prestige
If the information in this manual is not followed exactly, a fire or explosion may
WARNING
result causing property damage, personal injury or loss of life.
•
Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or
any other appliance.
•
WHAT TO DO IF YOU SMELL GAS
- Do not try to light any appliance
- Do not touch any electrical switch; do not use any phone in your building.
- Immediately call your gas supplier from a neighbor's phone. Follow the gas supplier's
instructions.
- If you cannot reach your gas supplier, call the fire department.
Installation and service must be performed by a qualified installer, service agency or the gas
supplier.
Date: 12/4/15
User s Information Manual
To maintain the safety & longevity
of your appliance read and follow
the maintenance schedule infor-
mation throughout this manual.
FOR YOUR SAFETY
WARNING
2015-11 Prestige ACVMax User's Manual
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for ACV Prestige
Summary of Contents for ACV Prestige
- Page 1 - Immediately call your gas supplier from a neighbor’s phone. Follow the gas supplier’s instructions. - If you cannot reach your gas supplier, call the fire department. Installation and service must be performed by a qualified installer, service agency or the gas supplier. 2015-11 Prestige ACVMax User’s Manual Date: 12/4/15...
-
Page 2: Table Of Contents
Product & Safety Information Homeowner ......................1 Technician ......................2 Service and Maintenance...................2 PRESTIGE Operation....................2 Boiler & System Water ....................2 Section I - Combustion Air - Prevention of Contamination Potential Contaminating Products.................4 Section II - Maintenance Schedule Service Technician ....................5 2.1.1 General ......................5 2.1.2 Poor Performance or Combustion ..............5... - Page 3 Table of Contents Lockout Screen .....................19 5.10 Manual Reset Hard Lockouts ................20 5.11 Automatic Reset Soft Lockouts ................21 Section VI - Replacement Parts Solo 80/110 Jacket Components..................23 Solo 155/175/250 Jacket Components ................24 Solo 299/399 Jacket Components..................25 Solo 80/110 Internal Components ...................27 Solo 155/175/250 Internal Components ................28 Solo 299/399 Internal Components .................29 Solo 80/110 &...
-
Page 4: Product & Safety Information Homeowner
The following terms are used throughout this manual to WARNING bring attention to the presence of potential hazards or to The PRESTIGE installation manual is for use only by important information concerning the product. a qualified heating installer / service technician. -
Page 5: Technician
Do not allow contaminated air to enter the unit’s combustion air inlet. See page 4 for details. • The PRESTIGE is equipped with a low water cutoff device. The boiler and system piping must be filled and pressurized to 12 psig prior to startup. The unit will shut down if the pressure falls below 10 psig. - Page 6 Product & Safety Information (Page left intentionally blank)
-
Page 7: Section I - Combustion Air - Prevention Of Contamination
WARNING Hydrochloric acid / muriatic acid Cements and glues Do not operate a PRESTIGE unit if its combustion air Antistatic fabric softeners used in clothes dryers inlet or the unit is located in or near a laundry room or pool facility. These areas will always contain haz- Chlorine-type bleaches, detergents, and clean- ardous contaminates. -
Page 8: Service Technician
Check ignition wiring and ground wiring. in this manual could result in damage to the Check all control wiring and connections. PRESTIGE or in system components, resulting in severe personal injury, death or substantial Check burner flame pattern (stable and uniform). -
Page 9: Daily Maintenance
5. In addition tact your qualified service technician to inspect to this maintenance, the PRESTIGE should be serv- the unit and the vent / combustion air system. iced at the beginning of the heating season by a qualified service technician. -
Page 10: Monthly Maintenance
Fig. 1: Condensate Drain Assembly WARNING 3.2.5 Check Automatic Air Vents (If Used) Do not operate PRESTIGE without condensate drain assembly firmly installed on unit and filled with 1. Remove the cap “A” from any automatic air vent water. If the trap is not installed and full of water flue... -
Page 11: 6-Month Maintenance
This discharge line must be installed by a qualified service technician or heating / plumbing installer in accordance with the PRESTIGE installa- tion manual. The discharge line must be terminated so as to eliminate possibility of severe burns or property damage should the valve discharge. -
Page 12: Section Iv - Operating Instructions
