  • Page 2 RR 250 - 300 2T Thanks for you preference, and have a good time! This hand- book contains the information you need to properly operate and maintain your motorcycle. The data and specifications provided in this manual does not constitute an engagement on the part of BETAMOTOR S.p.A.
  • Page 3 • check that the plastics are properly fastened • engine bolts • shock absorber bolts/swingarm • wheel hubs/spokes • rear frame • pipe connections • tensioning the chain IMPORTANT For any servicing requirements, please get in contact with Beta- motor’s authorized service network.

  • Page 4: Table Of Contents

    Operating instructions ................5. Ecologic guide..................5. Riding safety ..................6 CHAPTER 1 GENERAL INFORMATION ..........7 Vehicle identification data ................ 8 Delivery ....................8 Load ....................10 Tyres ....................10 Steering lock ..................11 Familiarizing with your vehicle ..............12 Controls ....................
  • Page 5 Adjusting the handlebars ................ 5.7 Gas control adjustment ................5.8 Checking and adjusting the steering play ..........5.8 Adjusting the Suspensions: telescopic fork and shock absorber ....5.9 ÷ 61 Tensioning the chain ................61 Idling setting ..................62 Exhaust valve control adjustment .............. 63 CHAPTER 5 REPLACEMENTS ............

  • Page 6: Operating Instructions

    OPERATING INSTRUCTIONS • The vehicle must be accompanied by: number-plate, registration document, tax disc and insurance. • Do not carry animals, pets or loose objects that can stick out from the vehicle. • Riding without a crash helmet is forbidden. •...

  • Page 7: Riding Safety

    RIDING SAFETY • Observe the Highway Code. • Always put on and fasten a homologated helmet. • Always ride with the low beam on. • Always keep the crash helmet visor clean. • Avoid wearing garments with hanging ends. • Do not keep sharp or brittle objects in your pockets while riding. •...

  • Page 8: Chapter 1 General Information

    CONTENTS CHAPTER 1 GENERAL INFORMATION Vehicle identification data Delivery Load Tyres Steering lock Familiarizing with your vehicle Controls Specifications Wiring diagram Electrical devices Euro 3 devices...

  • Page 9: Vehicle Identification Data

    VEHICLE IDENTIFICATION DATA FRAME IDENTIFICATION Frame identification data A are stamped on the right side of the steering head tube. ENGINE IDENTIFICATION Engine identification data B are stamped in the area shown in the figure. WARNING: Tampering with the identification numbers is severely punished by law.
  • Page 10 To take the tool kit, push the button 1 to get off the saddle. Pull back the saddle. Pull the rear side panel 2 to disassemble it. Get off the male end wrenches and hexa- gon socket 3. With these is possible to unscrew the screw 4.

  • Page 11: Load

    LOAD •To avoid to let the vehicle be unstable, do not carry bulky or heavy objects. •Do not carry objects that stick from the vehicle or cover the lighting and signalling devices. TYRES • Only fit tyres approved by BETAMOTOR. Unsuitable tyres can adversely affect the road holding of the vehicle.

  • Page 12: Steering Lock

    Note The type, condition and pressure of the tyres affect the road holding of the vehicle. For this reason it is essential to check them before each journey. •The size of the tyres is shown in the technical specifications and in the vehicle handbook.
  • Page 13 FAMILIARIZING WITH THE VEHICLE Main parts: 1 - Fuel tank 10 - Lower bumper 18 - Fork covers 2 - Tank cap (Bumper kit) 19 - Rear mudguard 3 - Silencer 11 - Saddle 20 - Cover air filter 4 - Rear shock absorber 12 - Engine 13 - Front mudguard 5.

