ROBATA 72 & 54 CONCRETE
We recommend that our fire pits be
installed and serviced by professionals
that are certified in the U.S. by NFI
(National Fireplace Institute)
Electronic Ignition
Installation + Owner's Manual
Burner conforms to: ANSI Z21.97/CSA 2.41 - (2012/10/01) "Outdoor Decorative Gas Appliances"
DANGER - IF YOU SMELL GAS
1. Shut off gas to the appliance.
2. Extinguish any open flame.
3. If odor continues, keep away from the appliance and immediately call your gas
supplier or fire department.
WARNING
Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this
or any other appliance. An LP-cyllinder not connected for use shall not be stored in the
vicinity of this or any other appliance.
DANGER
CARBON MONOXIDE HAZARD
This appliance can produce carbon monoxide which has no odor.
Using it in an enclosed space can kill you.
Never use this appliance in an enclosed space such as a camper, tent, car
or home.
WARNING:
Improper installation, adjustment, alteration, service or maintenance can cause injury
or property damage. Read the installation, operating and maintenance instructions
thoroughly before installing or servicing this equipment.
WARNING: FOR OUTDOOR USE ONLY!
INSTALLER: Leave this manual with the appliance. CONSUMER: Retain this manual for future reference
Advertisement
Table of Contents
Related Manuals for Paloform Robata 72 concrete
Summary of Contents for Paloform Robata 72 concrete
- Page 1 ROBATA 72 & 54 CONCRETE Electronic Ignition Installation + Owner's Manual Burner conforms to: ANSI Z21.97/CSA 2.41 - (2012/10/01) “Outdoor Decorative Gas Appliances” DANGER - IF YOU SMELL GAS 1. Shut off gas to the appliance. 2. Extinguish any open flame. 3.
-
Page 2: Safety Information
SAFETY INFORMATION ROBATA 72/54 CONCRETE FIRE | Installation & Owner’s Manual WARNINGS: WARNING: 10. Turn the appliance off and let cool before servicing, Any modification to this appliance or its installing, repairing or covering. Any guard or other controls can be dangerous. protective device removed for servicing the appliance IMPORTANT: This appliance should must be replaced prior to operating the appliance. -
Page 3: Basic Assembly
BASIC ASSEMBLY ROBATA 72/54 CONCRETE FIRE | Installation & Owner’s Manual UNPACK: Account for all parts (p. 15-16) FRAGILE: Handle with care LEVEL: Place on a solid, level surface AIR VENTS: Do not block ventilation gaps (p. 4-5) GAS / ELECTRICAL: Supply lines are routed through the base of the unit and must be installed by licensed trades MEDIA TOPPINGS: Review correct placement (p. - Page 4 DIMENSIONS - ROBATA 54 ROBATA 72/54 CONCRETE FIRE | Installation & Owner’s Manual SIDE 12-1/2” VENTILATION GAP 8" DO NOT OBSTRUCT 54" 24" 1372 20-3/4" 12-1/2" BOTTOM 22" 22" BASE OPENING...
- Page 5 DIMENSIONS - ROBATA 72 ROBATA 72/54 CONCRETE FIRE | Installation & Owner’s Manual SIDE 12-1/2” VENTILATION GAPS 8” DO NOT OBSTRUCT 72” 24” 1829 16-3/4” 11-1/4” BOTTOM 22” BASE OPENINGS...
-
Page 6: Specifications & Clearances
SPECIFICATIONS & CLEARANCES ROBATA 72/54 CONCRETE FIRE | Installation & Owner’s Manual ROBATA 54 ROBATA 54 ROBATA 72 ROBATA 72 NATURAL GAS PROPANE NATURAL GAS PROPANE Burner Model # LIN-36 LIN-36P LIN-48 LIN-48P Max Heat Input 60,000 BTU/h 57,000 BTU/h 80,000 BTU/h 77,000 BTU/h Inlet Pressure - Min,... - Page 7 Outdoor Fire Pit Burner. These Do not obstruct the pilot ignition port with burner media! Do plates contain important information. not use media not supplied by Paloform! 5. Place the burner assembly on a stable surface. Ensure NOTICE: burner is level.
