- Page 1 Installation Manual LCDW-9320-101-x 32" Widescreen LCD Monitor Document # 540363 7300 Industry Drive, North Little Rock, AR 72117 Phone: 501-955-2929 Fax: 501-955-2988 www.decraneaerospace.com...
-
Page 2: Reference Documents
DeCrane Aerospace Audio International. Neither this document nor the data contained herein shall be reproduced, used, or disclosed to anyone without the written authorization of DeCrane Aerospace Audio International. Document # 540363, Rev A1, 11/2008... -
Page 3: Table Of Contents
Specifications ........Unit Specifications-LCDW-9320-101-x .... -
Page 4: General Information
This manual contains information for the proper installation of the DeCrane Aerospace Audio International 32" Widescreen Liquid Crystal Display (LCD) Monitor, Model No: LCDW-9320-101-x. The “-x” suffix designates the type of connector utilized; “-1” = Positronic and “-2” = D-Subminiature. Also included are physical and electrical characteristics of the unit. -
Page 5: Application
DeCrane Aerospace Audio International representative for details. Application Introduction The LCDW-9320-101-x is a widescreen LCD monitor with Composite Video, PC Graphic capabilities, and Serial Digital Interface capabilities. If any one of these formats is applied to their respective inputs, the monitor will display that format. -
Page 6: Installation
• Environmental conditions (temperature, humidity, etc.) • Length of cable runs 3.1.2 The LCDW-9320-101-x shall be installed to conform to the standards designated by the customer, installing agency, and existing conditions as to the unit location and type of installation. - Page 7 Refer to Section 6.0 for unit dimensions. 3.1.9 The LCDW-9320-101-x is configured using the external menu selection switch, SP-LCD6. The switch utilizes a D-Subminiature connector. This connector mates with the D-Subminiature connector on the LCDW-9320-101-x model monitor.
-
Page 8: Unpacking And Inspection
DeCrane Aerospace Audio International LCDW-9320-101-x Installation Manual Unpacking and Inspection 3.2.1 Carefully open the packaging and remove the LCDW-9320-101-x. Verify that all components have been included in the package per the packing list. Inspect the unit for damage. Retain the packing materials and packing list. -
Page 9: Wiring Requirements
LCDW-9320-101-x. Serial Digital Video connections are recommended to use shielded coaxial cable in accordance with PIC V76261 or equivalent. -
Page 10: Electrical Characteristics
Green Mounting Studs 6-32 x 0.75 inches long 3.5.3 The LCDW-9320-101-x utilizes three (3) connectors. J1 is a 13-pin connector that provides power input, ground, video input, monitor on/off control and monitor status. The monitor on/off function (J1, Pin 5) is transition level sensitive. - Page 11 3.5.5 J3 is a 15-pin high-density connector that provides VGA signal to the monitor. 3.5.6 The SP-LCD6 utilizes one (1) 9-pin connector that mates with J2 of the LCDW-9320-101-x. This connector provides +28 VDC power input, ground, data bus connections, and data bus configuration ID connections.
-
Page 12: Mating Connector Information
LCDW-9320-101-1 (Positronic Industries) DAMA15PK87 Male Plug w/ male jackscrews or equivalent LCDW-9320-101-2 (ITT Cannon) Pinout Assignment Descriptions 3.7.1 Pinout assignment for the LCDW-9320-101-x is as follows: Pin # Description +28VDC Power Input Ground Reserved Monitor Status Gnd Output Monitor On/Off Gnd Input... -
Page 13: Sp-Lcd6 Configuration Overview
Unit ID Common SP-LCD6 Configuration Overview 3.8.1 Configuration is typically accomplished via an SP-LCD6 attached to the D-Subminiature connector on the monitor. DeCrane Aerospace Audio International reserves the right to add, delete, or alter Document # 540363, Rev A1, 11/2008... -
Page 14: Instructions For Continued Airworthiness
Instructions for Continued Airworthiness No periodic scheduled maintenance or calibration is required for continued airworthiness of the LCDW-9320-101-x. If the unit fails to perform to specifications, it must be removed and serviced by a qualified service facility. Document # 540363, Rev A1, 11/2008... -
Page 15: Troubleshooting
LCDW-9320-101-x Installation Manual Troubleshooting Cleaning Method The LCDW-9320-101-x should be cleaned when excessive dust or dirt becomes apparent. Use a twin pack cleaning system that employs a wet pad pre-moistened with an Isopropyl Alcohol based cleaner/anti-static solution and a lint-free drying cloth. -
Page 16: Troubleshooting Chart
Contact DeCrane Aerospace Audio International *The monitor displays a black screen with the unit turned on and no video signal. Specifications Unit Specifications for LCDW-9320-101-x: Physical Specifications – LCDW-9320-101-x Iridited Aluminum Housing (with black powder-coat finish) Screen Size 32" (81.28 cm) diagonal Weight Approx. -
Page 17: Unit Specifications-Sp-Lcd6
Note: These dimensions are for the cutout. Reference Drawings LDCW-9320-101-x – Widescreen LCD Monitor The following diagrams show the unit dimensions, mounting locations, and connector locations for the LCDW-9320-101-x. LCDW-9320-101-x Connector Configuration Document # 540363, Rev A1, 11/2008 Page 16 of 18... - Page 18 DeCrane Aerospace Audio International LCDW-9320-101-x Installation Manual Document # 540363, Rev A1, 11/2008 Page 17 of 18...
-
Page 19: Sp-Lcd6 -External Menu Switch
DeCrane Aerospace Audio International LCDW-9320-101-x Installation Manual SP-LCD6 – External Menu Switch The following diagrams show the unit dimensions and connector locations for the external menu selection switch, SP-LCD6. Document # 540363, Rev A1, 11/2008 Page 18 of 18...
