Definition of Symbols:
Caution: Refer to Accompanying Documents
Caution: Risk of Electric Shock
Double Insulation
Over-voltage category III (CAT III): equipment in fixed installations.
WARNING: If the power analyzer is used in a manner not specified by the
manufacturer, the protection provided by the clamp meter may be impaired.
Please read the following instructions before use
1.
Do not operate this instrument in wet or dusty environments.
2.
Do not operate this instrument in the presence of combustible or explosive gas
3.
Do not touch exposed metal parts or unused terminals.
4.
Consider the use of rubber gloves in operation.
5.
Do not operate in excess of AC 500V (Phase to Neutral), or AC 600V (Phase to Phase)
6.
Do not operate this instrument if it appears to be malfunctioning
Do not use the flexible current probe before reading the following instructions.
1.
Do not install the flexible current probe around bare conductors carrying a voltage from
30V to 600V unless you are wearing protective clothing and glove suitable for
high-voltage work.
2.
Always inspect and check for any damage of the current probe assembly before usage.
Do not use the flexible current probe if any damage is found.
3.
Do not use the flexible current probe on circuit rated higher than 600V in installation
category III.
www.actoolsupply.com
EN 61010-2-032
CAT III 600V
Pollution Degree 2
www.actoolsupply.com
2
PQ3350 V5.2 11/10
