INSTALLER: Leave this manual with party responsible for use and operation.
OWNER: Retain this manual for future reference.
NOTICE: DO NOT discard this manual!
QUARTZ
SERIES
Models:
This appliance may be installed as an OEM
installation in manufactured home (USA
only) or mobile home and must be installed
in accordance with the manufacturer's
instructions and the Manufactured Home
Construction and Safety Standard, Title 24
CFR, Part 3280 in the United States, or the
Standard for Installation in Mobile Homes,
CAN/CSA Z240 MH Series, in Canada.
This appliance is only for use with the type(s)
of gas indicated on the rating plate. This
appliance is not convertible for use with other
gases, unless a certifi ed kit is used.
In the Commonwealth of Massachusetts installation must be
performed by a licensed plumber or gas fi tter.
See Table of Contents for location of additional Commonwealth
of Massachusetts requirements.
Installation Manual
Installation and Appliance Setup
Majestic • QUARTZ32, QUARTZ36 Installation Manual • 2412-980 Rev. H • 10/16
WARNING:
FIRE OR EXPLOSION HAZARD
Failure to follow safety warnings exactly
could result in serious injury, death, or
property damage.
• DO NOT store or use gasoline or other fl am-
mable vapors and liquids in the vicinity of this
or any other appliance.
• What to do if you smell gas
- DO NOT try to light any appliance.
- DO NOT touch any electrical switch. DO
NOT use any phone in your building.
- Leave the building immediately.
- Immediately call your gas supplier from
a neighbor's phone. Follow the gas sup-
plier's instructions.
- If you cannot reach your gas supplier, call
the fi re department.
• Installation and service must be performed
by a qualifi ed installer, service agency, or the
gas supplier.
DANGER
DO NOT TOUCH GLASS
NEVER ALLOW CHILDREN
A barrier designed to reduce the risk of
burns from the hot viewing glass is provided
with this appliance and shall be installed for
the protection of children and other at-risk
individuals.
HOT GLASS WILL
CAUSE BURNS.
UNTIL COOLED.
TO TOUCH GLASS.
1
Advertisement
Table of Contents
Related Manuals for Majestic fireplaces QUARTZ32IN
Summary of Contents for Majestic fireplaces QUARTZ32IN
- Page 1 Installation Manual Installation and Appliance Setup INSTALLER: Leave this manual with party responsible for use and operation. OWNER: Retain this manual for future reference. NOTICE: DO NOT discard this manual! WARNING: QUARTZ FIRE OR EXPLOSION HAZARD Failure to follow safety warnings exactly SERIES could result in serious injury, death, or property damage.
-
Page 2: Table Of Contents
Safety Alert Key: • DANGER! Indicates a hazardous situation which, if not avoided will result in death or serious injury. • WARNING! Indicates a hazardous situation which, if not avoided could result in death or serious injury. • CAUTION! Indicates a hazardous situation which, if not avoided, could result in minor or moderate injury. •... -
Page 3: Installation Standard Work Checklist
This standard work checklist is to be used by the installer in conjunction with, not instead of, the instructions contained in this installation manual. Customer: Date Installed: Lot/Address: Location of Fireplace: Installer: Model (circle one): QUARTZ32IN QUARTZ32IL Dealer/Distributor Phone # QUARTZ36IN QUARTZ36IL Serial #: WARNING! Risk of Fire or Explosion! Failure to install appliance according to these instructions could lead to a re or explosion. -
Page 4: Product Specifi C And Important Safety Information
Product Specifi c and Important Safety Information A. Appliance Certifi cation C. BTU Specifi cations MODELS: QUARTZ32IN, QUARTZ32IL, Orifi ce Models Maximum Minimum Size Input BTU/h Input BTU/h (U.S. or Canada) (DMS) QUARTZ36IN, QUARTZ36IL QUARTZ32IN LABORATORY: Underwriters Laboratories, Inc. (UL) -
Page 5: Requirements For The Commonwealth Of Massachusetts
Inspection Note: The following requirements reference various The state or local gas inspector of the side wall horizon- Massachusetts and national codes not contained in this tally vented gas fueled equipment shall not approve the document. installation unless, upon inspection, the inspector ob- serves carbon monoxide detectors and signage installed H. -
Page 6: Getting Started
