3002206/02
OWNER'S GUIDE
C h u r c h i l l L F E
(GC No. 32-032-30)
OUTSET RADIANT/CONVECTOR
LIVING FLAME EFFECT GAS FIRE
(Manufacturer ref. 3413)
THIS APPLIANCE IS FOR USE WITH NATURAL GAS (G20)
THIS APPLIANCE IS FOR USE IN THE UNITED KINGDOM (GB) AND THE
REPUBLIC OF IRELAND (IE) ONLY.
This guide is intended to help you care for your gas fire. Please read thoroughly before
using and keep for future reference
For Service Phone 0845 960 5040
Manufactured exclusively for British Gas & Scottish Gas by Valor Heating, Wood Lane,
Erdington, Birmingham B24 9QP
This guide to be left with the owner
© Valor Heating
Advertisement
Related Manuals for Valor Churchill LFE
Summary of Contents for Valor Churchill LFE
- Page 1 This guide is intended to help you care for your gas fire. Please read thoroughly before using and keep for future reference For Service Phone 0845 960 5040 Manufactured exclusively for British Gas & Scottish Gas by Valor Heating, Wood Lane, Erdington, Birmingham B24 9QP This guide to be left with the owner...
- Page 2 OWNER’S GUIDE Safety First. This fire is CE Approved and designed to meet the appropriate British Standards and Safety Marks. Quality and Excellence This fire has been manufactured to the highest standards of quality and excellence and has been manufactured under a BS EN ISO 9001 quality system accepted by the British Standards Institute.
-
Page 3: Table Of Contents
OWNER’S GUIDE LIST OF CONTENTS SAFETY ..........................4 APPLIANCE DIMENSIONS....................6 OPERATING YOUR FIRE ....................7 CLEANING ........................9 MAINTENANCE ......................11 C U S T O M E R C A R E This gas fire has been designed to meet the most stringent quality, performance and safety requirements to provide our customers with many years’... -
Page 4: Safety
OWNER’S GUIDE SAFETY IF YOU SMELL GAS DON’T SMOKE EXTINGUISH ALL NAKED FLAMES DON’T TURN ELECTRICAL SWITCHES ON OR OFF TURN OFF THE GAS SUPPLY AT THE METER OPEN DOORS AND WINDOWS TO GET RID OF THE GAS IMMEDIATELY CALL THE GAS EMERGENCY SERVICE – SEE YOUR LOCAL TELEPHONE DIRECTORY •... - Page 5 OWNER’S GUIDE • Provide a suitable guard that complies with BS 6539 or 6778 for the protection of young children, the elderly and the infirm. Such a guard is also recommended for the protection of pet animals. (Although this fire conforms to all the applicable standards, it is a heating appliance and certain parts of its surface will become hot.) Note: The glass panel acts as a fireguard conforming to BS1945:1971 and satisfies the Heating Appliance (Fireguard) (Safety) Regulations 1991.
-
Page 6: Appliance Dimensions
OWNER’S GUIDE APPLIANCE DIMENSIONS Figure 1 Dimensions Page 6... -
Page 7: Operating Your Fire
OWNER’S GUIDE OPERATING YOUR FIRE PLEASE NOTE When operating your fire for the first time, some vapours may be given off which may cause a slight odour and could possibly set off any smoke alarms in the immediate vicinity. These vapours are quite normal with new appliances. They are totally harmless and will disappear after a few hours use. - Page 8 OWNER’S GUIDE • The burner settings are; 1/IGN...Centre section on low. Outer sections off. 2....Centre section fully on. Outer sections off. 3....Centre section fully on. Outer sections on low. 4....Centre section fully on. Outer sections fully on. • We recommend that the fire is set at position 4 for the first 10 minutes after lighting to warm up the chimney and so obtain full efficiency quickly.
-
Page 9: Cleaning
OWNER’S GUIDE CLEANING To maintain the high performance and quality finish of your gas fire, please follow these guidelines: • Before attempting to clean the fire, please remember to turn off the fire and wait for the appliance to cool. The fire will retain heat for some time before cleaning can begin. - Page 10 OWNER’S GUIDE 3. After cleaning, replace and secure the window unit to the firebox by turning the two screws turn clockwise with the screwdriver. Refit the window surround by sliding the surround upwards to locate its upper tabs in the slots underneath the outer case hood.
-
Page 11: Maintenance
OWNER’S GUIDE MAINTENANCE Regular maintenance In order to achieve and maintain high levels of personal safety and performance efficiency, it is essential that the opening at the back of the fire and the flue are kept clear of any form of obstruction. It is possible that deposits of mortar or soot could fall and accumulate causing the flue to be blocked or restricted and so preventing proper clearance of dangerous exhaust fumes. - Page 12 OWNER’S GUIDE Owner Replaceable Parts The following owner replaceable parts are available. Please quote the part number when ordering. Description Part No Ceramic coal 3001005 Window unit 3000627 Window surround 3001022 When fitting replacement parts, follow the instructions contained in this guide. It is important that only approved parts are used for maximum safety.
