- Page 1 Installation Manual LCDW-9190-101-x 19" Widescreen LCD Monitor Document # 540383 7300 Industry Drive, North Little Rock, AR 72117 Phone: 501-955-2929 Fax: 501-955-2988 www.decraneaerospace.com...
-
Page 2: Reference Documents
DeCrane Aerospace Audio International. Neither this document nor the data contained herein shall be reproduced, used, or disclosed to anyone without the written authorization of DeCrane Aerospace Audio International. Document # 540383, Rev IR, 08/2009... -
Page 3: Table Of Contents
Specifications ........Unit Specifications – LCDW-9190-101-x .... -
Page 4: General Information
This manual contains information for the proper installation of the DeCrane Aerospace Audio International 19" Widescreen LCD Monitor, Model No: LCDW-9190-101-x. The “-x” suffix designates the type of connector utilized; “-1” = Positronic and “-2” = D-Subminiature. Also included are physical and electrical characteristics of the unit. -
Page 5: Application
LCDW-9190-101-x Installation Manual Application Introduction The LCDW-9190-101-x is a widescreen LCD monitor with Composite Video, PC Graphic capabilities, and Serial Digital Interface capabilities. If any one of these formats is applied to their respective inputs, the monitor will display that format. For installations where multiple inputs may be connected and active at the same time, the user can set the monitor input priority via the On Screen Display (see Section 3.8). -
Page 6: Typical Interface
• Environmental conditions (temperature, humidity, etc.) • Length of cable runs 3.1.2 The LCDW-9190-101-x shall be installed to conform to the standards designated by the customer, installing agency, and existing conditions as to the unit location and type of installation. - Page 7 3.1.9 The LCDW-9190-101-1 is configured using the external menu selection switch, SP-LCD6. The switch utilizes a D-Subminiature connector. This connector mates with the D-Subminiature connector on the LCDW-9190-101-x model monitor. 3.1.10 A 3/8 long grounding lug is included as part of the housing. See Section 7.0 for details.
-
Page 8: Unpacking And Inspection
DeCrane Aerospace Audio International LCDW-9190-101-x Installation Manual Unpacking and Inspection 3.2.1 Carefully open the packaging and remove the LCDW-9190-101-x. Verify that all components have been included in the package per the packing list. Inspect the unit for damage. Retain the packing materials and packing list. -
Page 9: Wiring Requirements
DeCrane Aerospace Audio International LCDW-9190-101-x Installation Manual Wiring Requirements 3.4.1 Introduction The installing agency shall supply and fabricate all external cables and mating connectors. The length and routing of external cables should be carefully studied and planned before attempting installation of the equipment. Allow adequate space for installation of cable and connectors. -
Page 10: Electrical Characteristics
Green Mounting Studs 6-32 x 0.75 inches long 3.5.3 The LCDW-9190-101-x utilizes three (3) connectors. J1 is a 13-pin connector that provides power input, ground, video input, monitor on/off control and monitor status. The monitor on/off function (J1, Pin 5) is transition level sensitive. - Page 11 3.5.5 J3 is a 15-pin high-density connector that provides VGA signal to the monitor. 3.5.6 The SP-LCD6 utilizes one (1) 9-pin connector that mates with J2 of the LCDW-9190-101-x. This connector provides +28 VDC power input, ground, data bus connections, and data bus configuration ID connections.
-
Page 12: Mating Connector Information
LCDW-9190-101-1 (Positronic Industries) DAMA-15PK87 Male Plug w/ male jackscrews or equivalent LCDW-9190-101-2 (ITT Cannon) Pinout Assignment Descriptions 3.7.1 Pinout assignment for the LCDW-9190-101-x is as follows: Pin # Description +28VDC Power Input Ground Reserved Monitor Status Gnd Output Monitor On/Off Gnd Input... - Page 13 DeCrane Aerospace Audio International LCDW-9190-101-x Installation Manual Pin # Description +28VDC Power Output For Monitor Control Panel Ground Data Bus A Data Bus B Data Bus Shield ID Common Pin # Description Red Video Green Video Blue Video Reserved Ground...
-
Page 14: Sp-Lcd6 Configuration Overview
To access the Main Menu, press the “MENU 1” button, which will cause the Monitor setup menu to be displayed on the LCDW-9190-101-x. To scroll through the setup modes, press the “MENU 2” button to scroll forward or the “MENU1” button to scroll back. -
Page 15: Instructions For Continued Airworthiness
Instructions for Continued Airworthiness Airworthiness Limitations No periodic scheduled maintenance or calibration is required for continued airworthiness of the LCDW-9190-101-x. If the unit fails to perform to specifications, it must be removed and serviced by a qualified service facility. Troubleshooting... -
Page 16: General Troubleshooting Procedures
DeCrane Aerospace Audio International LCDW-9190-101-x Installation Manual General Troubleshooting Procedures • Verify power to the unit by rechecking +28 VDC power is applied to the proper pins on the unit. Use a voltmeter to verify correct level. • Remove power from the unit for at least one (1) minute and reapply power. -
Page 17: Specifications
DeCrane Aerospace Audio International LCDW-9190-101-x Installation Manual Specifications Unit Specifications for LCDW-9190-101-x: Physical Specifications – LCDW-9190-101-x Iridited Aluminum Housing (with black powder-coat finish) Weight Approx. 8.0 lb / 3.63 kg 0.80 lb / 0.40 kg Dimensions 17.47" x 1.65" x 10.66"... -
Page 18: Reference Drawings
DeCrane Aerospace Audio International LCDW-9190-101-x Installation Manual Reference Drawings LDCW-9190-101-x – Widescreen LCD Monitor The following diagrams show the unit dimensions, mounting locations, and connector locations for the LCDW-9190-101-x. LCDW-9190-101-x Connector Configuration Document # 540383, Rev IR, 08/2009 Page 17 of 19... - Page 19 DeCrane Aerospace Audio International LCDW-9190-101-x Installation Manual Document # 540383, Rev IR, 08/2009 Page 18 of 19...
-
Page 20: Sp-Lcd6 - External Menu Switch
DeCrane Aerospace Audio International LCDW-9190-101-x Installation Manual SP-LCD6 – External Menu Switch The following diagrams show the unit dimensions and connector locations for the external menu selection switch, SP-LCD6. Document # 540383, Rev IR, 08/2009 Page 19 of 19...