Getting Started A. Design and Installation Considerations B. Good Faith Wall Surface/TV Guidelines Majestic direct vent gas appliances are designed to oper- ate with all combustion air siphoned from outside of the FIREPLACE building and all exhaust gases expelled to the outside. No TO CEILING OPENING additional outside air source is required. -
Page 7: Inspect Appliance And Components
D. Inspect Appliance and Components • Carefully remove the appliance and components from the packaging. • The vent system components and decorative doors and fronts may be shipped in separate packages. • If packaged separately, the log set and appliance grate must be installed. -
Page 8: Framing And Clearances
A. Appliance/Decorative Front Dimension Diagrams Dimensions are actual appliance dimensions. Use for reference only. For framing dimensions and clearances refer to Section 5. Ø HEAT-ZONE® ACCESS Ø ELECTRICAL ACCESS GAS LINE ACCESS Appliance Dimensions Table QUARTZ32IN/IL QUARTZ36IN/IL Location Inches Millimeters Inches Millimeters 1041 31-1/8... - Page 9 STANDARD DECORATIVE FRONT 28-7/8 25-1/8 1-5/8 2-5/8 27-1/8 28-3/4 QUARTZ32IN/IL SRV2401-021 28-3/4 35-15/16 1-5/8 2-5/8 30-5/8 32-1/4 QUARTZ36IN/IL SRV2402-021 Figure 3.2 Decorative Front Dimensions - Firescreen Majestic • QUARTZ32, QUARTZ36 Installation Manual • 2412-980 Rev. H • 10/16...
-
Page 10: Clearances To Combustibles
Refer to instructions included with cabinet system. Models Min. 59-1/2 62-1/4 16-1/4 48-1/2 68-3/4 15-1/16 7-1/2 QUARTZ32IN/IL See Section 1067 1511 1118 1581 1232 1746 10.B for Alcove Instal- 45-1/2 64-3/8... - Page 11 (Height) (Width) (Width) (Width) (Depth) (Depth) 8-5/8 34-3/4 16-1/4 16-1/4 QUARTZ32IN/IL 8-5/8 38-1/4 16-1/4 16-1/4 QUARTZ36IN/IL 1067 * Adjust framing dimensions for interior sheathing (such as sheetrock) C** Add 12 inches when rear venting with one 90º elbow. Note: Consider use of the optional Heat-Zone ®...
-
Page 12: Constructing The Appliance Chase
NOTICE: Install appliance on hard metal or wood surfaces C. Constructing the Appliance Chase extending full width and depth. DO NOT install directly A chase is a vertical box-like structure built to enclose the on carpeting, vinyl, tile or any combustible material other gas appliance and/or its vent system. -
Page 13: Termination Location And Vent Information
Termination Location and Vent Information A. Vent Termination Minimum Clearances 6 in. (minimum) up to 20 in. 18 in. minimum WARNING 152 mm/508 mm 457 mm 20 in. and over 0 in. minimum Fire Risk. Gas, Wood or Fuel Oil Maintain vent clearance to combustibles as Termination Cap specifi... -
Page 14: Chimney Diagram
B. Chimney Diagram H or i Electrical Service = VENT TERMINAL = AIR SUPPLY INLET = AREA WHERE TERMINAL IS NOT PERMITTED = 12 inches....clearances above grade, veranda, Covered Alcove Applications porch, deck or balcony (Spaces open only on one side and with an overhang) = 12 inches....clearance to window or door that may = 6 inches ... -
Page 15: Approved Pipe
C. Approved Pipe This appliance is approved for use with Hearth & Home Technologies DVP or SLP venting systems. Refer to Sec- tion 12.A for vent component information and dimensions. DO NOT mix pipe, fi ttings or joining methods from differ- ent manufacturers. -
Page 16: Use Of Elbows
D. Use of Elbows Diagonal runs have both vertical and horizontal vent as- pects when calculating the effects. Use the rise for the vertical aspect and the run for the horizontal aspect. See Figure 4.4. Two 45º elbows may be used in place of one 90º elbow. On 45º... -
Page 17: Measuring Standards
E. Measuring Standards Vertical and horizontal measurements listed in the vent diagrams were made using the following standards: • Pipe measurements are shown using the effective length of pipe. See Section 12.A for information on effective length of pipe components. •... -
Page 18: Use Of Flex Vent
G. Vent Diagrams F. Use of Flex Vent The fl ex vent must be supported with the spacing between General Rules: support intervals not exceeding 4 feet, with no more than • SUBTRACT 3 ft. from the total H measurement for each 1/2 inch sag between supports. - Page 19 Top Vent - Horizontal Termination One Elbow Maximum Minimum ALL MODELS One 90º Elbow 90 Elbow * 18 in. 457 mm 1/2 ft.* 152 mm 2 ft. 610 mm Note: Use SLP Series 1-1/2 ft.* 457 mm 3 ft. 914 mm components only.
