- Page 1 Installation Manual LCDHW-420-BN1-x 42" High Definition Widescreen LCD Monitor Document # 540390 7300 Industry Drive, North Little Rock, AR 72117 Phone: 501-955-2929 Fax: 501-955-2988 www.decraneaerospace.com...
-
Page 2: Reference Documents
DeCrane Aerospace Audio International. Neither this document nor the data contained herein shall be reproduced, used, or disclosed to anyone without the written authorization of DeCrane Aerospace Audio International. Document # 540390, Rev IR, 08/2010... -
Page 3: Table Of Contents
DeCrane Aerospace Audio International LCDHW-420-BN1-x Installation Manual Table of Contents Section Description Page General Information ....... . -
Page 4: General Information
DeCrane Aerospace Audio International’s “building block” system for configuring total cabin management. Application Introduction The LCDHW-420-BN1-x is a 42.0" Wide Screen High Definition LCD monitor with HDMI and 3G-SDI input. Document # 540390, Rev IR, 08/2010 Page 3 of 16... -
Page 5: Communication
LCDHW-420-BN1-x Installation Manual Communication This unit incorporates an IEEE 802.3 compliant Ethernet interface for communication purposes to other network-connected devices. The Ethernet protocol is compliant to DeCrane Aerospace Audio International’s Ethernet Specification document 480032. Block Diagram - Typical Application Typical Interfaces 2.4.1... -
Page 6: Installation
• Environmental conditions (temperature, humidity, etc.) • Length of cable runs 3.1.2 The LCDHW-420-BN1-x shall be installed to conform to the standards designated by the customer, installing agency, and existing conditions as to the unit location and type of installation. -
Page 7: Unpacking And Inspection
3.1.8 The maximum length of the connection to PC Graphic (VGA) input is 15 feet. Unpacking and Inspection 3.2.1 Carefully open the packaging and remove the LCDHW-420-BN1-x. Verify that all components have been included in the package per the packing list. Inspect the unit for damage. Retain the packing materials and packing list. -
Page 8: Wiring Requirements
DeCrane Aerospace Audio International LCDHW-420-BN1-x Installation Manual Wiring Requirements 3.4.1 Introduction The installing agency shall supply and fabricate all external cables and mating connectors. The length and routing of external cables should be carefully studied and planned before attempting installation of the equipment. Allow adequate space for installation of cable and connectors. -
Page 9: Electrical Characteristics
Storage Temperature -20° to +60° C 3.5.2 The LCDHW-420-BN1-x utilizes four (4) connectors. P1 is a 15-pin connector that provides Ethernet control. Four (4) ID pins are also provided on the P1 connector. These ID pins allow for up to 16 units to be connected on the same DeCrane Aerospace Audio International’s Ethernet network while maintaining independent... -
Page 10: Mating Connector Information
DeCrane Aerospace Audio International LCDHW-420-BN1-x Installation Manual 3.5.3 P2 is a 19-pin connector that provides HDMI connectivity. 3.5.4 P3 is a BNC connection that provides HDSDI connectivity. 3.5.5 P4 is a 6-pin Amphenol connector that provides power input and ground. -
Page 11: Pinout Assignment Descriptions
DeCrane Aerospace Audio International LCDHW-420-BN1-x Installation Manual Pinout Assignment Descriptions Pinout assignment for the LCDHW-420-BN1-x is as follows: Pin # Description Reserved Ethernet RX+ Ethernet RX- Ethernet TX+ Ethernet TX- Ethernet Shield ID Common ID Bit 0 ID Bit 1... -
Page 12: Instructions For Continued Airworthiness
Reserved Instructions for Continued Airworthiness No periodic scheduled maintenance or calibration is required for continued airworthiness of the LCDHW-420-BN1-x. If the unit fails to perform to specifications, it must be removed and serviced by a qualified service facility. Troubleshooting Cleaning Method The LCDHW-420-BN1-x should be cleaned when excessive dust or dirt becomes apparent. -
Page 13: General Troubleshooting Procedures
DeCrane Aerospace Audio International LCDHW-420-BN1-x Installation Manual DeCrane Aerospace Audio International’s recommended cleaning method follows: A. Turn off monitor. B. Open pre-moistened pad and gently wipe evenly across display glass. Do not allow solution to “pool” or puddle around display edges. -
Page 14: Troubleshooting Chart
Contact DeCrane Aerospace Audio International *The monitor displays a black screen with the unit turned on and no video signal. Specifications Unit Specifications for LCDHW-420-BN1-x: Physical Specifications – LCDHW-420-BN1-x Iridited Aluminum Housing (with black powder-coat finish) Screen Size 42" (106.68 cm) diagonal Weight Approx. -
Page 15: Reference Drawings
LCDHW-420-BN1-x Installation Manual Reference Drawings LDCHW-420-BN1-x – High Definition Widescreen LCD Monitor The following diagrams show the unit dimensions, mounting locations, and connector locations for the LCDHW-420-BN1-x. Front View Bottom View LCDHW-420-BN1-x Connector Configuration Document # 540390, Rev IR, 08/2010... - Page 16 DeCrane Aerospace Audio International LCDHW-420-BN1-x Installation Manual Top View Back View Document # 540390, Rev IR, 08/2010 Page 15 of 16...
- Page 17 DeCrane Aerospace Audio International LCDHW-420-BN1-x Installation Manual Side View Document # 540390, Rev IR, 08/2010 Page 16 of 16...
