- Page 1 Installation Manual LCDP-9151-201 15.1" LCD Monitor with Plug-In Arm Document # 540355 7300 Industry Drive, North Little Rock, AR 72117 Phone: 501-955-2929 Fax: 501-955-2988 www.decraneaerospace.com...
- Page 2 DeCrane Aerospace Audio International. Neither this document nor the data contained herein shall be reproduced, used, or disclosed to anyone without the written authorization of DeCrane Aerospace Audio International. Document # 540355, IR, 11/2007...
-
Page 3: Table Of Contents
Airworthiness Limitations………………..……………………..… Cleaning Method………………………………………………….. Troubleshooting ………………………………………………… General Troubleshooting Procedures ………………………….. Troubleshooting Chart……………………………………………. Specifications …………………………………………………… Reference Drawings ……………………………………………. Dimensions and Connections: LCDP-9151-201 ……………… Dimensions and Connections: BSE-9101-201-x ……………… Friction Joints: LCDP-9151-201 ………………………………… Document # 540355, IR, 11/2007 Page 2 of 16... -
Page 4: Optional Equipment
Contact your DeCrane Aerospace Audio International representative for details. Application Introduction 2.1.1 The LCDP-9151-201 is a LCD monitor with Composite video, PC Graphic capabilities, and Serial Digital interface capabilities. If any Document # 540355, IR, 11/2007 Page 3 of 16... -
Page 5: Communication
DeCrane Aerospace Audio International LCDP-9151-201 Installation Manual one of these formats is applied to their respective inputs, the monitor will display that format. 2.1.2 Very flexible wide-ranging picture controls are provided via an on- screen menu. These controls include picture size/position controls as well as contrast, brightness, and color/hue for video. -
Page 6: Plug-In Arm Mobility
Plug-In Arm Mobility The Plug-In Arm affords the LCDP-9151-201 a wide range of mobility, allowing the user to present the monitor screen to a passenger at a desired distance and viewing angle. - Page 7 DeCrane Aerospace Audio International LCDP-9151-201 Installation Manual SIDE VIEW Document # 540355, IR, 11/2007 Page 6 of 16...
-
Page 8: Preparation
• Environmental conditions (temperature, humidity, etc.) • Length of cable runs 3.1.2 The LCDP-9151-201 shall be installed to conform to the standards designated by the customer, installing agency, and existing conditions as to the unit location and type of installation. - Page 9 (6) inches between the lines. 3.4.2 Power Wires DeCrane Aerospace Audio International recommends that the chassis be electrically bonded to the airframe structure by a conductive mounting point with <0.1 resistance using <50...
- Page 10 LCDP-9151-201. Serial digital video connections are recommended to use shielded coaxial cable in accordance with PIC V76261 or equivalent.
- Page 11 Industry Standard Digital Video Input ANSI/SMPTE 259M-1997 3.5.2 The LCDP-9151-201 utilizes a 11-pin connector that provides power input, ground, video input, monitor on/off control and RS-485. Two (2) pins are also provided. These ID pins allow for up to four (4) units to be connected on the same AI proprietary RS-485 data bus while maintaining independent control of each unit.
-
Page 12: Mating Connector Information
Instructions for Continued Airworthiness Airworthiness Limitations No periodic scheduled maintenance or calibration is required for continued airworthiness of the LCDP-9151-201. If the unit fails to perform to specifications, it must be removed and serviced by a qualified service facility. Cleaning Method 4.2.1 The LCDP-9151-201 should be cleaned when excessive dust or dirt... -
Page 13: Troubleshooting
Do not allow cleaner to puddle or pool around edges. Seepage may damage internal circuitry. 4.2.2 DeCrane Aerospace Audio International’s recommended cleaning method follows: Turn off monitor. Open pre-moistened pad and gently wipe evenly across display glass. -
Page 14: Troubleshooting Chart
Audio International malfunctioning * The monitor displays a black screen with the unit turned on and no video signal. Specifications Unit Specifications for LCDP-9151-201: Physical Specifications – LCDP-9151-201 Screen Size 15.1 (38.4 cm) diagonal Weight Approx. 5.86 lb / 2.66 kg Dimensions See Reference Drawings 7.0... -
Page 15: Reference Drawings
Reference Drawings Dimensions and Connections: LCDP-9151-201 The following diagrams show the unit dimensions, mounting locations, and connector locations for the LCDP-9151-201. All dimensions are given with tolerance of 0.03" (0.08 cm). Dimensions and Connections: BSE-9101-201-x Document # 540355, IR, 11/2007... -
Page 16: Friction Joints: Lcdp-9151-201
DeCrane Aerospace Audio International LCDP-9151-201 Installation Manual BSE-9101-201-x Plug-In Monitor Base is required for mounting. This base is sold separately. Contact your DeCrane Aerospace Audio International representative for details. Friction Joints: LCDP-9151-201 Document # 540355, IR, 11/2007 Page 15 of 16... - Page 17 DeCrane Aerospace Audio International LCDP-9151-201 Installation Manual Friction Joints allow arm movement with minimum resistance while allowing arm to remain in desired position. Document # 540355, IR, 11/2007 Page 16 of 16...