- Page 20 Top Vent - Horizontal Termination - (continued) Two Elbows Maxi- V Minimum Note: Use SLP Series ALL MODELS components only. 90 Elbow * 1/2 ft. 152 mm 1/2 ft.* 152 mm 1 ft. 305 mm Note: There MUST be a 25% 1-1/2 ft.* 457 mm 2 ft.
- Page 21 Top Vent - Horizontal Termination - (continued) Three Elbows Maxi- Note: Use SLP Series Minimum components only. ALL MODELS Min. 90 Elbow ** 2 ft. 610 mm 1/2 ft.** 152 mm 6 ft. 1.8 m 1-1/2 ft.** 457 mm 10 ft. 3.0 m 2-1/2 ft.** 762 mm 12 ft.
- Page 22 Exhaust restrictor Instructions Top Vent - Vertical Termination Exhaust restrictors are recommended for these verti- cally terminated products which have excessive draft. No Elbow Exhaust restrictors will compensate for high draft, and restore visual fl ame height. If the vent confi guration has a total vertical of 15-60 feet, an exhaust restrictor may be needed.
- Page 23 Top Vent - Vertical Termination - (continued) Two 90º Elbows H MAX. MIN. 90 Elbow 1-1/2 ft. 457 mm 1/2 ft. 152 mm 2 ft. 610 mm 1-1/2 ft. 457 mm 3 ft. 914 mm 2-1/2 ft. 762 mm 5 ft. 1.5 m 3-1/2 ft.
- Page 24 Top Vent - Vertical Termination - (continued) Three Elbows ALL MODELS MIN. H MAX. MIN. Note: Use SLP Series 90 Elbow 1/2 ft. 152 mm components only. 1/2 ft. 152 mm 1 ft. 305 mm 1-1/2 ft. 457 mm 2 ft. 610 mm Note: There MUST be a 25% 2-1/2 ft.
- Page 25 Top Vent - Vertical Termination - (continued) Four 90º Elbows ALL MODELS Min. Max. Min. Max. Min. Note: There MUST be a 25% reduction in total H when 1-1/2 ft. 457 mm 4 ft. 1.2 m 4 ft. 1.2 m 4 ft.
- Page 26 Rear Vent - Horizontal Termination No Elbow Note: Use DVP Series components only. QUARTZ32 24 in. 610 mm QUARTZ36 24 in. 610 mm Figure 4.18 Rear Vent - Horizontal Termination = 9 in. (229 mm) Maximum One 45º Elbow Note: Use DVP Series components only.
- Page 27 Rear Vent - Horizontal Termination - (continued) Two Elbows MAX. MIN. MAX. MAX. 1-1/2 ft. 457 mm Back to back elbows 1 ft. 305 mm 2-1/2 ft. 762 mm 3 ft. 914 mm 1 ft. 305 mm 3 ft. 914 mm 6 ft.