  • Page 14: Controls

    CONTROLS CLUTCH LEVER Clutch lever 1 is fitted to the left-hand side of the handlebars. Screw A can be used to alter the home position of the lever (see Adjustments). FRONT BRAKE LEVER Front brake lever 2 is fitted to the right-hand side of the handlebars.
  • Page 15 STARTER BUTTON Starte button 1 is located on the right-hand side of the handlebars and operate the electri engine starter. Push the button until the engine sterts. Do not press the button 1 while the engine is running. LH SWITCH Dip switch 2 has three positions: A = lights off B = low beam on...
  • Page 16 DIGITAL RPM INDICATOR GENERAL SPECIFICATIONS SPEED/DISTANCE SENSOR: Non-contact magnetic SCREEN MEASUREMENTS: 125.mm x 41mm x 34mm STORAGE TEMPERATURE: -20°C to 80°C (-4°F to 176°F) BATTERY: 3V CR2032 BATTERY LIFE: Approximately one year EXTERNAL CURRENT SUPPLY: 12V DC GENERAL INFORMATION Backlight: The digital speedometer/odometer is backlit to enable reading where there is poor or no lighting.
  • Page 17 SETTING THE PARAMETERS General information: Allowed settings: • Km/h (kilometres per hour) or M/h (Miles per hour) • Wheel size (rolling circumference) [mm] • Clock format: 12-hour / 24-hour • Current date • Maintenance TO ENTER THE PARAMETER SETTINGS MODE HOLD DOWN THE RIGHT AND LEFT BUTTONS FOR APPROX.
  • Page 18 Selecting the unit of measure (Km/h or M/h): TO SELECT THE UNIT OF MEASURE (Km/h or M/h), PRESS THE RIGHT OR LEFT BUTTON. WAIT 5. SECONDS TO PROCEED TO THE NEXT SETTING. DO NOT PRESS ANY BUTTONS. Selecting the wheel size (rolling circumference): The instrument has programmed two rolling circumference measurements for the front wheel: 2190mm (Enduro version - 21”...
  • Page 19 SCREENS Switching between 3 normal modes All of the information that the instrument is capable of providing is displayed on one of these 3 screens. The instrument will stay on the set screen until a button is pressed to switch to another screen.
  • Page 20 SPEEDOMETER Speed The speed is displayed in the centre of screens 1 or 2 and can range from 0 to 399.9 km/h or M/h. The unit of measure (km/h or M/h) appears next to the speed reading. Maximum (Max) and Average (AVG) speed The Maximum (MAX) or Average (AVG) speeds are displayed on screen 3 to the left of the display.
  • Page 21 Travelled distance (DST) The travelled distance can range from 0 to 9999.9 miles or kilometres and appears on the right side of screen1. To clear the travelled distance, hold the right button down for 5. seconds. Note: you must be on screen 1 to clear the travelled distance. Travelled distance 2 (DST 2) Travelled distance 2 can range from 0 to 9999.9 miles or kilometres and appears on the right side of screen 2.

  • Page 22: Specifications

    SPECIFICATIONS Dry weight RR 25.0 - 300 ......104 kg (front 5.0 Kg; rear 5.4 Kg) DIMENSIONS RR 25.0 - 300 maximum length ................2172 mm maximum width ................807 mm overall height ................1270 mm wheelbase .................1482 mm saddle height ................930 mm ground clearance ................320 mm footrest height ................407 mm FRAME ....
  • Page 23 CAPACITIES fuel tank...................8 liter including reserve ................1,3 liter coolant circuit ................1,3 liter gear oil ......... 85.0 ml (10W - 40) - about details see page 36 FRONT SUSPENSION “SACHS” hydraulic upside-down fork (Ø48 mm shafts) spring .................... K 4,2 oil type ..............FUCHS 1091 (SAE 2.5.) oil quantity (from the top, without spring and with fork compressed) ..110 mm wheel excursion ................290 mm REAR SUSPENSION...
  • Page 24 ENGINE Type ............Single-cylinder, 2-stroke, liquid cooled and electric start Bore x stroke RR 25.0 ............66,4 x 72 mm Bore x stroke RR 300 ............... 72 x 72 mm Displacement (cm ) RR 25.0 ............249 cm Displacement (cm ) RR 300 ............293,1 cm Compression ratio RR 25.0 ...............
  • Page 25 Fuel system .............. carburetor without mixer Cooling system ..........forced liquid circulation by pump Spark plug ................NGK BR7 ES Clutch .................. wet, multidisc Transmission ............ 6-speed with front claw clutch RR 25.0 RR 300 Primary drive 28/70 28/70 Gear ratio 1 gear 12/31 12/31...

  • Page 26: Wiring Diagrams Rr 2T

    WIRING DIAGRAM RR 2T...
  • Page 27 WIRING DIAGRAM RR 2t RIGHT-HAND FRONT TURN INDICATOR (12V-10W BULB) FRONT BRAKE LIGHT BUTTON START BUTTON WHEEL REVOLUTION SENSOR TRAFFICATOR LIGHTS TELL TALE LAMP RIGHT BUTTON DISPLAY LEFT BUTTON HEADLIGHT TELL TALE LAMP HEADLIGHT (12V-35./35.W BULB) 12V HORN ENGINE STOP BUTTON HORN BUTTON HEADLIGHT SELECTOR 15.)

  • Page 28: Electrical Devices

    ELECTRICAL DEVICES BATTERY Battery 1 is located under the saddle and requires no maintenance. It is not necessary to check the level of the electrolyte or top up with water. Keep the battery terminals clean and, if necessary, protect them with a small quantity of vaseline technique.

