- Page 1 Installation Manual LCDW-9230-101-x 23" Widescreen LCD Monitor Document # 540362 7300 Industry Drive, North Little Rock, AR 72117 Phone: 501-955-2929 Fax: 501-955-2988 www.decraneaerospace.com...
-
Page 2: Reference Documents
DeCrane Aerospace Audio International. Neither this document nor the data contained herein shall be reproduced, used, or disclosed to anyone without the written authorization of DeCrane Aerospace Audio International. Document # 540362, Rev A, 11/2008... -
Page 3: Table Of Contents
Specifications ........Unit Specifications-LCDW-9230-101-x .... -
Page 4: General Information
This manual contains information for the proper installation of the DeCrane Aerospace Audio International 23" Widescreen LCD Monitor, Model No: LCDW-9230-101-x. The “-x” suffix designates the type of connector utilized; “-1” = Positronic and “-2” = D-Subminiature. Also included are physical and electrical characteristics of the unit. -
Page 5: Application
DeCrane Aerospace Audio International representative for details. Application Introduction The LCDW-9230-101-x is a widescreen LCD monitor with Composite Video, PC Graphic capabilities, and Serial Digital Interface capabilities. If any one of these formats is applied to their respective inputs, the monitor will display that format. -
Page 6: Installation
• Environmental conditions (temperature, humidity, etc.) • Length of cable runs 3.1.2 The LCDW-9230-101-x shall be installed to conform to the standards designated by the customer, installing agency, and existing conditions as to the unit location and type of installation. -
Page 7: Unpacking And Inspection
Refer to Section 6.0 for unit dimensions. 3.1.9 The LCDW-9230-101-x is configured using the external menu selection switch, SP-LCD6. The switch utilizes a D-Subminiature connector. This connector mates with the D-Subminiature connector on the LCDW-9230-101-x model monitor. -
Page 8: Cautions & Warnings
LCDW-9230-101-x Installation Manual a Return Request Authorization Number shall be obtained from DeCrane Aerospace Audio International by contacting the Repair Department at 501.801.8101. Repackage the unit in its original packaging materials and return it to DeCrane Aerospace Audio International following instructions... - Page 9 LCDW-9230-101-x. Serial Digital Video connections are recommended to use shielded coaxial cable in accordance with PIC V76261 or equivalent.
-
Page 10: Electrical Characteristics
Green Mounting Studs 6-32 x 0.75 inches long 3.5.3 The LCDW-9230-101-x utilizes three (3) connectors. J1 is a 13-pin connector that provides power input, ground, video input, monitor on/off control and monitor status. The monitor on/off function (J1, Pin 5) is transition level sensitive. -
Page 11: Mating Connector Information
Three (3) ID pins are also provided on the J2 connector. These ID pins allow for up to eight (8) units to be connected on the same DeCrane Aerospace Audio International proprietary RS-485 data bus while maintaining independent control of each unit. -
Page 12: Pinout Assignment Descriptions
LCDW-9230-101-1 (Positronic Industries) DAMA15PK87 Male Plug w/ male jackscrews or equivalent LCDW-9230-101-2 (ITT Cannon) Pinout Assignment Descriptions 3.7.1 Pinout assignment for the LCDW-9230-101-x is as follows: Pin # Description +28VDC Power Input Ground Reserved Monitor Status Gnd Output Monitor On/Off Gnd Input... -
Page 13: Sp-Lcd6 Configuration Overview
To access the Main Menu, press the “MENU 1” button, which will cause the Monitor setup menu to be displayed on the LCDW-9230-101-x. To scroll through the setup modes, press the “MENU 2” button to scroll forward or the “MENU1” button to scroll back. -
Page 14: Instructions For Continued Airworthiness
Instructions for Continued Airworthiness No periodic scheduled maintenance or calibration is required for continued airworthiness of the LCDW-9230-101-x. If the unit fails to perform to specifications, it must be removed and serviced by a qualified service facility. Troubleshooting... -
Page 15: General Troubleshooting Procedures
Do not allow cleaner to puddle or pool around edges. Seepage may damage internal circuitry. DeCrane Aerospace Audio International’s recommended cleaning method follows: A. Turn off monitor. B. Open pre-moistened pad and gently wipe evenly across display glass. -
Page 16: Troubleshooting Chart
Mother board malfunctioning • Contact DAAI * The monitor displays a black screen with the unit turned on and no video signal. Specifications Unit Specifications for LCDW-9230-101-x: Physical Specifications – LCDW-9230-101-x Iridited Aluminum Housing (with black powder-coat finish) Screen Size 23.00"... -
Page 17: Reference Drawings
DeCrane Aerospace Audio International LCDW-9230-101-x Installation Manual Reference Drawings LDCW-9230-101-x – Widescreen LCD Monitor The following diagrams show the unit dimensions, mounting locations, and connector locations for the LCDW-9230-101-x. LCDW-9230-101-x Connector Configuration Document # 540362, Rev A, 11/2008 Page 16 of 18... - Page 18 DeCrane Aerospace Audio International LCDW-9230-101-x Installation Manual Document # 540362, Rev A, 11/2008 Page 17 of 18...
-
Page 19: Sp-Lcd6 -External Menu Switch
DeCrane Aerospace Audio International LCDW-9230-101-x Installation Manual SP-LCD6 – External Menu Switch The following diagrams show the unit dimensions and connector locations for the external menu selection switch, SP-LCD6. Document # 540362, Rev A, 11/2008 Page 18 of 18...