- Page 28 Rear Vent - Horizontal Termination - (continued) Three Elbows MAX. MIN. MAX. MAX. 1-1/2 ft. 457 mm Back to back elbows 1 ft. 305 mm 2-1/2 ft. 762 mm Note: Use DVP Series 3-1/2 ft. 1.1 m 1 ft. 305 mm 2 ft.
- Page 29 Rear Vent - Vertical Termination One Elbow MIN. MAX. 1 ft. 305 mm 3-1/2 ft. 1.1 m 2 ft. 610 mm 5-1/2 ft. 1.7 m Note: Use DVP Series 3 ft. 914 mm 7-1/2 ft. 2.3 m components only. H MAX. = 7-1/2 ft. (2.3 m) MAX.
- Page 30 Rear Vent - Vertical Termination - (continued) ALL MODELS Three Elbows Maximum Minimum Maximum Maximum Back to Back 1-1/2 ft. 457 mm 1 ft. 305 mm 2-1/2 ft. 762 mm Elbows Note: Use DVP Series 3-1/2 ft. 1.1 m 1 ft. 305 mm 3 ft.
- Page 31 Coaxial to Colinear Venting OUTSIDE FACE OF The coaxial to colinear adapter (DV-46DVA-GCL) is ap- FIREPLACE proved for installations into solid fuel masonry or factory built fi replaces that have been installed in accordance EXHAUST VENT PIPE with the National, Provincial, State and local building codes.
- Page 32 Connecting the DV-46DVA-GCL Adapter to Appliance • Attach one section of fl exible vent pipe to the stainless steel fl ex pipe with three self-tapping screws. Top Vent • Attach one section of fl exible vent pipe to the inlet collar •...
-
Page 33: Vent Clearances And Framing
Vent Clearances and Framing A. Pipe Clearances to Combustibles WARNING! Risk of Fire! Maintain air space clearance to vent. DO NOT pack insulation or other combustibles: • Between ceiling fi restops • Between wall shield fi restops • Around vent system Failure to keep insulation or other material away from vent pipe could cause overheating and fi... -
Page 34: Wall Penetration Framing/Firestops
DVP pipe - A wall shield fi restop is required on one 24-3/8 23-3/8 Inches side only on interior walls. If your local inspector re- QUARTZ32IN/IL Millimeters quires a wall shield fi restop on both sides, then both 27-7/8 26-7/8 Inches wall shield fi... -
Page 35: Ceiling Firestop/Floor Penetration Framing
C. Ceiling Firestop/Floor Penetra- tion Framing A ceiling fi restop MUST be used between fl oors and attics. • DVP pipe only - Frame an opening 10 in. by 10 in. (254 mm by 254 mm) whenever ATTIC ABOVE the vent penetrates a ceiling/fl oor (see Figure 5.3). -
Page 36: Appliance Preparation
Appliance Preparation A. Vent Collar Preparation COMBUSTIBLE CAUTION! Risk of Cuts, Abrasions or Flying Debris. SURFACE Wear protective gloves and safety glasses during instal- lation. Sheet metal edges are sharp. 3-6 IN. MIN. HEAT 12-15 IN. (76-152 mm) NOTICE: Once appliance is set up for top or rear venting, SHIELD (305 mm to 381 mm) it CANNOT be changed at a later time. - Page 37 SCREW 3 IN. (76mm) 2 SCREWS Figure 6.7 Replace the two screws as shown. Figure 6.4. Elbow Heat Shield Installed WARNING! Risk of Fire! Do not remove heat shield. El- evated header temperatures may cause a fi re. 2 SCREWS Figure 6.8 Remove the seal cap.
- Page 38 Figure 6.10 Remove the insulation from the outer vent pipe. 2 SCREWS Figure 6.11 To attach the fi rst section of vent pipe, make sure to use the fi berglass gasket to seal between the fi rst vent component and the outer fi replace wrap. Use 2 self tapping screws to secure the gasket to the outer wrap.