  • Page 29: Ais Valve

    FUSE Fuse 3 is located in starting relay 4 placed under the saddle and front the battery. To gain access to the fuse remove the saddle. The fuse protects the following devices: •electric starter •horn •indicators •instrument panel The starting relay also contains spare fuse 5 (10 amperes).

  • Page 30: Chapter 2 Operation

    CONTENTS CHAPTER 2 OPERATION Checks to be performed before each ride Lubricants Running-in Engine start Refuelling...

  • Page 31: Checks To Be Performed Before Each Ride

    CHECKS TO BE PERFORMED BEFORE EACH RIDE The vehicle can be used only if it is in perfect condition from a technical point of view. To ensure maximum safety, it is advisable to carry out a general inspection of the motorcycle before each ride. The checks to be performed are described below. 1 FUEL Check the level of the fuel in the tank, arrange the breather pipe so that it has no kinks and fit the fuel tank cap.

  • Page 32: Lubricants

    LUBRICANTS To maximize the vehicle’s performance and ensure many years of trouble-free opera- tion, we recommend using the following products: PRODUCT TYPE SPECIFICATIONS OILMIXTURE PANOLIN OFF ROAD 2T RACE 10W/5.0 GEAR AND CLUTCH OIL PANOLIN OFF ROAD 4T SYNTH 10W/40 BRAKE OIL BRAKE FLUID DOT 4 CLUTCH ACTUATOR OIL...
  • Page 33 ENGINE START COLD STARTING 1 Open fuel cock 1. 2 Take the vehicle off the stand. 3 Shift into neutral. 4 Operate choke 2 by pulling it until it stops. 5. WITHOUT opening the throttle, firmly and FULLY operate kickstart 3 or use the electric starter.

  • Page 34: Refuelling

    REFUELLING Use a blend of high-octane unleaded gaso- line and synthetic oil at 1.6% (as related to the oil specifications, see table at page 31) FUEL TANK CAP Open: Turn tank cap 1 anticlockwise. Close: Set the tank lid and crew it clock- wise.

  • Page 36: Chapter 3 Checks And Maintenance

    CONTENTS CHAPTER 3 CHECKS AND MAINTENANCE Changing the gear and clutch oil Check the level of the front and rear brake fluid and bleeding Check the front and rear brake pads Check the oil level in the hydraulic clutch and bleeding Fork oil Air filter Spark plug...

  • Page 37: Changing The Gear And Clutch Oil

    CHANGING THE GEAR AND CLUTCH Before performing this operation, remove the lower bumper 1 after unscrewing the two screws 2 as shown in the picture. The oil must be changed when the engine is at operating temperature. Park the motorbike on a flat surface, re- move the drain plug 3 and collect the oil in a vessel.
  • Page 38 CHECK THE LEVEL OF THE FRONT BRAKE FLUID Check the level of the brake fluid through sight A. The level of the fluid should never fall below the mark in the sight. RESTORING THE LEVEL OF THE FRONT BRAKE FLUID To restore the level of the brake fluid, loosen the two screws 1, lift cap 2 and add brake fluid (BARDAHL BRAKE FLUID DOT 4) until...
  • Page 39 CHECK THE LEVEL OF THE REAR BRAKE FLUID Check the level of the brake fluid through sight D. The level of the fluid should never fall below the mark in the sight. RESTORING THE LEVEL OF THE REAR BRAKE FLUID To restore the level of the brake fluid, unscrew cap 3 and pour in brake fluid (BARDAHL BRAKE FLUID DOT 4) until the...
  • Page 40 FRONT BRAKE LINING CONTROL In order to verify the wear condition of front brake is enough to view the plincer from the bottom, where is possible to glimpse the brake lining tails which will have to show a brake of 2 mm in thickness. If the stratum is lesser let’s start replacing them.
  • Page 41 HYDRAULIC CLUTCH OIL LEVEL CHECK To check the oil level in the clutch pump, first remove cover 2. Remove the two screws 1 and take off cover 2 together with the rubber bellows. With the clutch pump in a horizontal posi- tion, the level of the oil should be 5.

  • Page 42: Fork Oil

    FORK OIL Right/left-hand rod The procedure for changing the oil in the forks is provided only for information. We recommend having the operation performed by a BETAMOTOR authorized workshop. • Rest the motor on a central stand, lift it making sure that it is stable. • Remove the cable gland U-bolt A • Remove the screws B that fix the brake caliper to the left leg and remove the...
  • Page 43 • Loosen the counter-nut 2 and remove cap 1. • Extract the spring 3 and overturn the pipe, making the oil escape. • Move the pumping unit and drain the remaining oil. When the oil has been drained com- pletely, introduce the amount of new oil described in chapter 1 page 22.
  • Page 44 • Tighten the cap to the completely exten- ded leg. • Insert the legs into the plates. Once the leg has been positioned at the desired extension, tighten screws E at 17Nm and F at 12Nm, after the screws have been greased.

