- Page 1 Installation & Operation Manual TSC-9104-101-x 10.4" Integrated Touch Screen/LCD Monitor Document # 540364 7300 Industry Drive, North Little Rock, AR 72117 Phone: 501-955-2929 Fax: 501-955-2988 www.decraneaerospace.com...
-
Page 2: Reference Documents
DeCrane Aerospace Audio International TSC-9104-101-x Installation & Operation Manual Document Revision History Rev. Level Date Description 02/2008 Initial Release Reference Documents (or latest revision) Document # Description 526122 Rev IR TSC-9104-101-x Outline Drawing Service Bulletin List Service Manual Revision Subject... -
Page 3: Table Of Contents
DeCrane Aerospace Audio International TSC-9104-101-x Installation & Operation Manual Table of Contents Section Description Page General Information ...... -
Page 4: General Information
Integrated Touch Screen/LCD Monitor is capable of displaying full color graphics and video at a vertical resolution of 768 pixels and a horizontal resolution of 1024 pixels (XGA). The TSC-9104-101-x is also capable of interfacing to an SDI video signal. In addition, a graphics overlay will be displayed on the TSC-9104-101-x Integrated Touch Screen/LCD Monitor with the ability to blend the video and graphics. -
Page 5: Optional Equipment
Aerospace Audio International representative for details. Application Introduction The TSC-9104-101-x Integrated Touch Screen/LCD Monitors are used to control other modules and components on DeCrane Aerospace Audio International’s proprietary RS-485 serial data bus through graphic images displayed on the monitor. Pressing these images sends commands out over the RS-485 serial data bus to other modules in order to control volume, audio selections, etc. -
Page 6: Installation
TSC-9104-101-x Installation & Operation Manual Installation Prior to Installation The TSC-9104-101-x is a simple module to install. Prior to installation the following items should be considered: 3.1.1 During the design and layout of the aircraft cabin, careful consideration of the location of this and all other video modules is necessary. -
Page 7: Cautions & Warnings
DeCrane Aerospace Audio International TSC-9104-101-x Installation & Operation Manual DeCrane Aerospace Audio International by contacting the Repair Department at 501.801.8101. Repackage the unit in its original packaging materials and return it to DeCrane Aerospace Audio International following instructions given DeCrane Aerospace Audio International representative. -
Page 8: Wiring Requirements
3.4.4 DeCrane Aerospace Audio International’s Proprietary RS-485 Data Bus The TSC-9104-101-x is designed to interface with other DeCrane Aerospace Audio International equipment via DeCrane Aerospace Audio International’s proprietary RS-485 serial data bus. The data bus shall be implemented using a twisted shielded pair cable in accordance with NEMA WC 27500. -
Page 9: Physical Characteristics
3.5.5 When mounting the unit to the aircraft’s frame, allow sufficient space for mating connectors. 3.5.6 The TSC-9104-101-x utilizes four (4) 8-32 UNF-2B two (2) each side, maximum depth .25 inches. 3.5.7 This unit is capable of installation/mounting in any orientation whether horizontal, vertical, inverted, or at an angle. -
Page 10: Electrical Characteristics
Data Communication Interfaces RS-485 Serial Data Bus 3.7.1 All RS-485 serial data bus electronic interface parameters are compliant to DeCrane Aerospace Audio International document #640071. 3.7.2 This unit is capable of maintaining full normal operation during power interruptions not greater than 200 msec. -
Page 11: Pinout Assignments And Descriptions
DeCrane Aerospace Audio International TSC-9104-101-x Installation & Operation Manual J3 CONNECTOR Model Number Mating Connector TSC-9104-101-x Type A 4 PIN Universal Serial Bus (UBS) connector J4 CONNECTOR Model Number Mating Connector TSC-9104-101-x Type OTG 5 PIN Universal Serial Bus (USB) connector... -
Page 12: 3.10 Post-Installation Test
COM CTS Reserved 3.10 Post-Installation Test 3.10.1 With the aircraft power ON, operate the TSC-9104-101-x Integrated Touch Screen/LCD Monitor, to verify that the display appears on the monitor. 3.10.2 Verify, by manipulating all selections of the menu system, that the Integrated Touch Screen/LCD Monitor controls are operational. -
Page 13: Instructions For Continued Airworthiness
Instructions for Continued Airworthiness Airworthiness Limitations No periodic scheduled maintenance or calibration is required for continued airworthiness of the TSC-9104-101-x. If the unit fails to perform to specifications, it must be removed and serviced by a qualified service facility. Cleaning Method The TSC-9104-101-x should be cleaned when excessive dust or dirt becomes apparent. -
Page 14: General Troubleshooting Procedures
DeCrane Aerospace Audio International TSC-9104-101-x Installation & Operation Manual General Troubleshooting Procedures • To verify power to the unit, recheck +28 VDC power is applied to the proper pins on the unit. Use a voltmeter to verify correct level. • Reset by removing power from the unit for at least one (1) minute and reapply power. -
Page 15: Reference Drawings
DeCrane Aerospace Audio International TSC-9104-101-x Installation & Operation Manual Reference Drawings The following diagrams show the unit dimensions, mounting locations, and connector locations for the TSC-9104-101-x. TSC-9104-101-x Connector Configuration Document # 540364, Rev IR, 02/2008 Page 14 of 15... - Page 16 DeCrane Aerospace Audio International TSC-9104-101-x Installation & Operation Manual Document # 540364, Rev IR, 02/2008 Page 15 of 15...
