INTRODUCTION
Congratulations on your purchase of the Jensen MPA6611X Mobile Receiver. It's a good idea
to read all of the instructions before beginning the installation. We recommend having your
Jensen MPA6611X installed by a reputable installation shop.
Features
XM READY
•
Requires Terk XMD1000 Satellite Tuner (Sold Separately)
•
Requires Terk XMDJEN100 XM Cables (Sold Separately)
•
Advanced display shows the artist, song title and XM channel and category at a glance
•
Direct Channel entry
MP3 / WMA
•
MP3 / WMA- CD-R/RW compatible
•
ID3 tag compatible
•
MP3 / WMA quick file search via rotary volume knob
•
MP3 / WMA song surfing
•
MP3 / WMA file search by title, artist or folder
•
MP3 / WMA direct track access
•
Supports up to 32 characters for file or folder names
•
MP3 / WMA "loaded/inserted" icon
•
High-speed audible fast forward/rewind
•
MP3 100-second ESP - Electronic Skip Protection
•
WMA 200-second ESP - Electronic Skip Protection
•
16MB SDRAM buffer
CD
•
Last position memory
•
Random/repeat/intro
•
High-speed audible track search
•
1-Bit D/A converter
•
Anti-shock mechanism
•
40-second ESP - Electronic Skip Protection
AM/FM Tuner
•
30 station presets (18 FM/12AM)
•
JENSEN Plus Tuner II
•
Auto station store
•
Preset scan
•
One-touch memory
•
Auto stereo/mono
•
Manual local/distance
•
Manual tuning up/down
•
Auto seek tuning up/down
•
5-second Scan tuning
Chassis
•
Motorized swing-down detachable faceplate
•
1.0 DIN
•
Import ISO/DIN mountable
•
20-pin power harness
General
•
INTEGRATED SD CARD READER
•
Supports MP3 and WMA Playback
•
Supports up to 1GB SD card
•
INTEGRATED Front Panel USB Input
•
USB 2.0 compatible
•
Supports up to a 1GB SD Card
•
Supports most standard "THUMB DRIVES"
•
Playback MP3 / WMA files from your thumb drive
•
User friendly setup menu
•
LCD contrast control
•
Clock
•
Switchable Bi-color preset illumination - Red or Blue
•
Ergo style Infrared remote control (included)
•
High contrast positive Liquid Crystal Display (LCD)
•
MOSFET audio IC
•
Electronic volume, bass, treble, balance, fader
•
Rotary encoder audio control
•
Programmable turn-on volume
•
Multi-button power on
•
Keyless CD eject
•
2-Pair Front / Rear pre-amp outputs
•
5V Peak / 2V RMS RCA pre-amp output voltages
•
200-ohm low impedance preamp output
•
1-Subwoofer pre-amp output (RCA) (adjustable level control)
•
200Hz low pass subwoofer crossover
•
1-Pair rear RCA auxiliary input
•
Flex-Fader
•
iEQ5 - instant EQ
•
5-selectable iEQ curves - Beat, Jazz, Classic, Pop and Rock
•
iX-Bass - instant eXtended bass
jLINK Ready (Included)
•
Controls all iPod's except "Shuffle"
•
Displays all text information including category, track name, artist and channel number
•
Requires jLINK iPod Approved Cable
1
(Sold
Separately)
Advertisement
Table of Contents
Related Manuals for Audiovox Jensen MPA6611X
Summary of Contents for Audiovox Jensen MPA6611X
- Page 1 MPA6611X INTRODUCTION Congratulations on your purchase of the Jensen MPA6611X Mobile Receiver. It’s a good idea to read all of the instructions before beginning the installation. We recommend having your Jensen MPA6611X installed by a reputable installation shop. Features XM READY •...
-
Page 2: Tools And Supplies
PREPARATION Tools and Supplies The following tools and supplies are needed to install the radio. • Torx type, flathead and Philips screwdrivers • Wire cutters and strippers • Tools to remove existing radio (screwdriver, socket wrench set or other tools) •... - Page 3 MPA6611X WIRING Wiring with a Wiring Adapter (Purchased Separately) Connect Wires You can make all these connections without even being in the vehicle. Splice or crimp wires. Attach wiring adapter to the car wiring harness. Wiring Diagram / Color Codes Power Antenna (dark blue wire) - Connect to the power antenna or a amplifier.