Follow the gas supplier’s instructions. OPERATING INSTRUCTIONS STOP! Read the safety information above. This appli- Turn the service switch on the PRESTIGE control panel “ON”. ance is equipped with an ignition device which auto- matically lights the burner. DO NOT try to light the burn- Set room thermostat(s) to desired setting(s). -
Page 13: Acvmax Navigation
The ACVMax Boiler Management System is designed to be flexible yet easy to use. ACVMax monitors and controls the Prestige to provide heat as efficiently as possible. All ACVMax features are easy to use through a graphical dis- play where information is presented either graphically or in plain English, so code charts are not required. -
Page 14: Acvmax Menu Structure
ACVMax Operation ACVMax Menu Structure... -
Page 15: Home Screen
The Home Screen presents status information in a very user friendly way so that the current state of the boiler can be quickly accessed. The Prestige is represented in the center of the Home Screen. Basic operating information such as supply and return temperatures are displayed as well as current burner status. -
Page 16: Status Line Messages
The domestic circulator continues to operate and the burner will fire again once the supply/system water temperature drops below the setpoint. The central heating circulator is running to remove heat from the Prestige at the CH Post Pump completion of a call. -
Page 17: Main Menu
ACVMax Operation Main Menu The Main Menu can be entered from the Home Screen by pressing the OK button. The menu system utilizes icons to represent each selection. The currently selected menu is displayed as a reversed image with a text description shown at the top of the display. -
Page 18: Ch/Dhw Operation Menu
The CH / DHW Operation Menu can be entered from the Main Menu by selecting the CH / DHW Operation icon and pressing the OK button. The CH / DHW Operation Menu provides a simple way to disable either the central heating or domestic hot water functions of the Prestige. CH/DHW Operation... -
Page 19: Boiler Information
ACVMax Operation Boiler Information Boiler Information can be viewed by selecting the Boiler Information icon and pressing the OK button. Boiler Information provides real time operating information of the Prestige. Boiler Information Press OK Button Currently selected menu Boiler Information... -
Page 20: Information Items
ACVMax Operation Information Items Information Item Description Displays the current operating state of the Prestige. This is the same as Boiler Status the status line on the home screen. Displays if a central heating call is present. Heating Call Displays if a domestic hot water call is present. -
Page 21: Lockout History
ACVMax Operation Lockout History Lockout History can be viewed by selecting the Lockout History icon and pressing the OK button. The Lockout History Screen lists the last eight lockouts along with how long ago they occurred. Lockout History Press OK Button Currently selected menu Lockout History 1: Low water... -
Page 22: Lockout Screen
The Lockout Screen replaces the Home Screen if a lockout occurs. The screen backlight will also illuminate con- stantly while the Prestige is locked out. Pressing any arrow button will return to the Home Screen so that addi- tional troubleshooting can be performed. See pages 20 and 21 for a list of lockouts and descriptions. -
Page 23: Manual Reset Hard Lockouts
ACVMax Operation 5.10 Manual Reset Hard Lockouts Code Lockout Message Description Failed Ignition The burner failed to light after 5 ignition attempts. False Flame A flame is being detected prior to ignition. High Boiler Temperature Boiler temperature has reached 210°F [99ºC] Blower is not at correct speed or speed signal is not being received Blower Speed by control module. -
Page 24: Automatic Reset Soft Lockouts
ACVMax Operation 5.11 Automatic Reset Soft Lockouts Code Lockout Message Description High Flue Temperature Flue temperature exceeds high limit. Internal Control Fault EEPROM misconfiguration Internal Control Fault CRC check error. DHW Sensor Shorted A short circuit has been detected in the DHW temperature sensor circuit. DHW Sensor Open An open circuit has been detected in the DHW temperature sensor circuit. -
Page 25: Section Vi - Replacement Parts
Use only genuine ACV-Triangle Tube replacement parts to ensure warranty coverage and to avoid damage to appliance and improper operation of appliance. Contact ACV-Triangle... - Page 26 Replacement Parts Fig. 3: PRESTIGE Solo 80/110 Jacket Components Item Part # Description PAJKT01 Front Jacket Panel (with insulation) PAJKT03 Left Side Jacket Panel (with insulation) PAJKT21 Right Side Jacket Panel (with insulation) PAJKT04 Top Panel PSRKIT21 Wall Mounting Bracket with Hardware...