- Page 39 Rear Vent NOTICE: Once appliance is set up for top or rear venting, it CANNOT be changed at a later time. Figure 6.12 (Generic Fireplace Shown) Discard the seal cap, remove and discard the insulation basket. Note: Once the seal cap has been removed it CANNOT be reattached. Figure 6.9 (Generic Fireplace Shown) Fold the tabs toward the center of the fi...
-
Page 40: Installing The Optional Heat-Zone Gas Kit
B. Installing the Optional Heat-Zone ® C. Securing and Leveling the Appliance WARNING! Risk of Fire! Prevent contact with: NOTICE: Additional clearances are required for Heat- • Sagging or loose insulation Zone® installations. Provisions must be made in advance • Insulation backing or plastic to ensure fi... -
Page 41: Venting And Chimneys
Venting and Chimneys A. Assemble Vent Sections (DVP Pipe Only) Attach Vent to the Firebox Assembly Note: The end of the pipe sections with the lanced tabs will face toward the appliance. Attach the fi rst pipe section to the starting collar: •... -
Page 42: Assemble Slip Sections
Assemble Vent Sections B. Assemble Slip Sections (SLP Only) • Slide the inner fl ue of the slip section into the inner fl ue To attach the fi rst vent component to the starting collars of the pipe section and the outer fl ue of the slip section of the appliance: over the outer fl... -
Page 43: Secure The Vent Sections
C. Secure the Vent Sections D. Disassemble Vent Sections • Vertical runs originating off the top of the appliance, with • Rotate either section (see Figure 7.10) so the seams on no offsets, must be supported every 8 ft. (2.44 m) after both pipe sections are aligned as shown in Figure 7.11. -
Page 44: Vertical Termination Requirements
E. Vertical Termination Requirements Install Metal Roof Flashing • See minimum vent heights for various pitched roofs CAULK (Figure 7.12) to determine the length of pipe to extend through the roof. • Slide the roof fl ashing over the pipe sections extending through the roof as shown in Figure 7.13. -
Page 45: Horizontal Termination Requirements
Install Vertical Termination Cap F. Horizontal Termination Requirements • Attach the vertical termination cap by sliding the inner Heat Shield Requirements for Horizontal collar of the cap into the inner fl ue of the pipe section Termination while placing the outer collar of the cap over the outer WARNING! Risk of Fire! To prevent overheating and fi... - Page 46 Install Horizontal Termination Cap (DVP and Note: When using termination caps with factory-supplied heat shield attached, no additional wall shield fi restop is SLP Pipe) required on the exterior side of a combustible wall. WARNING! Risk of Fire! The telescoping fl ue section of the termination cap MUST be used when connecting vent.
-
Page 47: Electrical Information
Electrical Information Accessories Requirements A. General Information • This appliance may be used with a wall switch, wall WARNING! Risk of Shock or Explosion! DO NOT wire mounted thermostat and/or a remote control. 110-120 VAC to the valve or to the appliance wall switch. Incorrect wiring will damage controls. - Page 48 IGNITION MODULE 3 VAC INTERMITTENT PILOT IGNITOR NOTE: 1. Ignition module, valve, pilot, and wall switch operate on 3 volts. 110-120 VAC is required at junction box unless equipped with battery back-up. TRANSFORMER WHITE 3 VAC ORANGE GROUND TO FIREPLACE PLUG IN CHASSIS WIRES...
- Page 49 Wall Switch Installation for Fan (Optional) If the box is being wired to a wall mounted switch for use with a fan. See Figure 8.4: Switch Minimum 14-3 AWG • The power supply for the appliance must be brought into with Ground a switch box.
