Chapter 7 Menu description tables

7-2 SYSTEM SETTING

7-2-1 SYSTEM MODE

Variable
Item
range
SYSTEM MODE
For AJ-HDX900E 1080-50i
For AJ-HDX900P 1080-59.94i
720-50P
720-59.94P
C U F
CAMERA MODE (1080-50i)
For AJ-HDX900E 50i
25P
(1080-59.94i)
For AJ-HDX900P 60i
30P
24P
24PA
(720-50P)
50P
25P
(720-59.94P)
60P
30P
24P
C U F R
<Note>
If the SYSTEM MODE item is changed while the time code is
advanced in the free-run mode (the TCG switch is set to the
F-RUN position.), the time code may not record properly.
When the SYTEM MODE item is changed and the power of
the unit is turned on again, check the time code and set it
again if necessary.

7-2-2 REC FUNCTION

Variable
Item
range
INTERVAL REC ON
MODE ONE SHOT
OFF
C U F
INTERVAL REC ON
HOLD OFF
C U F
The underlining in the variable range column indicates the setting in the preset
mode.
102
Downloaded From CamcorderManual.com Panasonic Manuals
Remarks
For setting the system frequency and the
recording format of the unit.
When this item is switched, turn "OFF" the
POWER switch on the unit and then turn it
"ON" again.
O When the remote control unit (AJ-RC10G)
is connected, this item is not displayed.
To switch this item, operate the main unit
independently.
For setting the video system for shooting.
Remarks
For setting the INTERVAL REC function.
ON:
For executing the interval recording.
It is possible to record in intervals in
increments of one frame.
ONE SHOT:
Recording is performed only once for the
time set in the REC TIME item, after
which it stops.
OFF:
Interval recording is not performed.
For details, refer to "3-5 Recording in
intervals (INTERVAL REC function)."
For setting whether the settings in the
INTERVAL REC MODE item are retained or
released, when the power is turned OFF.
ON: For retaining the settings in the
INTERVAL REC MODE item.
OFF: For releasing the settings in the
INTERVAL REC MODE item.
(continued)
Variable
Item
range
REC TIME
For 59.94 Hz 00s01f
:
59s29f
00s01f
For 50 Hz
:
59s24f
C U F
PAUSE TIME
For 59.94 Hz 00h00m00s01f
:
00h04m59s29f
:
23h59m59s29f
For 50 Hz
00h00m00s01f
:
00h04m59s24f
:
23h59m59s24f
C U F
TAKE TOTAL TIME NONE
:
5day
C U F
TOTAL REC TIME 00m00s01f
:
99m59s29f
OVER
100min
NONE
AUDIO REC OFF
ON
C U F
START DELAY 0SEC
:
10SEC
C U F
PRE REC MODE OFF
ON
C U F
PRE REC TIME 0SEC
:
7SEC
C U F
RETAKE MODE ON
OFF
F
Remarks
For setting the recording time (one cut).
O When the CAMERA MODE item is set to
24P or 24PA, the value is set in
increments of 5 frames (rounded down).
(Minimum value: 00s05f)
For setting the recording pause time.
O When the CAMERA MODE item is set to
24P or 24PA, the value is set in
increments of 5 frames (rounded down).
(Minimum value: 00h00m00s05f)
For setting the time required for shooting.
Select a setting from NONE (shooting
continues until it is stopped manually) to
5DAY (5 days).
For displaying the total recording time. The
setting for this time cannot be changed.
The total time yielded by adding the REC
TIME, PAUSE TIME and TOTAL TAKE
TIME is displayed.
O This indication is just a guide for the
recording time. It is impossible to record
for a period longer than the recording time
of the tape.
For setting the availability of audio records
during INTERVAL REC.
For setting the time taken until recording is
to start after the REC START button is
pressed in the INTERVAL REC mode.
For setting the PRE RECORDING function.
OFF: Recording starts about 0.4 seconds
after pressing the REC START button
or the VTR button on the lens.
ON: The PRE RECORDING function is
activated.
For details, refer to "3-4 To record video
signals of a few seconds before starting
recording (PRE-RECORDING function)."
For setting the length of time for which the
video and audio signals can be recorded
before the REC START button is pressed in
PRE RECORDING.
For setting the RETAKE function.
ON: The RETAKE function is activated.
OFF: The RETAKE function is not activated.
It returns to OFF once the power is turned
off.
For details, refer to "3-6 To take the previous
cut again (RETAKE function)."
