Tripod Mode; Forward And Downward Vision System - dji Mavic pro User Manual

Mavic Pro User Manual

Tripod Mode

Tap the icon in the DJI GO app to enable Tripod Mode. In Tripod Mode, the maximum flight speed is
limited to 2.2 mph (3.6 kph) and the braking distance is reduced to 3.2 ft (1 m). Responsiveness to stick
movements is also reduced for smoother more controlled movements.
Only use Tripod Mode where the GPS signal is strong or light conditions are ideal for the vision
system. If GPS signal is lost and if the vision system cannot function, it will automatically switch
to Atti mode. In this case, flight speed will increase and the aircraft cannot hover in place. Use
Tripod Mode carefully.

Forward and Downward Vision System

The Mavic Pro is equipped with a Forward and Downward Vision System that constantly scans for
obstacles in front of it, allowing it to avoid collisions by going around, over or hovering. The down-
ward Vision System uses ultrasound and image data to help the aircraft maintain its current position.
With the help of the Downward Vision System, your Mavic Pro can hover in place more precisely
and fly indoors or in other environments where a GPS signal is not available. The main components
of the Forward and Downward Vision System are located on the nose and the bottom of the aircraft;
they include [1] [2] four monocular sensors and [3] two ultrasonic sensors.
Detection Range
The detection range of the Forward and Downward Vision System is depicted as follow. Note that the
aircraft cannot sense or avoid the obstacles that are not within the detection range.
22
©
2016 DJI All Rights Reserved.
