PROFILE-150 AXIAL EXTRACTOR FANS
Suitable for kitchen applications

INSTALLATION

IMPORTANT: before installing and wiring the unit, ensure that the mains supply is
disconnected.
PROFILE-150 should only be used in conjunction with fixed wiring.
Fig.1
The PROFILE-150 is suitable for panel, ceiling or wall mounting (for wall mounting
applications using EnviroVent wall kit) (fig. 2).
Drill 160mm-diameter hole in chosen position in the panel, ceiling or wall. The hole for
•
the duct should be angled downwards to prevent rainwater running through the duct into
the unit.
Loosen the screw (4), which holds the grille in place (1) and remove grille.
•
Place the extractor against the internal wall or ceiling. For a wall mounted fan the
•
terminal block should be at the top. Mark the 4 screw hole positions. Drill, plug and
screw the extractor in position.
Check that the wall tube is not distorted and that the impeller turns freely.
•
This fan must be installed by a competent person. Complete electrical wiring of fan as
•
outlined in the Wiring Instructions below. Then refit the grille and tighten the screw (2).
1 – Grille
2 – Cable entry point
3 – Outlet
4 – Fixing screw for front cover
5 – Connection terminals
