  • Page 2: Instructions For Care And Operation

    Preface Instructions for Care and Operation The notebook computer is quite rugged, but it can be damaged. To prevent this, follow these suggestions: Don’t drop it, or expose it to shock. If the computer falls, the case and the components could be damaged. Do not expose the computer Do not place it on an unstable Do not place anything heavy...

  • Page 3: Power Safety

    Preface Avoid interference. Keep the computer away from high capacity transformers, electric motors, and other strong mag- netic fields. These can hinder proper performance and damage your data. Take care when using peripheral devices. Use only approved brands of Unplug the power cord before peripherals.

  • Page 4: Battery Precautions

    Preface Battery Precautions • Only use batteries designed for this computer. The wrong battery type may explode, leak or damage the computer. • Do not continue to use a battery that has been dropped, or that appears damaged (e.g. bent or twisted) in any way. Even if the computer continues to work with a damaged battery in place, it may cause circuit damage, which may possibly result in fire.

  • Page 5: Related Documents

    Preface Related Documents You may also need to consult the following manual for additional information: User’s Manual on CD/DVD This describes the notebook PC’s features and the procedures for operating the computer and its ROM-based setup pro- gram. It also describes the installation and operation of the utility programs provided with the notebook PC. System Startup 1.

  • Page 6: Specifications

    Introduction Specifications Processor Options Memory Intel® Core™ i7 Processor Four 204 Pin SO-DIMM Sockets Supporting DDR3L 1600MHz Memory i7-4980HQ (2.80GHz), i7-4870HQ (2.50GHz), i7-4710HQ (2.50GHz) (The real memory operating frequency depends on the FSB  6MB L3 Cache, 22nm, DDR3L-1600MHz, TDP 47W of the processor.) Latest Specification Information Memory Expandable from 4GB (minimum) up to 32GB...
  • Page 7 Introduction Audio Communication High Definition Audio Compliant Interface Built-In Gigabit Ethernet LAN S/PDIF Digital Output 2.0M FHD PC Camera Module Two Speakers (Factory Option) M.2 3G/4G Module Sound Blaster Audio WLAN/ Bluetooth M.2 Modules: ANSP ™ 3D sound technology on headphone output (Factory Option) Intel®...

  • Page 8: External Locator - Top View With Lcd Panel Open

    Introduction External Locator - Top View with LCD Panel Open Figure 1 Top View 1. PC Camera 2. *PC Camera LED *When the PC camera is in use, the LED will be illuminated. 3. Built-In Array Microphone 4. LCD 5. Speakers 6.

  • Page 9: External Locator - Front & Right Side Views

    Introduction External Locator - Front & Right Side Views Figure 2 Front View 1. LED Indicator FRONT VIEW Figure 3 Right Side View 1. S/PDIF-Out Jack RIGHT SIDE VIEW 2. Microphone-In Jack 3. Headphone-Out Jack 4. Multi-in-1 Card Reader 5. USIM Card Reader (for 3G/ 4G USIM Cards) 6.

  • Page 10: External Locator - Left Side & Rear View

    Introduction External Locator - Left Side & Rear View Figure 4 Left Side View 1. Vent 2. HDMI-Out Port 3. Powered USB 3.0 LEFT SIDE VIEW Port 4. Mini DisplayPorts Figure 5 REAR VIEW Rear View 1. Vent 2. DC-In Jack 3.

  • Page 11: External Locator - Bottom View

    Introduction External Locator - Bottom View Figure 6 Bottom View 1. Vent  Overheating To prevent your com- puter from overhea- ting, make sure no- thing blocks any vent while the computer is in use. External Locator - Bottom View 1 - 7...

  • Page 12: Maintenance Tools

    Disassembly NOTE: All disassembly procedures assume that the system is turned OFF, and disconnected from any power supply (the battery is removed too). Maintenance Tools The following tools are recommended when working on the notebook PC: • M3 Philips-head screwdriver •...

  • Page 13: Maintenance Precautions

    Disassembly Maintenance Precautions  The following precautions are a reminder. To avoid personal injury or damage to the computer while performing a re- moval and/or replacement job, take the following precautions: Power Safety Warning 1. Don't drop it. Perform your repairs and/or upgrades on a stable surface. If the computer falls, the case and other Before you undertake components could be damaged.

