Page 1: Table Of Contents
Special Features Product Replacement on a Prorated Basis Knife Grommets Limitations Double Cylinder Setup - Using Aqua Lung Twin Tank Kit Basic Setup Pre-Dive Inspection for BC's using Powerline Inflator Attaching the MP Hose to the First Stage BC Inspection Checklist... -
Page 2: Copyright Notice
Aqua Lung. It may not be distributed through the internet or computer bulletin board systems without prior consent in writing from Aqua Lung. -
Page 3: Safety Information
This manual provides essential instruction for the proper fitting, adjustment, inspection and care of your new BC. Because Aqua Lung BC’s utilize patented technology, it is very important to take the time to read these instructions in order to understand and fully enjoy the features that are unique to your specific model. - Page 4 Factory prescribed service for this BC must be performed at least once annually by a factory trained technician who is employed by an Authorized Aqua Lung Dealer or Distributor. Annual service consists of a complete overhaul of the power inflator, and a general air leak inspection of the bladder and valve connections.
- Page 5 If you have any questions regarding your Buoyancy Compensator or the information found in this manual, please contact your regional Aqua Lung Dealer or Distributor. Distributor information is available on the Aqua Lung website at: www.aqualung.com...
-
Page 6: Dealer Inspection And Service
NOTE: It is important to obtain prescribed dealer service for your BC at least once annually, from an Authorized Aqua Lung Dealer or Distributor, your personal safety and the mechanical integrity of your BC depends on it. © 2012 Aqua Lung International... -
Page 7: Annual Service And Inspection Record
English Home ANNUAL SERVICE AND INSPECTION RECORD Purchase Date: Store Name: Country: BC Model: Serial Number: DATE DEALER NAME CITY, STATE COUNTRY TECH INITIALS © 2012 Aqua Lung International... -
Page 8: Warranty Information
Aqua Lung warrants to the original purchaser for the useful life of the product, from the date of purchase, that the product will be free from defects in materials and workmanship, provided that it receives normal use, proper care and prescribed dealer service subject to the limitations listed below. - Page 9 This warranty gives you specific legal rights. You may have rights which vary from state to state and country to country. AQUA LUNG DISCLAIMS AND EXCLUDES ANY LIABILITY FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES. SOME STATES IN THE U.S. AND CERTAIN FOREIGN COUNTRIES DO NOT ALLOW EXCLUSIONS OR LIMITATIONS OF LIABILITY FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THIS MAY NOT APPLY TO YOU.
-
Page 10: Basic Setup
Home BASIC SETUP Aqua Lung recommends that you bring your buoyancy compensator, together with your regulator, to your authorized dealer for the installation of the MP inflator hose and other accessories. The retailer can also answer any questions you may have pertaining to the information in this manual. -
Page 11: Attaching The Mp Hose To The First Stage
3. Check to ensure the o-ring is present and in good condition. Screw the threaded end of the hose into the port and tighten to 40 in-lbs (4.5 Nm) with a 9/16” wrench. © 2012 Aqua Lung International... -
Page 12: Threading The Cylinder Band
1. Firmly grasp the metal D-ring with your left hand. While firmly holding the metal D-ring, rotate the back towards the webbing. The buckle should form an angle with the metal D-ring as shown in the top view. © 2012 Aqua Lung International... - Page 13 4 in section: Securing the Band to the Cylinder). Close the buckle half way to prevent the webbing from slipping and thread the free end of the band through the open slot in the end of the buckle. © 2012 Aqua Lung International...
-
Page 14: Securing The Band To The Cylinder
2. Wet the cylinder band and then slide it over the cylinder so that the BC is at the desired position in relation to the cylinder valve. Make sure the cylinder valve air outlet is facing the back of the BC. © 2012 Aqua Lung International... - Page 15 5. Pull the cam buckle closed so tat it lies flat against the cylinder. Secure the end of the cylinder band with the hook & loop attachment. 6. Test the tightness by pushing/pulling the back frame and cradle. © 2012 Aqua Lung International...