-
Page 27: Solo 155/175/250 Jacket Components
Replacement Parts Fig. 4: PRESTIGE Solo 155/175/250 Jacket Components Item Part # Description PAJKT01 Front Jacket Panel (with insulation) PAJKT03 Left Side Jacket Panel (with insulation) PAJKT21 Right Side Jacket Panel (with insulation) PAJKT12 Top Panel PSRKIT21 Wall Mounting Bracket with Hardware... -
Page 28: Solo 299/399 Jacket Components
Replacement Parts Fig. 5: PRESTIGE Solo 299/399 Jacket Components Item Part # Description PAJKT15 Front Jacket Panel (with insulation) PAJKT16 Left Side Jacket Panel (with insulation) PAJKT22 Right Side Jacket Panel (with insulation) PAJKT17 Top Panel - Front PAJKT18 Top Panel - Rear... - Page 29 Replacement Parts (Page left intentionally blank)
-
Page 30: Solo 80/110 Internal Components
Replacement Parts Fig. 6: PRESTIGE Solo 80/110 Internal Components Item Part # Description PARKIT90 Heat Exchanger Body PTADPT07 Vent Outlet/Combustion Air Inlet Adapter PARKIT02 Polypropylene Vent Pipe PTRKIT123 Supply/Return Temperature Sensor PARKIT01 Flue Temperature Sensor PARKIT04 LWCO Pressure Sensor PARKIT05... -
Page 31: Solo 155/175/250 Internal Components
Replacement Parts Fig. 7: PRESTIGE Solo 155/175/250 Internal Components Item Part # Description PARKIT91 Heat Exchanger Body Solo 155 PARKIT92 Heat Exchanger Body Solo 175 PARKIT93 Heat Exchanger Body Solo 250 PTADPT07 Vent Outlet/Combustion Air Inlet Adapter PARKIT08 Polypropylene Vent Pipe... -
Page 32: Solo 299/399 Internal Components
Replacement Parts Fig. 8: PRESTIGE Solo 299/399 Internal Components Item Part # Description PARKIT94 Heat Exchanger Body Solo 299 PARKIT95 Heat Exchanger Body Solo 399 PTADPT08 Vent Outlet/Combustion Air Inlet Adapter PARKIT09 Polypropylene Vent Pipe PARKIT78 Supply/Return Temperature Sensor PARKIT01... - Page 33 Replacement Parts (Page left intentionally blank)
-
Page 34: Solo 80/110 & Excellence Burner Components
Replacement Parts Fig. 9: PRESTIGE Solo 80/110 & Excellence Burner Components Item Part # Description PARKIT12 Combustion Chamber 2-in-1 Insulation PARKIT14 Burner Head Assembly (with Gasket) PARKIT11 Blower Assembly (with Gasket) PARKIT18 Blower Clamp PARKIT19 Blower Gasket PARKIT15 Burner Plate Assembly... -
Page 35: Solo 155/175/250 Burner Components
Replacement Parts Fig. 10: PRESTIGE Solo 155/175/250 Burner Components Item Part # Description PARKIT42 Combustion Chamber 2-in-1 Insulation - Solo 155 PARKIT52 Combustion Chamber 2-in-1 Insulation - Solo 175 & 250 PARKIT54 Burner Head Assembly (with Gasket) PARKIT51 Blower Assembly (with Gasket) - Solo 155 & 175... -
Page 36: Solo 299/399 Burner Components
Replacement Parts Fig. 11: PRESTIGE Solo 299/399 Burner Components Item Part # Description PARKIT72 Combustion Chamber 2-in-1 Insulation PARKIT74 Burner Head Assembly (with Gasket) PARKIT71 Blower Assembly (with Gasket) PARKIT18 Blower Clamp PARKIT19 Blower Gasket PARKIT75 Burner Plate Assembly PARKIT79... -
Page 37: Control Module Enclosure
Replacement Parts Fig. 12: PRESTIGE Display & Control Module Enclosures Item Part # Description PTRKIT109 Pressure Gauge PTSWI01 Power Switch PTSWI02 Power Switch Cover PADIS02 Display Module PACON01 Control Module PAHNG01 Control Box Hinges... -
Page 38: Section Vii - Notes
Notes SECTION VII - NOTES... - Page 39 Notes...
- Page 40 Additional quality water heating equipment available from ACV- Triangle Tube Brazed Plate Heat Exchangers For domestic water, snow melting, radiant floor, refrigeration Plates made of stainless steel, with a 99.9 % copper and brazed, ensuring a high resistance to corrosion...
