- Page 1 Alcatel-Lucent 4306 OmniAccess Switch...
- Page 2 Legal Notice The use of Alcatel-Lucent switching platforms and software, by all individuals or corporations, to terminate Cisco or Nortel VPN client devices constitutes complete acceptance of liability by that individual or corporation for this action and indemnifies, in full, Alcatel- Lucent from any and all legal actions that might be taken against it with respect to infringement of copyright on behalf of Cisco Systems or Nortel Networks."...
-
Page 3: Table Of Contents
Storage Specifications ..................15 Safety and Regulatory Compliance ..............16 FCC Class B Device..................16 Proper Disposal of Alcatel-Lucent Equipment ............16 Waste of Electrical and Electronic Equipment ..........17 European Union RoHS ..................17 China RoHS ....................17 Alcatel-Lucent 4306 OmniAccess Switch | Installation Guide Contents | 3... - Page 4 4 | Contents Alcatel-Lucent 4306 OmniAccess Switch | Installation Guide...
-
Page 5: Preface
Related Documentation The following documentation are referred to in this guide and are considered components of the complete documentation set needed for a successful installation and management of an Alcatel-Lucent switch. AOS-W Quick Start Guide AOS-W User Guide... -
Page 6: Contacting Alcatel-Lucent
Support Site https://service.esd.alcatel-lucent.com Support Email esd.support@alcatel-lucent.com Table 2 Contact Information Telephone Support North America 1-800-995-2696 Latin America 1-877-919-9526 Europe +33 (0) 38 855 6929 Asia Pacific +65 6240 8484 Worldwide 1-818-878-4507 6 | Preface Alcatel-Lucent 4306 OmniAccess Switch | Installation Guide... -
Page 7: Alcatel-Lucent 4306 Hardware Overview
The Alcatel-Lucent 4306 Switch requires AOS-W 3.4.0 or later. AOS-W software builds prior to version 3.4.0 does not support the Alcatel-Lucent 4306 Switch. If your network currently runs a software build prior to 3.4.0, you must upgrade the software on your master and local switches to 3.4.0 or later prior to installing an Alcatel-Lucent 4306 Switch in your existing network. -
Page 8: Hardware Model Overview
Port LEDs In non-rack deployments, the Alcatel-Lucent 4306 is placed with the front facing out. This allows the cables to be hidden and create a more aesthetically pleasing look. Therefore, a set of LEDs displaying link activity on the ports is placed on this side. -
Page 9: Rear View
AC Power Socket USB port AC Power Socket The Alcatel-Lucent 4306 supports integrated AC powering and the AC power socket on the rear of the unit is for use with an AC power cord (country-specific). Refer to "Power Specifications" on page 17 for power specification details. -
Page 10: Serial Console Port Adaptor
Output Output USB Ports The Alcatel-Lucent 4306 has one USB 2.0 interface. These interfaces allow the use of EVDO/HSPDA modem, flash or disk storage devices, or a printer 10 | Alcatel-Lucent 4306 Hardware Overview Alcatel-Lucent 4306 OmniAccess Switch | Installation Guide... -
Page 11: Media Eject Button
Media Eject Button The Alcatel-Lucent 4306 is equipped with a media eject button, which allows users to eject storage devices safely and place the system in standby. Pushing the media eject button changes the state of the Alcatel-Lucent 4306; the table below describes the states and LED behaviors associated with use of the media eject button. -
Page 12: Led Status Indicators
LED Status Indicators Table 5 Alcatel-Lucent 4306 LED Status Indicators Label Function Indicator Status Power POWER Input Power Status Indicator On (Solid Green) Power on No Power Status STATUS Module Status Indicator On (Solid Green) Device is operational On (Solid Red) -
Page 13: Alcatel-Lucent 4306 Installation
Alcatel-Lucent 4306 Installation Installation Pre-Installation Requirements The following tools and equipment are required for installation of an Alcatel-Lucent 4306 switch. AC Power Cord (country-specific) Physical Installation Tabletop Deployment To deploy an Alcatel-Lucent 4306 switch on a flat surface, such as a tabletop: 1. - Page 14 14 | Alcatel-Lucent 4306 Installation Alcatel-Lucent 4306 OmniAccess Switch | [Doc Type]...
-
Page 15: Appendix A Specifications, Safety, & Compliance
Operating Humidity Range: 5% to 95% (RH), non-condensing Storage Specifications Storage Temperature Range: 0°C to 50°C (32°F to 122°F) Storage Humidity Range: 5% to 95% (RH), non-condensing Alcatel-Lucent 4306 OmniAccess Switch | Installation Guide Specifications, Safety, & Compliance | 15... -
Page 16: Safety And Regulatory Compliance
For a complete list of Country Specific Regulations please speak with your Alcatel-Lucent Representative . Proper Disposal of Alcatel-Lucent Equipment For the most current information on Global Environmental Compliance and Alcatel-Lucent products please see our website at http://www.alcatel-lucent.com/enterprise. 16 | Specifications, Safety, & Compliance... -
Page 17: Waste Of Electrical And Electronic Equipment
Lead (including Solder used in printed circuit assemblies), Cadmium, Mercury, Hexavalent Chromium, and Bromine. Some Alcatel-Lucent products are subject to the exemptions listed in RoHS Directive Annex 7 (Lead in solder used in printed circuit assemblies). Products and packaging will be marked with the “RoHS” label shown at the left indicating conformance to this Directive. - Page 18 18 | Specifications, Safety, & Compliance Alcatel-Lucent 4306 OmniAccess Switch | Installation Guide...
- Page 19 Alcatel-Lucent 4306 OmniAccess Switch | Installation Guide Specifications, Safety, & Compliance | 19...
- Page 20 October 2009 | 0510573-02 Alcatel-Lucent 4306 OmniAccess Switch | Installation Guide...