-
Page 16: Donning And Adjustment Procedures
Adjusting the shoulder straps too tightly will transfer the cylinder weight from the hips to the shoulders, restricting your arm movement and decreasing comfort. 8. If necessary, readjust the waistband and waist buckle so that they are comfortably snug, but not restricting. © 2012 Aqua Lung International... -
Page 17: Adjusting The Chest Strap
D-rings until the BC fits comfortably. Some BC models also offer vertical adjustment of the chest strap. Become familiar with the adjustment method on your particular model so that you can perform this adjustment in the water if necessary. © 2012 Aqua Lung International... -
Page 18: Weight Integration Features Surelock Ii™ Integrated Weight Release System
Refer to the model-specific label, usually found in the pocket of your BC, to find the designated lift capacity, and load weight pouches accordingly (see photo above). © 2012 Aqua Lung International... - Page 19 Your BC may not be able to float by itself on the surface if your BC is loaded with weight at or near its maximum buoyancy. In water weight of cylinders and other equipment may contribute to negative buoyancy of your full set of SCUBA equipment. Balance BC Weight Capacity Chart Balance BC Size...
- Page 20 Loading Weight into the SureLock II™ Weight Pouches Aqua Lung recommends that each pouch is loaded with equal amounts of weight for optimum balance, preventing the tendency to roll to one side during the dive. Also, it is strongly recommended that each...
- Page 21 Loading Soft Weight into the SureLock II™ Weight Pouches Aqua Lung recommends block weights be used in the SureLock II weight pouch for the best fit and ease of insertion. Soft weights may be used, but it is critical that the weights be loaded and secured correctly.
-
Page 22: Installing The Surelock Ii™ Weight Pouches On Your Bc
INSTALLING THE SURELOCK II™ WEIGHT POUCHES ON YOUR BC CAUTION: Aqua Lung strongly recommends that you do not attempt to don your BC when it is fully loaded with weight. You may otherwise risk injury due to muscle strain or a temporary loss of balance. -
Page 23: Releasing Surelock Ii™ Weight Pouches
To avoid injuring other divers, always look below you before dropping weight. NOTE: In addition to becoming familiar with the weight system yourself, it is very important to explain its function to your dive buddy so that he/she is equally familiar with it. © 2012 Aqua Lung International... -
Page 24: Non-Releasable Weight
(trim) pockets after the BC has been secured to the cylinder. The non-releasable weight pockets are designed to hold single rectangular weight blocks. To avoid accidental loss of weight, Aqua Lung strongly advises against using small bullet-shaped weights and shot weight. -
Page 25: Inflation Methods Using A Powerline Inflator
While continuing to exhale into the mouthpiece, depress the oral inflator button (b) to inflate the BC. Immediately after exhaling, release the oral inflator button to prevent air from escaping. © 2012 Aqua Lung International... -
Page 26: Deflation Via Oral Inflator
Dump Valve at the top of the airway assembly. You can vent air from the BC by firmly pulling straight down on the power inflator. This dump valve provides an effective and convenient way to vent air from the BC while in either an upright or facedown swimming position. © 2012 Aqua Lung International... -
Page 27: Deflation Via Dump Valve / Flat E-Valve / Flat Valve
For example, the lower rear valve works best while making a headfirst descent, or swimming in a facedown position; the right shoulder valve works best when in an upright position. Dump Valve Flat E-Valve Flat Valve © 2012 Aqua Lung International... -
Page 28: Special Features
BC knives available from Aqua Lung. For information on available knife models, consult an Authorized Aqua Lung Dealer or Distributor. To attach or remove the knife and sheath from the BC, refer to the instructions provided with the knife. - Page 29 Home SPECIAL FEATURES - Double Cylinder Setup - Using Aqua Lung Twin Tank Kit The Tank Band Kit for Twin Cylinders (PN 427042) allows mounting of twin cylinders to your BC in sizes ML, L, XL, XXL only. Please see mounting instructions provided with the kit.
-
Page 30: Pre-Dive Inspection For Bc's Using Powerline Inflator
WARNING: If you can hear any leaks, or if the bladder begins to deflate within 5-10 minutes, DO NOT attempt to use the BC until it has received service from an Authorized Aqua Lung Dealer or Distributor. 4. Make a final check of the cylinder band’s tension to ensure that it has not loosened due to stretching. -
Page 31: Post-Dive Care And Maintenance
After rinsing, inflate the BC, and allow it to dry inside and out. Store the BC partially inflated, away from direct sunlight and in a clean, dry area. Do not store the BC in an enclosed space, such as a car trunk, where temperatures may fall below 0ºF (-18ºC) or rise above 120ºF (49ºC). © 2012 Aqua Lung International...