-
Page 50: Gas Information
Gas Information A. Fuel Conversion C. Gas Connection • Make sure the appliance is compatible with available gas • Refer to Reference Section 3 for location of gas line types. access in appliance. • Conversions must be made by a qualified service •... -
Page 51: Air Shutter Setting
(LP) flames may be a little shorter and much vice technician at the time of installation. brighter than a natural gas (NG) flame. Factory Pre-Set Air Shutter Settings QUARTZ32IN (NG) 3/16 in. QUARTZ32IL (PROPANE) 5/16 in. QUARTZ36IN (NG) 3/16 in. -
Page 52: Burner Identifi Cation/Verifi Cation
See Figure 9.2 for burner identifi cation chart. Notch patterns are located on bottom side of burner. DETAIL A NG /LP QUARTZ32IN/IL QUARTZ36IN/IL Figure 9.2 Burner Identifi cation Majestic • QUARTZ32, QUARTZ36 Installation Manual • 2412-980 Rev. H • 10/16... -
Page 53: Finishing
Finishing A. Facing Material NOTICE: Surface temperatures around the appliance will become warm while the appliance is in operation. Ensure • Metal front faces may be covered with non-combustible finishing materials used for all surfaces (floor, walls, materials only. mantels, etc.) will withstand temperatures up to 190°F. •... -
Page 54: Mantel And Wall Projections
B. Mantel and Wall Projections Combustible or Non-Combustible Mantel Legs WARNING! Risk of Fire! Comply with all minimum clear- ances as specifi ed. Framing closer than the minimums list- ed must be constructed entirely of noncombustible materials (i.e., steel studs, concrete board, etc.) Note: Measurement is taken from top of the 1/2 IN. - Page 55 3-1/2 IN. MIN. 12 IN. MINIMUM WITH ELBOW HEAT SHIELD INSTALLED 15 INCH MINIMUM WITHOUT ELBOW HEAT SHIELD INSTALLED. Figure 10.6 Rear Vent Non-Combustible Zone Above Appliance Figure 10.7 Top Vent Non-Combustible Zone Above Appliance Majestic • QUARTZ32, QUARTZ36 Installation Manual • 2412-980 Rev. H • 10/16...
-
Page 56: Decorative Front Finishing
C. Decorative Front Finishing Only decorative fronts certifi ed for use with this appliance model may be used. Contact your dealer for a list of dec- orative fronts that may be used. Once you have deter- mined what kind of decorative front and fi nishing material is going to be used on the fi... -
Page 57: Appliance Setup
11 11 Appliance Setup A. Remove Fixed Glass Assembly C. Clean the Appliance WARNING! Risk of Asphyxiation! Handle fi xed glass Clean/vacuum any sawdust that may have accumulated assembly with care. Inspect the gasket to ensure it is inside the fi rebox or underneath in the control cavity. undamaged and inspect the glass for cracks, chips or scratches. -
Page 58: Install Logs
E. Install Logs Log Set Assembly: LOGS-QUARTZ32, LOGS-QUARTZ36 LOG PLACEMENT Models: QUARTZ32IN, QUARTZ32IL, QUARTZ36IN, QUARTZ36IL INSTRUCTIONS Install Logs RIGHT REAR BASE LOG RIGHT REAR BASE LOG CAUTION: Logs are fragile, handle with care. LEFT REAR BASE LOG LEFT REAR BASE LOG... - Page 59 2. Locate and install the left rear base log (1) by installing the right end of the log over the log pin. Then rotate the rear log until it contacts the rear left hand bend tab. See Figure 4. BASE PAN EDGE BASE PAN EDGE Figure 6.
- Page 60 7. QUARTZ36 ONLY: Locate and install Top Left Log (5). This Log does not have any “burn out” features painted on the log. The “left” end of this log will rest on the base pan and the “right” end will rest on the “left” end of Left Rear Base Log.
-
Page 61: Install Fixed Glass Assembly
G. Install Majestic Decorative Front and F. Install Fixed Glass Assembly Hood WARNING! Risk of Asphyxiation! Handle fi xed glass assembly with care. Inspect the gasket to ensure it is WARNING! Risk of Fire! Install ONLY doors or fronts undamaged and inspect the glass for cracks, chips or approved by Hearth &... -
Page 62: Reference Materials
Reference Materials A. Vent Components Diagrams Effective Length Pipe Inches Millimeters 10-1/2 in. DVP4 (267 mm) 45 ° Effective DVP6 Height/Length DVP12 DVP24 4-7/8 in. (124 mm) DVP36 10-7/8 in. DVP48 1219 (276 mm) DVP Pipe (see chart) DVP6A 3 to 6 76 to 152 DVP45 (45º... - Page 63 A. Vent Components Diagrams (continued) Note: Heat shields MUST overlap by a minimum of 1-1/2 in. (38 mm). The heat shield is designed to be used on a wall 4 in. to 7-1/4 in. (102 mm to 184 mm) thick. If wall thickness is less than 4 in. (102 mm) the existing heat shields must be field trimmed.
