Schenker XIRIOS D501 Service Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XIRIOS D501 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Schenker XIRIOS D501

Summary of Contents for Schenker XIRIOS D501

  • Page 2: Instructions For Care And Operation

    Preface Instructions for Care and Operation The notebook computer is quite rugged, but it can be damaged. To prevent this, follow these suggestions: Don’t drop it, or expose it to shock. If the computer falls, the case and the components could be damaged. Do not expose the computer Do not place it on an unstable Do not place anything heavy...

  • Page 3: Power Safety

    Preface Avoid interference. Keep the computer away from high capacity transformers, electric motors, and other strong mag- netic fields. These can hinder proper performance and damage your data. Take care when using peripheral devices. Use only approved brands of Unplug the power cord before peripherals.

  • Page 4: Battery Precautions

    Preface Battery Precautions • Only use batteries designed for this computer. The wrong battery type may explode, leak or damage the computer. • Do not continue to use a battery that has been dropped, or that appears damaged (e.g. bent or twisted) in any way. Even if the computer continues to work with a damaged battery in place, it may cause circuit damage, which may possibly result in fire.

  • Page 5: Related Documents

    Preface Related Documents You may also need to consult the following manual for additional information: User’s Manual on CD/DVD This describes the notebook PC’s features and the procedures for operating the computer and its ROM-based setup pro- gram. It also describes the installation and operation of the utility programs provided with the notebook PC. System Startup 1.

  • Page 6: Specifications

    Introduction Specifications Processor Options W350HU: 15.6" (39.62) HD/HD+ TFT LCD Intel® Core™ i7 Processor Memory  i7-2620M (2.7GHz) 4MB L3 Cache, 32nm, DDR3-1333MHz, TDP 35W Two 204 Pin SO-DIMM Sockets Supporting DDR3 1333MHz Latest Specification Information Memory Intel® Core™ i5 Processor Memory Expandable up to 8GB The specifications listed here are correct at the i5-2540M (2.6GHz), i5-2520M (2.5GHz), i5-2410M (2.3GHz)
  • Page 7 Introduction Audio Communication High Definition Audio Compliant Interface Built-In Gigabit Ethernet LAN 2 * Built-In Speakers (Factory Option) 1.3M/2.0M Pixel USB PC Camera Module Built-In Microphone (Factory Option) 3.75G/HSPA Mini-Card Module W350HU: Interface (Factory Option) Intel® Centrino® Advanced-N 6230 Wire- One Powered USB 2.0 Port less LAN (802.11a/g/n) + Bluetooth 3.0 Two USB 3.0 Ports...

  • Page 8: External Locator - Top View With Lcd Panel Open

    Introduction External Locator - Top View with LCD Panel Open Figure 1 Top View 1. Built-In PC Ca- mera 2. LCD 3. Speakers 4. Power Button 5. Hot Key Buttons 6. Keyboard 7. Built-In Microphone 8. Touchpad & Buttons 9. Fingerprint Reader 10.LED Indicators 1 - 4 External Locator - Top View with LCD Panel Open...

  • Page 9: External Locator - Front & Right Side Views

    Introduction External Locator - Front & Right Side Views Figure 2 Front View 1. LED Indicators FRONT VIEW Figure 3 RIGHT SIDE VIEW Right Side View 1. S/PDIF-Out Jack 2. Microphone-In Jack 3. Headphone-Out Jack 4. Powered USB  2.0 Port (see note below) 5.

  • Page 10: External Locator - Left Side & Rear View

    Introduction External Locator - Left Side & Rear View Figure 4 Left Side View 1. DC-In Jack 2. External Monitor Port LEFT SIDE VIEW 3. RJ-45 LAN Jack 4. e-SATA Port/USB 2.0 Combo Port 5. HDMI-Out Port 6. Vent 7. 2 * USB 3.0 Ports 8.

  • Page 11: External Locator - Bottom View

    Introduction External Locator - Bottom View Figure 6 Bottom View 1. Battery 2. Docking Port 3. Component Bay Cover 4. Vent 5. Hard Disk Bay Cover  Overheating To prevent your com- puter from overhea- ting, make sure no- thing blocks any vent while the computer is in use.

