Rockwell Automation 6181P Installation Instructions Manual
Integrated display computers
Hide thumbs
Also See for 6181P:
- User manual (124 pages) ,
- Migration manual (12 pages) ,
- User manual (124 pages)
Table of Contents
Advertisement
Quick Links
Download this manual
See also:
User Manual
Integrated Display Computers
Catalog Numbers 6181P, 6181F
Topic
About This Publication
This publication provides procedures on how to install the integrated display
computers. It also describes how to make peripheral, power, and network
connections. For information on operating and troubleshooting, refer to the user
manual listed under Additional Resources.
Installation Instructions
Page
1
2
3
4
5
5
6
7
13
14
15
16
16
17
20
Advertisement
Table of Contents
Related Manuals for Rockwell Automation 6181P
Summary of Contents for Rockwell Automation 6181P
-
Page 1: Table Of Contents
Installation Instructions Integrated Display Computers Catalog Numbers 6181P, 6181F Topic Page About This Publication Important User Information Environment and Enclosure Information European Union Directive Compliance Multilingual User Interface CD Pack Operating Systems Before You Begin Install the Computer Connect the Keyboard and Mouse... -
Page 2: Important User Information
In no event will Rockwell Automation, Inc. be responsible or liable for indirect or consequential damages resulting from the use or application of this equipment. -
Page 3: Environment And Enclosure Information
• Industrial Automation Wiring and Grounding Guidelines, Allen-Bradley publication 1770-4.1, for additional installation requirements. • NEMA Standards publication 250 and IEC publication 60529, as applicable, for explanations of the degrees of protection provided by different types of enclosure. Publication 6181P-IN001I-EN-P - July 2008... -
Page 4: European Union Directive Compliance
This product meets the European Union Directive requirements when installed within the European Union or EEA regions and has the CE mark. A copy of the Declaration of Conformity is available at the Rockwell Automation / Allen-Bradley website: www.ab.com/certification This product is intended to operate in an industrial or control room environment, ATTENTION which utilizes some form of power isolation from the public low voltage mains. -
Page 5: Multilingual User Interface Cd Pack
MUI packs are available for all Windows XP operating systems and provide a localized start menu and system icons support. The instructions for installing MUI languages on your computer are supplied with the MUI CD Pack. Publication 6181P-IN001I-EN-P - July 2008... -
Page 6: Before You Begin
• Mounting clips, except for the 1200P Non-display computer • AC power cord, when appropriate • PS/2 Y-adapter cable for keyboard and mouse connection (supplied with all 6181P Series A and 6181H 1500P Series B computers) • Installation guide and cutout template Installation Guidelines Follow these guidelines to make sure your product provides safe and reliable service. -
Page 7: Install The Computer
Review each mounting type and product dimensions before installation. Panel Mounting Before installing the computer in a panel, review the following information. • Required tools • Panel mounting guidelines • Panel cutout dimensions • Product dimensions Publication 6181P-IN001I-EN-P - July 2008... - Page 8 Remove all electrical power from the panel before making cutout. ATTENTION Make sure the area around the panel cutout is clear. Failure to follow these warnings may result in personal injury or damage to the panel components. Publication 6181P-IN001I-EN-P - July 2008...
- Page 9 The sequence begins with the center clips and continues to the corner clips. Repeat this process at least three times until the clips are hand-tight and the gasket is compressed uniformly against the panel. Torque Sequence Publication 6181P-IN001I-EN-P - July 2008...
- Page 10 Tighten the mounting clips to the specified torque to provide a proper seal and ATTENTION prevent damage to the product. Rockwell Automation assumes no responsibility for water or chemical damage to the product or other equipment within the enclosure because of improper installation.
-
Page 11: Product Dimensions
Product dimensions for each computer model are given in mm (in). 1200P Integrated Display Computer 320 [12.60] 281 [11.079] 349 [13.75] 175.9 [6.93] 8.00 [0.31] 1200P Non-display Computer 281 [11.079] 343 [13.51] 144.9 [5.70] 317.5 [12.51] 2 (.078) Publication 6181P-IN001I-EN-P - July 2008... - Page 12 Integrated Display Computers 1500P Integrated Display Computer 383.60 [15.10] 13.20 [0.52] 8.00 [0.31] 99.9 [3.93] 410.00 [16.14] 1700P Integrated Display Computer 422.00 14.00 [0.52] 8.00 [0.31] 101.6 [4.00] 452.00 [17.80] Publication 6181P-IN001I-EN-P - July 2008...
-
Page 13: Connect The Keyboard And Mouse
1500P - Series A 1500P - 6181H Series A and B 1700P - Series A The 6181P Series B and later computers have separate PS/2 ports for the keyboard and mouse. 1200P - Series B and C 1500P - Series B and C... -
Page 14: Connect Ac Power
The computer circuit should have its own disconnect. Use an Uninterruptible Power Source (UPS) to protect against unexpected power failure or power surges. Always shut down the operating system before removing power to minimize performance degradation and operating system failures. Publication 6181P-IN001I-EN-P - July 2008... -
Page 15: Connect Dc Power
GND (Safety Ground Alternate Connection) V+ (DC Positive) Connect the product to earth ground using a 1.31 mm (16 AWG) or larger external wire. ATTENTION The ground wire should have green insulation with a yellow stripe for easy identification. Publication 6181P-IN001I-EN-P - July 2008... -
Page 16: Replace The Battery
Proper cable routing and power conditioning is required to ensure reliable Ethernet communication in industrial environments. Rockwell Automation recommends that you route all Ethernet cabling through dedicated metal conduits. Installing ferrite bead filters at the cable ends may also improve reliability. -
Page 17: Ship Or Transport The Product
Doing so may cause damage to the product. You must uninstall the product and place in its original packing material before shipping. Rockwell Automation is not responsible for damage incurred to a product that is shipped or transported while installed in a machine, panel or rack. -
Page 18: Specifications
140 VA (1.4 A @ 100 V rms, 0.58 A @ 240 V rms) Input voltage, DC 18…32 V dc 1200P and 1200P (6181P-2X Non-display) Power consumption, DC 150 W 1200P 140 W 1200P (6181P-2X Non-display) Applies to 6181P computers with rotating media only. Publication 6181P-IN001I-EN-P - July 2008... -
Page 19: Mechanical Specifications
NEMA Type 4X for stainless steel units only Applies to panel-mounted products only. The floppy drive and optical disc drive are considered maintenance devices. You should not operate computers with these devices in environments with the shock and vibration levels listed. Publication 6181P-IN001I-EN-P - July 2008... -
Page 20: Additional Resources
Allen-Bradley and Rockwell Automation are trademarks of Rockwell Automation, Inc. Trademarks not belonging to Rockwell Automation are property of their respective companies. Publication 6181P-IN001I-EN-P - July 2008 PN-29060 Supersedes Publication 6181P-IN001H-EN-P - July 2007 Copyright © 2008 Rockwell Automation, Inc. All rights reserved. Printed in the U.S.A.