- Page 64 A. Vent Components Diagrams (continued) 31 in. (787 mm) 13-1/4 in. (337 mm) 24-5/8 in. (625 mm) 27-1/2 in. 24-5/8 in. (699 mm) (625 mm) 13-1/4 in. (337 mm) RF12 Roof Flashing Roof Flashing 11-7/8 in. 5 in. (302 mm) (127 mm) 13-7/8 in.
- Page 65 A. Vent Components Diagrams (continued) 7-3/8 in. (187 mm) 1-1/2 in. (38 mm) 12 in. 305 mm 14 in. 17-3/4 in. 7-1/4 in. (356 mm) (184 mm) (451 mm) 12-1/2 in. (318 mm) 6 in. 152 mm 5-1/4 in. (133 mm) 12 in.
- Page 66 A. Vent Components Diagrams (continued) 8-1/8 in. 13 in. (206 mm) (330 mm) Effective Length 5-1/2 in. 8-3/8 in. 5-3/4 to 8-3/8 in. 140 mm 213 mm 146 to 213 mm 3° 87° 15 in. (381 mm) 10-1/2 in. 267 mm 10-7/8 in.
- Page 67 A. Vent Components Diagrams (continued) Top View 6-1/4 IN. 159 mm 1-1/2 IN. 38 mm Front View Side View 2-1/4 IN. 15-1/2 IN. 57 mm 394 mm 4-3/4 IN. 121 mm 8 IN. 9-1/2 IN. 14 IN. 203 mm 241 mm 356 mm 5-1/4 IN.
- Page 68 A. Vent Components Diagrams (continued) 6-1/2 in. 165 mm 6-1/2 in. 165 mm 6-1/2 in. 165 mm 8-3/4 in. 9-1/4 in. 222 mm 6 in. 235 mm 152 mm 6-5/8 in. 168 mm 6-5/8 in. SLP45 168 mm 45° Elbow 9-7/8 in.
- Page 69 A. Vent Components Diagrams (continued) Note: Heat shields MUST overlap by a minimum of 1-1/2 in. (38 mm). The heat shield is designed to be used on a wall 4 in. to 7-1/4 in. (102 mm to 184 mm) thick. If wall thickness is less than 4 in. (102 mm) the existing heat shields must be field trimmed.
- Page 70 A. Vent Components Diagrams (continued) 12 in. 305 mm 14 in. 13 in. 356 mm 330 mm 12-1/2 in. 1-5/16 in. 318 mm 10-9/16 in. 13 in. 34 mm 269 mm 330 mm SLP-CCS-BK SLP-DCF-BK SLP-TVHW Cathedral Ceiling Ceiling Firestop Vertical Support Box-Black Black...
- Page 71 A. Vent Components Diagrams (continued) 8 IN. (203 mm) 15 IN. (381 mm) 12 IN. (305 mm) SLP-HHW2 Horizontal High Wind Termination Cap Figure 12.10 SLP series Vent Components COAXIAL to COLINEAR VENTING LINK-DV30B 768-380A DV-46DVA-GCL Flex Liner Kit Stainless Steel Flex Pipe Coaxial/Colinear Appliance Connector DVP-2SL Adapter...
-
Page 72: Accessories
B. Accessories Remote Controls, Wall Controls and Wall Switches Follow the instructions supplied with the control installed to operate your fi replace: For safety: • Install a switch lock or a wall/remote control with child protection lockout feature. • Keep remote controls out of reach of children. See your dealer if you have questions.