  • Page 45: Air Filter

    AIR FILTER A dirty air filter hinders the passage of air, reduces engine power and increases fuel consumption. For these reasons it is essen- tial to clean the air filter on a regular basis. Follow these steps to gain access to the air filter.

  • Page 46: Spark Plug

    SPARK PLUG To accede to spark plug, is necessary to take off saddle and the fuel tank. To remove the fuel tank proceed as follows. Unscrew the two screws 1, unscrew the screw 2 (both side). Close the fuel tap (OFF position) and disconnect the pipe fuel 3 from the fuel tap.
  • Page 47 To perform the check, just extract the spark plug cap and unscrew the spark plug by means of the provided wrench. Carefully clean the electrodes using a 0,5 0,6 wire brush. Blow the spark plug with com- pressed air to prevent any residues from getting into the engine.

  • Page 48: Carburetor

    CARBURETTOR The throttle valve, the needle valve and the needle jet are subject to heavy wear due to engine vibrations. As a result, wrong functioning may manifest. DRAINING THE CARBURETTOR FLOAT CHAMBER If the carburetor tank needs to be emptied, proceed as described.

  • Page 49: Coolant

    CHECKING THE FLOAT LEVEL 60° Remove the carburettor and the float cham- ber. Keep the carburetor on a 60° approx. incline, so that float leans on the needle valve without pressing it. In this position the float edge should be parallel with the float chamber sealing surface (see figure).
  • Page 50 DRIVE CHAIN MAINTENANCE The life of the drive chain largely depends on its maintenance. Chains without X- rings must be periodically cleaned in petroleum and then immersed in hot chain oil or treated with a chain spray. X-ring chains require very little maintenance. The best way to clean them is rinsing them generously with water.
  • Page 51 CHARGING THE BATTERY Remove the battery and check its charge. Using an open-circuit multimeter (10-12 hours after the activation), check that the voltage is greater than 12.6 V. If it is lower, it is advisable to recharge the battery. Based on the type of charger available, charge the battery using either of the fol- lowing procedures: •...
  • Page 52 CLEANING AND CHECKING THE VEHICLE Use water jet to soften the dirt and mud accumulated on the paintwork, then remove them with a soft bodywork sponge soaked in water and shampoo (2-4 percent shampoo in water). Subsequently rinse well with water, and dry with air and cloth or suede leather.

  • Page 53: Scheduled Maintenance Vehicle

    SCHEDULED MAINTENANCE VEHICLE Every 30h Every 60h After 1°coupon Every 15h UNIT INTERVENTION or 300l every after 3h or 15l or 75l or 150l (fuel) (fuel) exit (fuel) (fuel) Gear and clutch oil Spark plug Engine clamping screws* ENGINE Kick start and gearchange lever screws Spark plug cap Tightness Lamellar pack...
  • Page 54 SCHEDULED MAINTENANCE ENGINE The required engine maintenance is strongly depending on the level of use and on the accordingly done periodic checks and service. The below mentioned maintenance intervals are for standard competition use, subject to the condition that the engine was never running under extraordinary conditions and the periodic service was done accurately.
  • Page 55 PROLONGED INACTIVITY A few simple operations should be performed to keep the vehicle in good condition whenever it is to remain inactive for a long period (e.g. during the winter): • Thoroughly clean the vehicle. • Reduce the tyre pressures by approximately 30 percent, and if possible raise the tyres off the ground.
  • Page 57 CONTENTS CHAPTER 4 ADJUSTMENTS Brake adjustment: front lever and brake pedal Adjusting the home position of the clutch lever Adjusting the handlebars Gas control adjustment Checking and adjusting the steering play Adjusting the Suspensions: telescopic fork and shock absorber Tensioning the chain Idling setting Exhaust valve control adjustment...
  • Page 58 ADJUSTING THE HOME POSITION OF THE FRONT BRAKE LEVER The home position of brake lever 2 can be adjusted by means of screw 1. ADJUSTING THE HOME POSITION OF THE BRAKE PEDAL The home position of brake pedal 1 can be altered by turning adjusting screw 2 af- ter loosening the counternut located under dust cap 3.
  • Page 59 GAS CONTROL ADJUSTMENT The throttle control cable should always have a 3-5. mm play. In addition, the idle speed should not change when the handle- bars are fully rotated to the left or right. Push back protective cap 1. Loosen counternut 2 and turn adjusting screw 3.
  • Page 60 SUSPENSIONS TELESCOPIC FORK ADJUSTING THE REBOUND DAMPER The hydraulic rebound damper determines the behaviour of the telescopic fork during extension and can be adjusted by means of screw A. Turning the screw clockwise (towards the + sign) increases the action of the rebound damper;...
  • Page 61 SHOCK ABSORBER ADJUSTING THE HYDRAULIC COMPRES- SION DAMPER (high and low speeds) The shock absorber can be adjusted for both high and low speeds. The terms ‘high’ and ‘low’ refer to the compression speed of the shock absorber, not to the speed of the vehicle.

