of Standards and Technology website
(http://csrc.nist.gov/groups/STM/cmvp/documents/fips140-2/FIPS1402IG.pdf).
For more information about Smart Array P830 Controller, see the Secure Encryption Installation and User
Guide on the Hewlett Packard Enterprise website (http://www.hpe.com/info/smartstorage/docs).

Supported servers

For more information on installing the controller in a supported server, see the server user guide.
For the latest support information, see the controller QuickSpecs on the Hewlett Packard Enterprise
website (http://www.hpe.com/info/qs).

Controller specifications

Feature
Controller
Board type
Dimensions, cm*
Dimensions, in*
I/O connection to
the system board
Maximum power
required
(approximate)
Internal SAS
connector life
expectancy
Cache module
and battery
Cache module
Time required to
recharge battery
Duration of battery
backup
Battery life
expectancy
Drives
Supported drive
types**
Maximum number
of logical drives
Description
Full-height, 1/2 length, PCIe stand-up board
16.8 x 11.1 x 1.8
6.6 x 4.4 x 0.7
PCIe3 x8 edge connector
14.5 W
250 connect/disconnect cycles
4 GiB FBWC
Approximately 200 MB from the cache module is
required to run the controller firmware. The remainder of
the available space can be configured for read-ahead or
write back caching.
5 minutes or less
80 seconds
The battery pack provides a sufficient duration to transfer
the cached data from DDR memory to flash memory,
where the data remains indefinitely or until a controller
retrieves the data.
More than 3 years
•
6 Gb/s SAS
•
6 Gb/s SATA
•
12 Gb/s SAS
Not all servers or storage systems support all SAS or
SATA drive types. For product-specific drive support,
see the product QuickSpecs on the Hewlett Packard
Enterprise website (http://www.hpe.com/info/qs).
64
