Gesture Mode - dji Mavic pro User Manual

You must follow local privacy laws and regulations when using ActiveTrack.
Aircraft will not be able to avoid obstacles while in Profile or Spotlight Mode. Use these
modes in open areas.
The aircraft will sense and avoid obstacles on its flight path.
If the aircraft loses track of the subject, because it is moving too fast or obscured, re-select
the subject to resume tracking.
Exiting ActiveTrack
Use the following methods to exit ActiveTrack:
1. Press the Flight Pause button on the remote controller.
2. Tap the "STOP" button on the screen.
After exiting ActiveTrack, the aircraft will hover in place, at which point you may choose to fly manually,
track another subject, or return to home.

Gesture Mode

In Gesture Mode, the Mavic's Vision System recognizes gestures, allowing it to follow and capture selfies
without a phone or a controller. Follow the steps below to use Gesture Mode:
Modes Prompts
1.
Confirm the
subject
2. Confirm the
distance
3. Selfie Count
Down
Gesture Mode can only be used in Photo Mode.
Fly the aircraft 2 meters or higher above the ground then move in front of the camera to be
recognized. Front LED Indicators will blink red rapidly if the Mavic Pro fails to recognize a subject.
Enabling GPS on your phone will allow the Mavic to follow with more accuracy while flying in
Gesture Mode.
Front LEDs Remarks
Ensure the forward vision system is active
and there is enough light. Tap the icon and
Slow Red Flashing move in front of the camera for the Mavic to
recognize you.
Raise your arms and wave to the Mavic,
×2
the Front LED will blink red twice once it
Red Flashes Twice
confirms the shooting distance.
Put your fingers in front on your face as
Fast Red Flashing shown.
Mavic Pro User Manual
STOP
OR
©
2016 DJI All Rights Reserved.
21