  • Page 12: Maintenance Tools

    Disassembly NOTE: All disassembly procedures assume that the system is turned OFF, and disconnected from any power supply (the battery is removed too). Maintenance Tools The following tools are recommended when working on the notebook PC: • M3 Philips-head screwdriver •...

  • Page 13: Maintenance Precautions

    Disassembly Maintenance Precautions  The following precautions are a reminder. To avoid personal injury or damage to the computer while performing a re- moval and/or replacement job, take the following precautions: Power Safety Warning 1. Don't drop it. Perform your repairs and/or upgrades on a stable surface. If the computer falls, the case and other Before you undertake components could be damaged.

  • Page 14: Removing The Battery

    Disassembly Removing the Battery Figure 1 Battery Removal 1. Turn the computer off, and turn it over. 2. Slide the latch in the direction of the arrow (Figure 1a a. Slide the latch and hold in 3. Slide the latch in the direction of the arrow, and hold it in place (Figure 1a place.

  • Page 15: Removing The Hard Disk Drive

    Disassembly Removing the Hard Disk Drive Figure 2 HDD Assembly The hard disk drive can be taken out to accommodate other 2.5" serial (SATA) hard disk drives with a height of 9.5mm Removal (h). Follow your operating system’s installation instructions, and install all necessary drivers and utilities (as outlined in Chapter 4 of the User’s Manual) when setting up a new hard disk.
  • Page 16 Disassembly 3. Remove the hard disk bay cover (Figure 3b Figure 3 4. Grip the tab and slide the hard disk in the direction of arrow (Figure 3c HDD Assembly 5. Lift the hard disk out of the bay (Figure 3d Removal (cont’d.) 6.

  • Page 17: Removing The System Memory (Ram)

    Disassembly Removing the System Memory (RAM) Figure 4 RAM Module The computer has two memory sockets for 204 pin Small Outline Dual In-line Memory Modules (SO-DIMM) supporting Removal DDR3 1066/1333MHz. The main memory can be expanded up to 8GB. The SO-DIMM modules supported are 1024MB, and 2048MB and DDRIII Modules.
  • Page 18 Disassembly 5. Gently pull the two release latches ( on the sides of the memory socket in the direction indicated by the Figure 5 arrows (Figure 5c). RAM Module Removal (cont’d.) c. Pull the release latches. d. Remove the module(s). 6.

  • Page 19: Removing The Optical (Cd/Dvd) Device

    Disassembly Removing the Optical (CD/DVD) Device Figure 6 Optical Device 1. Turn off the computer, remove the battery (page 2 - 5) and the component bay cover (page 2 - Removal 2. Remove the screw at point (Figure 6a , and use a screwdriver to carefully push out the optical device point (Figure 6b a.

  • Page 20: Removing The Wireless Lan Module

    Disassembly Removing the Wireless LAN Module Figure 10 Wireless LAN 1. Turn off the computer, remove the battery (page 2 - 5) and the component bay cover (page 2 - Module Removal 2. The Wireless LAN module will be visible at point (Figure 10a on the mainboard.

  • Page 21: Removing The Keyboard

    Disassembly Removing the Keyboard Figure 11 Keyboard Removal 1. Turn off the computer and remove the battery (page 2 - & 2. Remove screws and use a screwdriver to carefully push out the top cover module at point (Figure a. Remove the screws and 11a).

  • Page 22: Removing The 3.75G Module

    Disassembly Removing the 3.75G Module Figure 12 3G Module Removal 1. Turn off the computer, turn it over, and remove the battery (page 2 - 5) and the component bay cover (page 2 - 14). a. Locate the 3.75G mod- 2.
  • Page 23 Disassembly 6. Remove screws & from the module and disconnect cable (Figure 14d). Figure 14 7. Carefully lift the modem up and off the socket (Figure 14e). Modem Removal (cont’d.) d. Remove the screws and disconnect cable from the module. e.
