- Page 1 AT-ANC10S/2 10 Gigbit Network Interface Card Installation and User’s Guide 613-002022 Rev. B...
- Page 2 Allied Telesis, Inc. has been advised of, known, or should have known, the...
- Page 3 European Union Restriction of the Use of Certain Hazardous Substances (RoHS) in Electrical and Electronic Equipment This Allied Telesis RoHS-compliant product conforms to the European Union Restriction of the Use of Certain Hazardous Substances (RoHS) in Electrical and Electronic Equipment. Allied Telesis ensures RoHS conformance by requiring...
- Page 4 RFI Emissions FCC Class B, EN55022 Class B, VCCI Class B, C-TICK, CE Immunity EN55024 Electrical Safety EN60950-1 (TUV), UL 60950-1 ( Laser Safety EN60825...
- Page 5 Translated Safety Statements Important: The symbol indicates that a translation of the safety statement is available in a PDF document titled “Translated Safety Statements” on our web site at www.alliedtelesis.com/support.
-
Page 7: Table Of Contents
Contents Preface ................................13 Safety Symbols Used in this Document ......................14 Contacting Allied Telesis ..........................15 Chapter 1: Introducing the AT-ANC10S/2 Adapter ..................17 Functional Descriptions ............................18 AT-ANC10S/2 Adapter Physical Description .....................19 Features ................................21 Adaptive Interrupt Frequency........................21 ASIC with Embedded RISC Processor ......................21 Supported Operating Environments......................21... - Page 8 Contents Using the Installer............................50 Using Silent Installation ..........................54 Removing the Device Drivers .......................... 57 Chapter 6: Setting Advanced Properties ....................59 Advanced Features ............................60 Accessing the Advanced Tab .......................... 62 Selecting the Advanced Tab in Windows Server 2008 or Windows Server 2008 R2........ 62 Selecting the Advanced Tab in Windows Server 2012................
- Page 9 Figures Figure 1: AT-ANC10S/2 Adapter ............................19 Figure 2: AT-ANC10S/2 Faceplate ............................19 Figure 3: Package Contents of the AT-ANC10S/2 Adapter....................24 Figure 4: Removing the Low-profile Bracket........................28 Figure 5: Installing the Standard Bracket..........................29 Figure 6: Removing the PC Cover............................31 Figure 7: Removing the Faceplate From PCIe Slot ......................
- Page 10 List of Figures...
- Page 11 Table 5. Default Values for the bnx2x Driver ........................45 Table 6. Supported Versions of Microsoft Windows ......................48 Table 7. Advanced Features in Microsoft Windows Supported by the AT-ANC10S/2 Adapter ..........60 Table 8. Advanced Features in Microsoft Windows ......................65 Table 9. Linux Module Size ..............................95 Table 10.
- Page 12 List of Tables...
-
Page 13: Preface
Preface This guide contains instructions on how to install and configure the AT-ANC10S/2 adapter. The Preface discusses the following topics: “Safety Symbols Used in this Document” on page 14 “Contacting Allied Telesis” on page 15... -
Page 14: Safety Symbols Used In This Document
Preface Safety Symbols Used in this Document This document uses the following conventions: Note Notes provide additional information. Caution Cautions inform you that performing or omitting a specific action may result in equipment damage or loss of data. Warning Warnings inform you that performing or omitting a specific action may result in bodily injury. -
Page 15: Contacting Allied Telesis
AT-ANC10S/2 Adapter Installation and User’s Guide Contacting Allied Telesis If you need assistance with this product, you may contact Allied Telesis technical support by going to the Support & Services section of the Allied Telesis web site at www.alliedtelesis.com/support. You can find links for the following services on this page: ... - Page 16 Preface...