-
Page 4: Installation
Reconnect Battery When wiring is complete, reconnect the battery negative terminal. Technical Assistance If you require assistance, contact Technical Support at 1-800-323-4815 from 8:30am to 7:00pm EST Monday through Friday and from 9:00am to 5:00pm EST on Saturday. Connecting the Satellite Radio Receiver (optional) ®... -
Page 5: Kit Installation
MPA6611X Place the radio in front of the dashboard opening so the wiring can be brought through the mounting sleeve. A6 61 TU NE Follow the wiring diagram carefully and make certain all connections are secure and insulated with crimp connectors or electrical tape to ensure proper operation. After completing the wiring connections, attach the front panel and turn the unit on to confirm operation (vehicle ignition switch must be on). -
Page 6: Operation
OPERATION Power Press the power button (1) or any other button on the front of the radio (except Eject) to turn the unit on. Press and hold the power button to turn the unit off. Mode Press MODE (2) to select a different mode of operation, as indicated on the display panel. Available modes include TUNER (F1, F2, F3, AM1, AM2), XM RADIO (if connected), S-CDP (CD), USB Host, SD/MMC and AUX (auxiliary). -
Page 7: Liquid Crystal Display (Lcd)
MPA6611X MID-CFQ (Middle Center Frequency) To adjust the Middle Center Frequency, press the volume control until “MID-CFQ” appears in the display. Rotate the control to select one of the following Middle Center Frequency options: 500Hz, 1KHz, 1.5KHz, 2.5KHz. MIDDLE-Q (Middle Quality Factor) To adjust the Middle Quality Factor, press the volume control until “MIDDLE-Q”... -
Page 8: Front Panel Release
TUNING (11) button to move to the next or previous option. Once the desired option appears in the display, adjust that option by rotating the volume control within five seconds. The following options are adjusted through this menu feature: Contrast The contrast level of the display is set at “CONTRAST 05”... -
Page 9: Reset Button
MPA6611X Reset Button The reset button (23) is located on the front of the chassis and can only be accessed with the front panel removed. The reset circuitry protects the microprocessor circuitry. Since resetting the unit will erase the time and preset memories, it should only be activated upon initial installation after all wiring is complete or if there is a malfunction of any of the switches on the unit. -
Page 10: Displaying The Identification (Id) Code
Preset Scan Scans stations stored in the current band. Select a band (if needed). Press AS/PS (21) for less than three seconds. The unit will pause for ten seconds at each preset station. Press AS/PS again to stop scanning when the desired station is reached. Stereo The unit will automatically pick up a stereo signal, when available. -
Page 11: Cd Player Operation
MPA6611X Tuner Modes Press the AS/PS button (21) to change the tuner mode to the following options in the order listed. • Channel Name • Genre (News, Sports, Hits, Kids, etc.) • Artist name • Song Name • 11 Bar Spectrum Indicator If the selected channel name, artist, or title exceeds eleven characters, the display information will scroll twice upon selection. -
Page 12: Mp3/Wma Operation
MPA6611X COPY Pause Press the pause >/|| button (12) to suspend disc play. Press the pause button again to resume disc play. Track Select Press the UP TUNING (10) or DOWN TUNING (11) button for less than one second to advance to the next track on the CD. - Page 13 MPA6611X Entering ID3 Tag This unit supports ID3 tag versions 1.0 and 1.1. For the character codes, refer to the table to the right. The unit also supports CD-TEXT encoded discs for Album, Track and Artist Title information. Entering File and Folder Names Names using the code list characters are the only file names and folder names that can be entered and displayed.
-
Page 14: Ipod Operation
Accessing the ID3 Tag Press AS/PS (21) repeatedly during MP3/WMA play to access the ID3 information manually. The display will show any of the following information that is programmed on the disc: Folder Name, File Name, Album Title, Track Title, Artist Title. ICON DESCRIPTION FOLDER ICON... -
Page 15: Track Selection
MPA6611X Track Selection Select a Track Press the UP TUNING button (10) or DOWN TUNING button (11) for < 1 second to advance to the next song in the current folder. Audible Fast Forward / Fast Reverse Press and hold the UP TUNING button (10) or DOWN TUNING button (11) for > 1 second to fast forward or fast reverse. -
Page 16: Remote Control
Navigating Files Please refer to “MP3/WMA Operation” on page 12 for information regarding directory navigation and file searching. NOTE: The MPA6611X will recognize MOST flash memory based storage devices. The MPA6611X does not support USB multi-card or all-in-one card readers with a flash memory device inserted. -
Page 17: Care And Maintenance
MPA6611X CARE AND MAINTENANCE CD Player The following guidelines will help you extend the life of your CD player: When cleaning the vehicle interior, do not get water or cleaning fluids on the unit. The CD player will not operate properly in extreme hot/cold or under damp conditions. In case of such conditions, wait until the vehicle interior reaches a normal temperature or any condensation on the disc player lens has evaporated before using the player. -
Page 18: Specifications
Specifications subject to change without notice. 12-MONTH LIMITED WARRANTY AUDIOVOX CORPORATION (the Company) warrants to the original retail purchaser of this product that should this product or any part thereof, under normal use and conditions, be proven defective in material or workmanship within 12 months from the date of original purchase, such defect(s) will be repaired or replaced with new or reconditioned product (at the Company's option) without charge for parts and repair labor. - Page 19 MPA6611X Audiovox Electronics Corporation Hauppauge, NY 11788 Technical Assistance: 1-800-323-4815 www.jensen.com © 2006 Audiovox Ver. 062106 Printed in China...
- Page 20 MPA6611X...
