Summary of Contents for Schenker xirios d301
-
Page 2: Instructions For Care And Operation
Preface Instructions for Care and Operation The notebook computer is quite rugged, but it can be damaged. To prevent this, follow these suggestions: Don’t drop it, or expose it to shock. If the computer falls, the case and the components could be damaged. Do not expose the computer Do not place it on an unstable Do not place anything heavy... -
Page 3: Power Safety
Preface Avoid interference. Keep the computer away from high capacity transformers, electric motors, and other strong mag- netic fields. These can hinder proper performance and damage your data. Take care when using peripheral devices. Use only approved brands of Unplug the power cord before peripherals. -
Page 4: Battery Precautions
Preface Battery Precautions • Only use batteries designed for this computer. The wrong battery type may explode, leak or damage the computer. • Do not continue to use a battery that has been dropped, or that appears damaged (e.g. bent or twisted) in any way. Even if the computer continues to work with a damaged battery in place, it may cause circuit damage, which may possibly result in fire. -
Page 5: Related Documents
Preface Related Documents You may also need to consult the following manual for additional information: User’s Manual on CD/DVD This describes the notebook PC’s features and the procedures for operating the computer and its ROM-based setup pro- gram. It also describes the installation and operation of the utility programs provided with the notebook PC. System Startup 1. -
Page 6: What To Do If You Spill Liquid On The Computer
Preface What to do if you Spill Liquid on the Computer The keyboard incorporates a drainage system that minimizes the chances of liquid spillages on the keyboard penetrating the inside components of the computer. Liquid spilled on the computer is drained towards the right side of the computer. There is no guarantee that all water can be prevented from entering the computer, and damage resulting from spillages is not covered in the warranty. -
Page 7: Specifications
Introduction Specifications Processor Options Core Logic W130HU: W130HU: Intel® Core™ i7 Processor Intel® HM65 Chipset i7-2640M (2.80GHz), i7-2620M (2.70GHz) W130HV: 4MB L3 Cache, 32nm, DDR3-1333MHz, TDP 35W Intel® QM67 Chipset Latest Specification Information Intel® Core™ i5 Processor i5-2540M (2.60GHz), i5-2520M (2.50GHz), Memory The specifications listed here are correct at the time of sending them to the press. - Page 8 Introduction Keyboard Pointing Device Isolated A4 Size Keyboard with Anti-Spray Support Built-in Touchpad (scrolling key functionality integrated) Interface Card Reader One Powered USB 2 .0 Port (see page Embedded Multi-in-1 Card Reader Two USB 3.0 Ports MMC (MultiMedia Card) / RS MMC One eSATA/USB 2.0 Combo Port SD (Secure Digital) / Mini SD / SDHC/ SDXC One HDMI-Out Port...
-
Page 9: External Locator - Top View With Lcd Panel Open
Introduction External Locator - Top View with LCD Panel Open Figure 1 Top View 1. PC Camera (Optional) 2. LCD 3. Power Button 4. Keyboard 5. Built-In Microphone 6. Touchpad & Buttons 7. Fingerprint Reader 8. LED Status Indicators 1 - 4 External Locator - Top View with LCD Panel Open... -
Page 10: External Locator - Front & Right Side Views
Introduction External Locator - Front & Right Side Views Figure 2 Front View 1. LED Power Indicator 2. WLAN Switch FRONT VIEW Figure 3 Right Side View 1. Microphone-In RIGHT SIDE VIEW Jack 2. Headphone-Out Jack 3. USB 2.0 Port 4. -
Page 11: External Locator - Left Side & Rear View
Introduction External Locator - Left Side & Rear View Figure 4 Left Side View 1. DC-In Jack 2. External Monitor Port LEFT SIDE VIEW 3. RJ-45 LAN Jack 4. e-SATA Port/USB 2.0 Combo Port 5. HDMI-Out Port 6. 2 * USB 3.0 Ports 7. -
Page 12: External Locator - Bottom View
Introduction External Locator - Bottom View Figure 6 Bottom View 1. Battery 2. Docking Port 3. Vent 4. Component Bay Cover 5. Drainage Outlet 6. Speakers Overheating To prevent your com- puter from overhea- ting, make sure no- thing blocks any vent while the computer is in use. -
Page 13: Maintenance Tools
Disassembly NOTE: All disassembly procedures assume that the system is turned OFF, and disconnected from any power supply (the battery is removed too). Maintenance Tools The following tools are recommended when working on the notebook PC: • M3 Philips-head screwdriver •... -
Page 14: Maintenance Precautions
Disassembly Maintenance Precautions The following precautions are a reminder. To avoid personal injury or damage to the computer while performing a re- moval and/or replacement job, take the following precautions: Power Safety Warning 1. Don't drop it. Perform your repairs and/or upgrades on a stable surface. If the computer falls, the case and other Before you undertake components could be damaged. -
Page 15: Removing The Battery
Disassembly Removing the Battery Figure 1 Battery Removal 1. Turn the computer off, and turn it over. 2. Slide the latch in the direction of the arrow (Figure 1a a. Slide the latch and hold it 3. Slide the latch in the direction of the arrow, and hold it in place (Figure 1a in place. -
Page 16: Removing And Installing The Hard Disk Drive
Disassembly Removing and Installing the Hard Disk Drive Figure 2 HDD Assembly Hdd Removal Procedure Removal The hard disk drive can be taken out to accommodate other 2.5" serial (SATA) hard disk drives with a height of 9.5mm (h). Follow your operating system’s installation instructions, and install all necessary drivers and utilities (as outlined in a. - Page 17 Disassembly 5. Raise the plastic tab Figure 3 6. Slide the hard disk assembly in the direction of arrow until you can see the (gold colored) HDD connector HDD Assembly 7. When the connector can be viewed, lift the assembly up in the direction of arrow remove the HDD assembly Removal (cont’d.) from the bay.
- Page 18 Disassembly Reinserting the HDD Figure 4 1. To reinsert the HDD assembly hold it carefully at the four corners between your thumb and forefinger and Insert HDD Installation the HDD directly down into the bay vertically (Figure 1a 2. Press and slide the HDD assembly at the area illustrated (do not press on the center area - see sidebar) the a.
-
Page 19: Removing The System Memory (Ram)
Disassembly Removing the System Memory (RAM) Figure 5 RAM Module The computer has two memory sockets for 204 pin Small Outline Dual In-line Memory Modules (SO-DIMM) supporting Removal DDRIII (DDR3) Up to 1333 MHz. The main memory can be expanded up to 8GB. The SO-DIMM modules supported are 1024MB and 2048MB DDRIII Modules. -
Page 20: Removing The 3.75G Module
Disassembly Removing the 3.75G Module Figure 9 3G Module Removal 1. Turn off the computer, turn it over, and remove the battery (page 2 - 5) and the component bay cover (page 2 - 2. The 3.75G module will be visible at point on the mainboard (Figure 9a). -
Page 21: Removing The Wireless Lan Module
Disassembly Removing the Wireless LAN Module Figure 10 Wireless LAN 1. Turn off the computer, turn it over, and remove the battery (page 2 - 5) and the component bay cover (page 2 - Module Removal 2. The Wireless LAN module will be visible at point on the mainboard (Figure 10a). -
Page 22: Removing The Keyboard
Disassembly Removing the Keyboard Figure 11 Keyboard Removal 1. Turn off the computer remove the battery (page 2 - 5), and the component bay cover (page 2 - 2. Remove screws from the bottom of the computer. a. Remove screws from the bottom of the computer.
