External And Internal Sirens; Programming The E12; Button Key Ring Remote - CellSecure E12 CLEO User Manual

when connected to mains power. The battery will be fully charged within 24 hrs. The
PSU also sends a Mains On/Off signal when the transformer is connected to - or
disconnected from the Mains.
PLEASE NOTE: THE E12 CLEO CAN ONLY POWER 12 WIRED
DEVICES OF BETWEEN 20 AND 100 MILLIAMPS EACH.
FOR ADDITIONAL DEVICES AN EXTRA POWER SUPPLY IS NEEDED.

2.4. External and internal sirens

The sirens will sound when the alarm is activated, deactivated or triggered as described
in the previous section.
Figure 9.
15Watt external siren (left), 40Watt external siren (middle) and indoor siren (right).
3. Programming the E12 Cleo
For new installations:
Press and hold the Learn button on the E12 Cleo until the LED switches off. (18 sec )
KEYRINGS AND DEVICES NEED TO BE READ INTO THE RECEIVER
FIRST.
3.1. Learning in Key rings and Sensors

3.1.1. 3 Button Key Ring Remote

1. Press the Learn Button on the Control Panel the Learn LED should switch on.
2. Press the Yellow Button on the 3 Button Remote Control and hold for 3 sec.
3. The Control Panel Learn LED may switch off.
4. The Control Panel Learn LED should flash and then stop.
5. To add more Remotes follow steps 1 – 4.
6. To program a remote to 1 of the 12 slots allocated follow the steps in section 3.2
of this document.
17