- Page 8 BURNER MEDIA & DECORATIVE TOPPING ROBATA 72/54 CONCRETE FIRE | Installation & Owner’s Manual METAL LID (OPTIONAL) DECORATIVE TOPPING MEDIA (VARIOUS): FILL TOPPING TRAY - COVER BURNER MEDIA - KEEP BELOW LID LINE BURNER MEDIA: CRUSHED GLASS (NG); LAVA ROCK (LP) - FILL BURNER MEDIA TRAY...
-
Page 9: Connecting To Gas Supply
CONNECTING TO GAS SUPPLY ROBATA 72/54 CONCRETE FIRE | Installation & Owner’s Manual WARNING: INSTALLATION REQUIREMENTS CHECKING GAS CONNECTION A qualified service person must connect Installation must include a manual shutoff valve, union, WARNING: Test all gas piping and connections the appliance to the gas supply. -
Page 10: Initial Lighting Instructions
LIGHTING YOUR FIRE PIT ROBATA 72/54 CONCRETE FIRE | Installation & Owner’s Manual WARNINGS INITIAL LIGHTING INSTRUCTIONS Failure to follow these instructions exactly may result in fire or explosion causing property damage, personal injury or loss Before placing burner assembly into a housing: of life. - Page 11 LIGHTING YOUR FIRE PIT ROBATA 72/54 CONCRETE FIRE | Installation & Owner’s Manual WARNING: OPERATING INSTRUCTIONS This appliance is designed to be connected to a power 1. STOP! Read the safety information on pages 1, 2 and 10 of this manual. source that is controllable by a switch.
-
Page 12: Cleaning And Maintenance
CLEANING AND MAINTENANCE ROBATA 72/54 CONCRETE FIRE | Installation & Owner’s Manual KEEP YOUR FIRE PIT COVERED Covering your fire pit with its all-weather cover when not in use will prolong the life of all its components. WARNING: Turn off gas before servicing fire pit. We recommend that a qualified service technician perform the following check-ups at the beginning of each fire pit season. -
Page 13: Troubleshooting
ROBATA 72/54 CONCRETE FIRE | Installation & Owner’s Manual TROUBLESHOOTING WARNING: OBSERVED PROBLEM POSSIBLE CAUSE REMEDY Turn off appliance and let cool before Burner shuts off/relights intermittently. Wind or gusts in excess of 16 km/h Protect pilot from wind with servicing. - Page 14 TROUBLESHOOTING cont’d ROBATA 72/54 CONCRETE FIRE | Installation & Owner’s Manual WARNING: OBSERVED PROBLEM POSSIBLE CAUSE REMEDY Turn off appliance and let cool before When power is turned on, nothing No power to unit Check connections between happens controls, power adapter and servicing.
-
Page 15: Illustrated Parts List
Power Adapter 120V-NA E-POW-24VAC same (not shown) WARNING: Failure to position parts in accordance with diagrams or failure to use parts specifically approved for this appliance may result in property damage or personal injury. REPLACEMENT PARTS ARE AVAILABLE FROM PALOFORM... - Page 16 ILLUSTRATED PARTS LIST - cont’d ROBATA 72/54 CONCRETE FIRE | Installation & Owner’s Manual Natural Gas Propane CIR Control Box Cover CIR-E-BOX same CIR Control Box Housing CIR-E-BOX same Dual Solenoid Valve E-VAL-BASO w/ LP reg. spring 3/8”x1-1/2” - Nipple 3/8”...
-
Page 17: Wiring Diagram
ILLUSTRATED PARTS LIST ROBATA 72/54 CONCRETE FIRE | Installation & Owner’s Manual Wiring Diagram IGNITION CONTROL BOARD: E-BOARD-CC9 PILOT: PIL-E-410 OR PIL-E-410LP GAS VALVE: E-VAL-BASO AC POWER ADAPTER INPUT: AC 120V 60 Hz 8A OUTPUT: 24 VAC, 750 mA CHASSIS GROUND... -
Page 18: Warranty Information
This warranty is expressly in lieu of other warranties, express or implied, including the warranty of merchantability of fitness for purpose and of all other obligations or liabilities. Paloform does not assume for it any other obligations or liabilities in connection with sale or use of the appliance. In states that do not allow limitations on how long an implied warranty lasts, or do not allow exclusion of indirect damage, those limitations of exclusions may not apply to you.
