Summary of Contents for Labokey 8101SL
- Page 1 Instruction Manual AUTOMATIC SHEET PRINT LAMINATOR for L8100 ８１０１ＳＬ...
-
Page 2: Introduction
INTRODUCTION This manual book is a guidance to operate the equipment correctly. Read the manual carefully and thoroughly for a full understanding before operating the equipment. Always keep themanual book aside of the equipment so as to refer to and follow instructions, whenever it is necessary, to cope with unexpected trouble and/or unfamiliar procedures in operations. -
Page 3: Table Of Contents
CONTENTS INTRODUCTION ･･････････････････････････････････････････････････ 1 CONTENTS･･･････････････････････････････････････････････････････ 2 SAFETY･･････････････････････････････････････････････････････ 3 1-1 SAFETY GUIDE (PRECAUTIONS ON OPERATING THE EQUIPMENT)････････ 3 1-2 LOCATION OF WARNING LABELS ････････････････････････････････････････ 3 1-3 WARNING LABELS･･･････････････････････････････････････････････････････ 4 1-4 DESCRIPTION OF SAFETY WORDS･･･････････････････････････････････････ 4 SPECIFICATIONS ････････････････････････････････････････････ 5 COMPONENT NAME ･････････････････････････････････････････ 6 INSTALLATION･･･････････････････････････････････････････････... -
Page 4: Safety
SAFETY 1 ‒ 1 SAFETY GUIDE (PRECAUTIONS ON OPERATING THE EQUIPMNET) Operations Precautions Label Reference to Location Manual Book Setting of Be careful not to have 5-1 Setting Laminating Tape Paper Holder your fingers pinched. W - 1 5-2 Setting Paper 5-3 Operation 1 ‒... -
Page 5: Warning Labels
1 ‒ 3 WARNING LABELS When Warning Labels put on the equipment become unreadable or be peeled off, please contact us or our distributors. Label Location Warning Label Part No. W ‒ 1 L802W01 1 ‒ 4 DESCRIPTION OF SAFETY WORDS Warning and Caution are provided for the safety notice. -
Page 6: Specifications
2. SPECIFICATIONS This equipment is a modified model of LABOKEY 802 for the purpose of using in combination with a puncher unit of Labokey 8100 automatic Sticker Print Puncher. Standard specifications arereferred to the Instruction Manual for Labokey 802 enclosed in the package. -
Page 7: Component Name
3. CONPONENTS NAMES LABOKEY 802 Guide Roller A Accumu-Roller Guide Roller B Accumu-Section Base Board Connector Cord... -
Page 8: Installation
4. INSTALLATION 4-1 UNPACKING AND CONFIRMATION OF CONTENTS Unpack the unit to find following components in it: ● LABOKEY 802 ……………………… 1 Unit ● Accumu-Unit ………………………… 1 Unit ● Instruction Manual …………………… 1 Booklet 4-2 LOCATION AND ENVIRONMENT Explanations refers to about location and environment which the equipment is installed. -
Page 9: Connecting To The L8100 Puncher Unit
4-3-3 Connecting to the L8100 Puncher Unit. ① Referring to the picture on the right, remove the [Position Setting Plate B] by unscrewing 3 screws. L8100 Screws x 3 Position Setting Plate B ② Using 2 out of the removed 3 screws, connect the L8101SL to the L8100 Puncher Unit. -
Page 10: Operations
5. OPERATION: Notes: Keep [Paper Cover Holder] closed before lifting Paper Holder. Be careful not to have your fingers pinched in closing [Paper Cover Holder]. 5-1 SETTING LAMINATING TAPE 1. Paste the tape onto a sheet of paper slightly wider than the tape. -
Page 11: Setting Paper
5. Put the sheet of paper with the tape pasted through outside [Tape Guide Roller] and Paper [Laminating Roller] and draw it out straight Holder from underneath [Paper Feed Pressure Roller]. Place the paper on [Laminating Roller]. Paper Feed Adhesive side of the tape now faces upward. Pressure Roller Tape Guide Roller... - Page 12 1. Turn [Paper Width Adjust Knob] to have [Paper Width Guides] Fixing Screw aligned to the width of paper, and set a deck of papers with tips properly aligned. Loosen the screw of [Paper Length Block] and have the block aligned to the rear end of paper. Tighten the screw to fix the block.
-
Page 13: Changing Papers (From Narrower Paper To Wider Paper)
5-2-1 Changing Papers (from narrower paper to wider paper) Note: When the width of paper is changed, ensure to change the Paper Width Guides of L8100. The paper width adjustment cardinal point is from center. 1. Open [Paper Holder Cover] and widen the span of [Paper Width Guides] with [Paper Width Adjust Knob] on the back to match the width of the paper to be used. -
Page 14: Operation
5-3 OPERATION Explanation refers to functions and operations of the equipment. LED indicators show the function currently in use and the buzzer warns the operator of the errors in operation. Warning by buzzer Incorrect setting of the Paper Holder ‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐ 0.05sec. Detection by the Space Sensor −−−−−−−−−−... - Page 15 3. Start Laminating and Kiss-Punching Work. 〇 〇 POWER P.END SPACE SEN.ON The operations described below are required for both L8100 and L8101SL. ― L8101SL 〇 After setting [Laminating Tape] and [Paper] correctly, depress START/STOP AUTO [AUTO] switch. [AUTO] switch and [SEN.ON] LED are lighted on. Then, depress [START/STOP] switch.
-
Page 16: Warning Of Errors Operation
4. Power OFF 〇 〇 〇 〇 L8101SL POWER P.END SPACE SEN.ON ― Depress the O end of [POWER] switch to turn off the unit. [POWER] LED turns off. 〇 Unplug the AC Adapter from an outlet. START/STOP AUTO 5-3-2 WARNING OF ERRORS OPERATION . L8100 MANUAL AUTO... -
Page 17: Attention At The End Of Ｊｏｂ
When the space is about 2-5mm, close Paper Holder Cover, Space send papers out by manually turning [Paper Feed Knob] while drawing paper by hand to prevent undesired sticking of paper. During this salvage procedure, make sure that next print is laminated correctly.