  • Page 14: Removing The Keyboard

    Disassembly Removing the Keyboard Figure 1 Keyboard Removal 1. Turn off the computer, turn it over. 2. Remove screws from the bottom of the computer. a. Remove the screws from 3. Open it up with the LCD on a flat surface before pressing at point to release the keyboard module (use the spe- the bottom of the compu- cial eject stick...

  • Page 15: Removing The Battery

    Disassembly Removing the Battery Figure 2 Battery Removal 1. Turn the computer off, and turn it over. 2. Remove the SD card cover and screws (Figure 2a). a. Remove the SD cover 3. Carefully lift the bottom case up in the direction of the arrow and remove it (Figure 2b and screws.
  • Page 16 Disassembly 5. Carefully disconnect the cable , then remove screws (Figure 3b Figure 3 6. Lift the battery off the computer (Figure 3e Battery Removal 7. Reinsert the bottom case starting from point as shown (Figure 3f) to avoid damaging the rear eSATA/USB 3.0 (cont’d.) port.

  • Page 17: Removing The Hard Disk Drive

    Disassembly Removing the Hard Disk Drive Figure 4 HDD Assembly The hard disk drive can be taken out to accommodate other 2.5" serial (SATA) hard disk drives with a height of 9.5mm Removal or 7mm (h). Follow your operating system’s installation instructions, and install all necessary drivers and utilities (as outlined in Chapter 4 of the User’s Manual) when setting up a new hard disk.
  • Page 18 Disassembly 4. Slightly lift and pull the hard disk in the direction of arrow (Figure 5c Figure 5 5. Lift the hard disk assembly out of the bay (Figure 5d HDD Assembly 6. Remove screws and bracket from the hard disk (Figure 5e Removal (cont’d.) 7.

  • Page 19: Removing The System Memory (Ram)

    Disassembly Removing the System Memory (RAM) Figure 6 RAM-1 Module The computer has two memory sockets for 204 pin Small Outline Dual In-line Memory Modules (SO-DIMM) supporting Removal DDR3L Up to 1600 MHz. The main memory can be expanded up to 16GB. The SO-DIMM modules supported are 1024MB and 2048MB DDR3L Modules.
  • Page 20 Disassembly 4. Gently pull the two release latches ( & ) on the sides of the memory socket in the direction indicated by the Figure 7 arrows (Figure 8c). The RAM module will pop-up Figure 8d , and you can then remove it RAM-1 Module 5.

  • Page 21: Memory-2 Upgrade Process

    Disassembly Memory-2 Upgrade Process Figure 8 RAM-2 Module 1. Turn off the computer, turn it over, remove the battery (page 2 - Removal 2. The RAM-2 modules will be visible at point on the mainboard (Figure 8a 3. Gently pull the two release latches ( &...

  • Page 22: Removing The M.2 Ssd Module

    Disassembly Removing the M.2 SSD Module Figure 9 M.2 SSD Module 1. Turn off the computer, turn it over, remove the battery (page 2 - Removal 2. The M.2 SSD module will be visible at point on the mainboard (Figure 9a).

  • Page 23: Removing The Wireless Lan Module

    Disassembly Removing the Wireless LAN Module Figure 10 Wireless LAN 1. Turn off the computer, turn it over, remove the battery (page 2 - Module Removal 2. The Wireless LAN module will be visible at point on the mainboard (Figure 10a).

  • Page 24: Wireless Lan, Combo, 3G & Lte Module Cables

    Disassembly Wireless LAN, Combo, 3G & LTE Module Cables Note that the cables for connecting to the antennae on WLAN, WLAN & Bluetooth Combo, 3G and LTE modules are not labelled. The cables/covers (each cable will have either a black or transparent cable cover) are color coded for iden- tification as outlined in the table below.

  • Page 25: Removing And Installing The 3G / Sata Module

    Disassembly Removing and Installing the 3G / SATA Module Figure 11 3G Removal Procedure 3G Module Removal 1. Turn off the computer, remove the battery (page 2 - a. Locate the module. 2. Locate the module, it is visible at point Figure 11a b.
  • Page 26 Disassembly SATA Removal Procedure Figure 12 1. Turn off the computer, remove the battery (page 2 - SATA Module 2. Locate the module, it is visible at point Figure 12a Removal 3. Remove the screw from the module Figure 12b 4.
  • Page 27 Disassembly 3G / SATA Installation Procedure Figure 13 3G / SATA Module 1. Place the thermal pad on the module as shown (Figure 13a). 2. Insert the module in the computer Figure 13b Installation 3. Tighten the screw to secure it in place (Figure 13c).
