- Page 1 Anleitung ECS 180 30.10.2001 9:35 Uhr Seite 1 Operating Instructions Electric hand circular saw ECS 180 Art. No.: 43.306.53...
-
Page 2: Table Of Contents
Anleitung ECS 180 30.10.2001 9:35 Uhr Seite 2 Contents Drawing page 3 Description, technical data, Safety instructions page 4 Operating and maintenance instructions page 5-6 Replacement parts drawing page 7 Replacement parts list page 8 Declaration of EC conformity page 9... -
Page 3: Drawing
Anleitung ECS 180 30.10.2001 9:35 Uhr Seite 3 Ear muffs Goggles Dust mask... -
Page 4: Safety Regulations
Anleitung ECS 180 30.10.2001 9:35 Uhr Seite 4 Description Safety regulations 1. Handle Adjust the riving knife so that it is no more than 5 2. Nameplate mm from the tooth rim of the saw blade and its 3. On/Off switch lowest point is not retracted more than 5 mm 4. -
Page 5: Operating And Maintenance Instructions
Anleitung ECS 180 30.10.2001 9:35 Uhr Seite 5 Working with the electric hand circular Before each use, always check that the safety devices - the hinged guard, riving knife, flanges and adjustment devices - are functioning properly and have been adjusted and secured correctly. - Page 6 Anleitung ECS 180 30.10.2001 9:35 Uhr Seite 6 Switching on Important! Pull out the plug before Before pressing the On/Off making any changes to the switch, check that the saw blade circular saw! is properly fitted, that the moving parts run smoothly and that the clamping screws are tight.
-
Page 7: Replacement Parts Drawing
Anleitung ECS 180 30.10.2001 9:35 Uhr Seite 7 Replacement parts drawing Art. No.: 43.306.53 Ident. No.: 91016... -
Page 8: Replacement Parts List
Anleitung ECS 180 30.10.2001 9:35 Uhr Seite 8 Replacement parts list Art. No.: 43.306.53 Ident. No.: 91019 Item Designation RP No. Fixing screw 43.303.00.20 Fixing screw 43.303.00.31 Brush holder 43.303.00.40 Brush cover 43.303.00.42 Switch 43.303.00.04 Spring-loaded support 43.303.00.17 Lock screw 43.303.00.84... -
Page 9: Declaration Of Ec Conformity
Anleitung ECS 180 30.10.2001 9:35 Uhr Seite 9... -
Page 10: Warranty Certificate
Anleitung ECS 180 30.10.2001 9:35 Uhr Seite 10 WARRANTY CERTIFICATE The guarantee period begins on the sales date and is valid for 1 year. Responsibility is assumed for faulty construction or material or functional defects. Any necessary replacement parts and necessary repair work are free of charge.
