1 - Amber 2 - Green
Off
Off
Flashing once
Off
every 2 seconds
Flashing once
Off
per second
Off
Off
Off
Off
On
Off
Flashing once
Off
per second
On
Off
Flashing once
Flashing once
per second
per second
Flashing once
Flashing once
per second
per second
On
Flashing once
per second
Flashing twice
Flashing twice
per second
per second
Flashing twice
Flashing twice
per second
per second
On
On
On
On
3 - Green Interpretation
Off The cache module is not powered.
Flashing once The cache microcontroller is executing from within its
every 2 seconds boot loader and receiving new flash code from the host
controller.
Flashing once The cache module is powering up, and the battery
per second pack is charging.
Flashing once The cache module is idle, and the battery pack is
per second charging.
On The cache module is idle, and the battery pack is
charged.
On The cache module is idle, the battery pack is charged,
and the cache contains data that has not yet been
written to the drives.
Off A backup of the DDR content on the cache module is
in progress.
Off The current backup is complete with no errors.
Off The current backup failed, and data has been lost.
On A power error occurred during the previous or current
boot. Data may be corrupt.
Off An overtemperature condition exists.
Off The battery pack is not attached.
On The battery has been charging for 10 minutes, but has
not reached sufficient charge to perform a full backup.
Off The current backup is complete, but power
fluctuations occurred during the backup.
On The cache module microcontroller has failed.
