower feedback. -
Page 3: Technical Parameters
TECHNICAL PARAMETERS UNIT SPECIFICATION Modulation T.H.D -0.8% Distance 50-100M Temperture 14-131°F RECEIVER S/Noise Ratio ≥105dB Removing weight 50ms Audio output 0-0.35Vp-p 5k Output connection 6.3 mm plug/XLR Power supply DC:12-17V www.PyleUSA.com... -
Page 4: Handheld Transmitter
TECHNICAL PARAMETERS HANDHELD TRANSMITTER 1. Mic Grill 2. Power ON Indicator 3. Power ON/OFF switch 4. Low voltage indicator 5. 9V Battery 6. Battery cover LAVALIER TRANSMITTER 1. Power ON/OFF switch 2. Power ON Indicator 3. Low battery LED 4. Install Battery box 5. -
Page 5: Front Panel
TECHNICAL PARAMETERS FRONT PANEL Pr o fessi o nal Wirel e ss Mic rophone 1. Power Switch 2. LCD Display 3. RF Indicator BACK PANEL 1. Antenna 2. Volume Controls 3. Unbalance Output 4. Balance Output 5. DC Power Input www.PyleUSA.com... -
Page 6: Receiver Installation
SYSTEM OPERATION 1. Please take note of the following work ow diagram for reference on connecting this machine. Connect the mix out of receiver with mic input on the ampli er or out A, B, C, D and mic input on the ampli er. 2. -
Page 7: Troubleshooting
TROUBLESHOOTING Some common problems and their solutions are printed below. PROBLEM SOLUTION • Make sure the transmitter No sound; • POWER switch is ON and the receiver is plugged into a RF light(s) not power source glowing • Check battery. •... - Page 8 • PDWM8325 8-Ch. Wireless Microphone System, UHF Microphone Receiver Kit with (8) Mics, Rack Mount • PDWM8350 8-Ch. Wireless Microphone System, UHF Microphone Receiver Kit with (4) Handheld Mics & (4) Beltpack/Headset Mics, Rack Mount • PDWM8374 8-Ch. Wireless Microphone System, UHF Microphone Receiver Kit with (8) Beltpacks,...
