- Page 1 Installation & Operation Manual LCDP-9084-301-x 8.4" LCD Monitor with the 9G Plug-in Arm Document # 540344 7300 Industry Drive, North Little Rock, AR 72117 Phone: 501-955-2929 Fax: 501-955-2988 www.decraneaerospace.com...
-
Page 2: Reference Documents
DeCrane Aerospace Audio International. Neither this document nor the data contained herein shall be reproduced, used, or disclosed to anyone without the written authorization of DeCrane Aerospace Audio International. Document # 540344, Rev A1, 02/2009... -
Page 3: Table Of Contents
DeCrane Aerospace Audio International, Inc. LCDP-9084-301-x Installation Manual Table of Contents Section Description Page General Information ……………………………………………. Introduction ……………………………………………………….. Purpose of the Equipment ………………………………………. Optional Equipment ……………. .………………………………. Application ……………………………………………………….. Introduction………………………………………………………… Typical Application……………………………………………….. Typical Interfaces…………………………………………………. 9G Plug-In Arm Mobility………………………………………….. Installation ……………………………………………………….. -
Page 4: General Information
This manual contains information for the proper installation of the DeCrane Aerospace Audio International (DAAI) 8.4" LCD Monitor with the 9G Plug-In Arm, Model No: LCDP-9084-301-x. The “-x” suffix designates the type of video utilized; “-1” = Composite analog video and “-2” = Serial Digital Interface (SDI) video. -
Page 5: Application
LCDP-9084-301-x Installation Manual Application Introduction The LCDP-9084-301-x is an 8.4" flat panel LCD monitor containing a Liquid Crystal Display (LCD) screen. The -1 unit is capable of displaying composite (NTSC, PAL, SECAM) video, while the -2 unit is capable of displaying SMPTE 259M SDI (NTSC, PAL) video. -
Page 6: Plug-In Arm Mobility
DeCrane Aerospace Audio International, Inc. LCDP-9084-301-x Installation Manual 9G Plug-In Arm Mobility The 9G Plug-In Arm affords the LCDP-9084-301-x a wide range of mobility (see drawings below). Depression of the Release Button halfway through the button’s travel releases the pivot lock and allows the horizontal support to move from either 0°... -
Page 7: Installation
• Environmental conditions (temperature, humidity, etc.) • Length of cable runs 3.1.2 The LCDP-9084-301-x shall be installed to conform to the standards designated by the customer, installing agency, and existing conditions as to the unit location and type of installation. -
Page 8: Cautions & Warnings
DeCrane Aerospace Audio International, Inc. LCDP-9084-301-x Installation Manual Cautions and Warnings 3.3.1 It is important to do a pin-to-pin power and ground check on all connectors. Ensure that power and ground are applied only where specified. Damage to the unit may result if power or ground is applied to the wrong points. -
Page 9: Electrical Characteristics
DeCrane Aerospace Audio International, Inc. LCDP-9084-301-x Installation Manual 3.4.3 Video Lines All single signal connections are shall be in accordance with NEMA WC 27500. SD-SDI video connections are recommended to use shielded coaxial cable PIC V72261. Electrical Characteristics: Electrical Nominal Power... -
Page 10: Mating Connector Information
DeCrane Aerospace Audio International, Inc. LCDP-9084-301-x Installation Manual Mating Connector Information 3.6.1 LCDP-9084-301-x All wiring harnesses to the unit shall be supplied and fabricated by the installing agency. Refer to Sections 8.2 and 8.3, for differing measurements and hole placements between the “-101-x” and “102-x”... -
Page 11: Operation
DeCrane Aerospace Audio International, Inc. LCDP-9084-301-x Installation Manual Operation Controls Control Functions: UP BUTTON Push to enter Menu Mode. UP BUTTON is used to navigate menu while Menu Mode is active. Push and hold to turn off Menu Mode. DOWN BUTTON DOWN BUTTON is used to navigate menu while Menu Mode is active. -
Page 12: Instructions For Continued Airworthiness
STATUS LED lights up green when power is activated. Instructions for Continued Airworthiness No periodic scheduled maintenance or calibration is required for continued airworthiness of the LCDP-9084-301-x. If the unit fails to perform to specifications, it must be removed and serviced by a qualified service facility. Troubleshooting... -
Page 13: General Troubleshooting Procedures
DeCrane Aerospace Audio International, Inc. LCDP-9084-301-x Installation Manual B. Open pre-moistened pad and gently wipe evenly across display glass. Do not allow solution to “pool” or puddle around display edges. C. Immediately dry display using the absorbent, lint-free cloth. Gently wipe display to a dry, clear finish. -
Page 14: Reference Drawings
DeCrane Aerospace Audio International, Inc. LCDP-9084-301-x Installation Manual Reference Drawings LCDP-9084-301-x The following diagrams show the unit dimensions, mounting locations, and connector locations for the monitor. All dimensions are given with tolerance of 0.03" (0.08 cm). Note: This product has the ability to meet or exceed all of the industry’s expectations and... - Page 15 DeCrane Aerospace Audio International, Inc. LCDP-9084-301-x Installation Manual Note: Torque fasteners allow arm movement with minimum resistance while allowing arm to remain in desired position. Document # 540344, Rev A1, 02/2009 Page 14 of 16...
- Page 16 DeCrane Aerospace Audio International, Inc. LCDP-9084-301-x Installation Manual BASE-9101-101-x The following diagrams show the unit dimensions, for the Plug-in Monitor Base. Note: The harness is not shown in this view for clarity. Document # 540344, Rev A1, 02/2009 Page 15 of 16...
- Page 17 DeCrane Aerospace Audio International, Inc. LCDP-9084-301-x Installation Manual BASE-9101-102-x The following diagrams show the unit dimensions, for the Plug-in Monitor Base. Note: The harness is not shown in this view for clarity. Document # 540344, Rev A1, 02/2009 Page 16 of 16...
