  • Page 2: Instructions For Care And Operation

    Preface Instructions for Care and Operation The notebook computer is quite rugged, but it can be damaged. To prevent this, follow these suggestions: Don’t drop it, or expose it to shock. If the computer falls, the case and the components could be damaged. Do not expose the computer Do not place it on an unstable Do not place anything heavy...

  • Page 3: Power Safety

    Preface Avoid interference. Keep the computer away from high capacity transformers, electric motors, and other strong mag- netic fields. These can hinder proper performance and damage your data. Take care when using peripheral devices. Use only approved brands of Unplug the power cord before peripherals.

  • Page 4: Battery Precautions

    Preface Battery Precautions • Only use batteries designed for this computer. The wrong battery type may explode, leak or damage the computer. • Do not continue to use a battery that has been dropped, or that appears damaged (e.g. bent or twisted) in any way. Even if the computer continues to work with a damaged battery in place, it may cause circuit damage, which may possibly result in fire.

  • Page 5: Related Documents

    Preface Related Documents You may also need to consult the following manual for additional information: User’s Manual on CD/DVD This describes the notebook PC’s features and the procedures for operating the computer and its ROM-based setup pro- gram. It also describes the installation and operation of the utility programs provided with the notebook PC. System Startup 1.

  • Page 6: Specifications

    Introduction Specifications Processor Options BIOS Intel® Core™ i7 Processor One 48Mb SPI Flash ROM i7-3820QM (2.70GHz) AMI BIOS 8MB L3 Cache, 22nm, DDR3-1600MHz, TDP 45W  i7-3720QM (2.60GHz), i7-3610QM (2.30GHz) Latest Specification Information 6MB L3 Cache, 22nm, DDR3-1600MHz, TDP 45W 15.6"...
  • Page 7 Introduction Audio Communication Power High Definition Audio Compliant Interface Built-In Gigabit Ethernet LAN Full Range AC/DC Adapter THX TruStudio Pro AC Input: 100 - 240V, 50 - 60Hz (Factory Option) 1.3M/2.0M Pixel USB PC Camera Module 2 * Built-In Speakers DC Output: 19V, 6.3A (120W) (Factory Option) 3.75G/HSPA Mini-Card Module (Model A Built-In Microphone...

  • Page 8: External Locator - Top View With Lcd Panel Open

    Introduction External Locator - Top View with LCD Panel Open Figure 1 Top View 1. PC Camera (Optional) 2. LCD 3. Power Button 4. GPU Button 5. LED Indicators 6. Hot Key Buttons 1 5 .6 ” (3 9 .6 2 c m ) 7.

  • Page 9: External Locator - Front & Right Side Views

    Introduction External Locator - Front & Right Side Views Figure 2 Front View 1. LED Indicators FRONT VIEW Figure 3 Right Side View 1. Headphone-Out RIGHT SIDE VIEW Jack 2. Microphone-In Jack 3. S/PDIF-Out Jack 4. USB 2.0 Port 5. Optical Device Drive Bay 6.

  • Page 10: External Locator - Left Side & Rear View

    Introduction External Locator - Left Side & Rear View Figure 4 Left Side View 1. DC-In Jack 2. Vent 3. External Monitor LEFT SIDE VIEW Port 4. RJ-45 LAN Jack 5. 2 * USB 3.0 Ports 6. HDMI-Out Port 7. Multi-in-1 Card Reader 8.

  • Page 11: External Locator - Bottom View

    Introduction External Locator - Bottom View Figure 6 Bottom View 1. Battery 2. Component Bay Cover 3. Vent 4. Speakers  Overheating To prevent your com- puter from overhea- ting, make sure no- thing blocks any vent while the computer is in use.

  • Page 12: Maintenance Tools

    Disassembly NOTE: All disassembly procedures assume that the system is turned OFF, and disconnected from any power supply (the battery is removed too). Maintenance Tools The following tools are recommended when working on the notebook PC: • M3 Philips-head screwdriver •...

  • Page 13: Maintenance Precautions

    Disassembly Maintenance Precautions  The following precautions are a reminder. To avoid personal injury or damage to the computer while performing a re- moval and/or replacement job, take the following precautions: Power Safety Warning 1. Don't drop it. Perform your repairs and/or upgrades on a stable surface. If the computer falls, the case and other Before you undertake components could be damaged.

  • Page 14: Removing The Battery

    Disassembly Removing the Battery Figure 1 Battery Removal 1. Turn the computer off, and turn it over. 2. Slide the latch in the direction of the arrow (Figure 1a a. Slide the latch and hold it 3. Slide the latch in the direction of the arrow, and hold it in place (Figure 1a in place.
  • Page 15 Disassembly 5. Gently pull the two release latches ( & ) on the sides of the memory socket in the direction indicated by the Figure 3 arrows (Figure 3d). The RAM module will pop-up Figure 3e , and you can then remove it RAM Module 6.

  • Page 16: Removing The Hard Disk Drive

    Disassembly Removing the Hard Disk Drive The hard disk drive can be taken out to accommodate other 2.5" serial (SATA) hard disk drives with a height of 9.5mm Figure 4 (h). Follow your operating system’s installation instructions, and install all necessary drivers and utilities (as outlined in HDD Assembly Chapter 4 of the User’s Manual) when setting up a new hard disk.
  • Page 17 Disassembly 4. Remove the hard disk bay cover (Figure 5c Figure 5 5. Grip the tab and slide the 1st hard disk assembly in the direction of arrow (Figure 5d HDD Assembly 6. Lift the 1st hard disk assembly out of the bay (Figure 5e Removal (cont’d.) 7.
  • Page 18 Disassembly 8. Remove screws from the 2nd hard disk assembly (Figure 6g Figure 6 9. Slide the 2nd hard disk in the direction of arrow (Figure 6h HDD Assembly 10. Lift the 2nd hard disk assembly out of the bay (Figure 6i Removal (cont’d.) 11.

  • Page 19: Removing The Optical (Cd/Dvd) Device

    Disassembly Removing the Optical (CD/DVD) Device Figure 7 Optical Device 1. Turn off the computer, remove the battery (page 2 - 5) and hard disk (page 2 - Removal 2. Remove the screw at point (Figure 7a 3. Use a screwdriver to carefully push out the optical device at point (Figure 7b a.

  • Page 20: Removing The Wireless Lan Module

    Disassembly Removing the Wireless LAN Module Figure 11 Wireless LAN 1. Turn off the computer, turn it over, and remove the battery (page 2 - 5) and the component bay cover (page 2 - Module Removal 2. The Wireless LAN module will be visible at point on the mainboard (Figure 11a).

  • Page 21: Removing The Keyboard

    Disassembly Removing the Keyboard Figure 12 Keyboard Removal 1. Turn off the computer, and remove the battery (page 2 - a. Remove screws from the 2. Remove screws from the bottom of the computer. Press at point to unsnap the LED cover module (you bottom of the computer.