  • Page 62: Tensioning The Chain

    ADJUSTING THE HYDRAULIC REBOUND DAMPER Turn screw G to adjust the hydraulic re- o adjust the hydraulic re- bound damper. Turning the screw anticlockwise (out) de- creases the damping effect. Standard adjustment RR 2t: clicks from the completely closed position TENSIONING THE CHAIN To ensure the drive chain a longer life, it is advisable to periodically check its tension.
  • Page 63 ADJUSTING THE IDLE SPEED Idling adjustment greatly affects the ap- propriate start-up and the accelerator response. Idling is adjusted through adjustment screw 1 and air adjustment screw 2. Adjustment screw 1 adjusts the basis position of the gas valve. Turn the screw clockwise to increase the rotation conditions and counterclockwise to diminish it.

  • Page 64: Exhaust Valve Control Adjustment

    Regolazione comando valvola scarico  ATTENZIONE! Il veicolo è dotato di valv EXHAUST VALVE CONTROL ADJUSTMENT messa  a  punto  viene  fatta  in  sede  di  motore.Non  modificare  per  nessun  m ATTENTION! The vehicle is provided with an exhaust valve whose fine tuning della vite di registro 1.  is performed during the final try-out of the engine.

  • Page 65: Chapter 5 Replacements

    CONTENTS CHAPTER 5 REPLACEMENTS Replacing the brake pads: front and rear Replacing the headlight bulbs Replacing the rear optic batch...
  • Page 66 REPLACING THE BRAKE PADS The procedure for replacing the brake pads is provided only for information. We recommend having the operation performed by a BETAMOTOR authorized workshop. FRONT Follow these steps to replace the pads: •Push the brake caliper towards the disc so that the pistons reach their home positions.
  • Page 67 REAR Follow these steps to replace the pads: •Push the brake caliper towards the disc so that the pistons reach their home positions. •Unscrew dowel A. •Pull out pin B, while supporting the two pads as shown in the figure. •Remove the brake pads taking care not to drop the leaf spring located above the two pads.

  • Page 68: Replacing The Headlight Bulbs

    REPLACING THE HEADLIGHT BULBS Release both spring washers and move forward the lamp holder front cowl. Carefully remove the headlight bulb 1 together with lamp holder. To replace the high beam / low beam, lift the rubber cover 2, release connector, push on the spring 3 and remove the lamp holder and replace the light bulb with a new one.
  • Page 69 Unscrew the two E screws and the four F screws. Take off the rear fender. Disconnect he connector A and unthread the cable. To reassebly the optical batch, insert before the connector in the hole B, and then put the cable as it shown in the picture.

  • Page 71: Chapter 6 Troubleshooting

    CONTENTS CHARTER 6 TROUBLESHOOTING INDEX...
  • Page 72 - Air filter dirty Check the air filter - No current supplied to spark plug Clean or replace the spark plug. If the problem persists, contact a BETA- MOTOR dealer - Engine flooded Operate the start-up pedal 5.-10 times or the electrical starter pushbutton 2 times every 5.

  • Page 73: Replacing The Brake Pads: Front And Rear

    Air filter ....................44 Battery: load ..................5.0 Bleeding clutch ..................40 Bleeding the brakes: front and rear ............37 Brakes adjustment: front and rear ............. 5.7 Carburetor ..................47 Checking and adjusting the steering play ..........5.8 Checks to be performed before each ride ..........30 Cleaning and checking the vehicle ............
  • Page 74 Steering lock ..................11 Suspensions: telescopic fork and shock absorber ........ 5.9 ÷ 61 Tensioning the chain ................61 Troubleshooting ..................71 Tyres ....................10 Vehicle identification data ................ 8 Vehicle: familiarizing with............... 12 Vehicle: prolonged inactivity ..............5.4 Wiring diagram RR 2t ................25.