-
Page 17: Chapter 1: Introducing The At-Anc10S/2 Adapter
Chapter 1 Introducing the AT-ANC10S/2 Adapter This chapter provides an introduction to the AT-ANC10S/2 network adapter and discusses the following topics: “Functional Descriptions” on page 18 “Features” on page 21... -
Page 18: Functional Descriptions
The AT-ANC10S/2 adapter, shown in Figure 1 on page 19, has two slots for SFP+ modules that operate at 10 Gbps in full duplex mode. You cannot change the speed or duplex mode of the transceiver slots. -
Page 19: At-Anc10S/2 Adapter Physical Description
AT-ANC10S/2 Adapter Installation and User’s Guide Figure 1. AT-ANC10S/2 Adapter AT-ANC10S/2 The faceplate on the AT-ANC10S/2 adapter, shown in Figure 2 on page 19, has two slots for SFP+ transceivers, and four LEDs. Adapter Physical Description Figure 2. AT-ANC10S/2 Faceplate... -
Page 20: Table 2. Network Link And Activity Leds
Chapter 1: Introducing the AT-ANC10S/2 Adapter Table 2. Network Link and Activity LEDs Port LED LED State Network State ACT LED The slot is empty or the transceiver in the slot is not transmitting or receiving network traffic. Blinking The transceiver in the slot is transmitting or receiving network traffic. -
Page 21: Features
AT-ANC10S/2 Adapter Installation and User’s Guide Features The following features apply to the AT-ANC10S/2 adapter: Dual 10 Gbps MAC on the AT-ANC10S/2 adapter TCP segmentation offload PXE v2.1 remote boot Receive side scaling (RSS) for IPv4 and IPv6 ... - Page 22 Chapter 1: Introducing the AT-ANC10S/2 Adapter Microsoft Windows Server 2008 R2 Microsoft Windows Server 2012 and 2012 R2 Microsoft Windows Server 2008 R2, 2012 and 2012 R2 Hyper-V Linux (32-bit and 64-bit extended) Solaris x86 ...
-
Page 23: Chapter 2: Installing The Hardware
Chapter 2 Installing the Hardware This chapter describes how to install the AT-ANC10S/2 in a PC and discusses the following topics:' “Reviewing the Contents of Your Shipment” on page 24 “Reviewing Safety Precautions” on page 25 “Pre-Installation Checklist” on page 27 ... -
Page 24: Reviewing The Contents Of Your Shipment
Chapter 2: Installing the Hardware Reviewing the Contents of Your Shipment The AT-ANC10S/2 adapter comes with two brackets: a pre-installed low- profile bracket and a standard bracket. Refer to Figure 3. AT-ANC10S/2 adapter with pre- installed low profile bracket. Standard bracket. -
Page 25: Reviewing Safety Precautions
AT-ANC10S/2 Adapter Installation and User’s Guide Reviewing Safety Precautions Please review the following safety precautions before you begin to install a network adapter card. Note The indicates that a translation of the safety statement is available in a PDF document titled “Translated Safety Statements”... - Page 26 Chapter 2: Installing the Hardware Warning The adapter is being installed in a system that operates with voltages that can be lethal. Before you remove the cover of your system, you must observe the following precautions to protect yourself and to prevent damage to the system components. - Remove any metallic objects or jewelry from your hands and wrists.
-
Page 27: Pre-Installation Checklist
5. Check the adapter for visible signs of damage, particularly on the card’s edge connector. Note Do not install a damaged adapter. If the adapter is damaged, report it to Allied Telesis. See “Contacting Allied Telesis” on page 15. -
Page 28: Installing The Standard Bracket On The Adapter
Chapter 2: Installing the Hardware Installing the Standard Bracket on the Adapter If you are installing AT-ANC10S/2 adapter in a computer that requires a standard bracket, you must replace the pre-installed low profile bracket on the adapter with the standard bracket. To install the standard bracket,... -
Page 29: Figure 5: Installing The Standard Bracket
AT-ANC10S/2 Adapter Installation and User’s Guide Figure 5. Installing the Standard Bracket... -
Page 30: Installing The Network Adapter Card
Note This procedure requires a Phillips-head screw. Note The AT-ANC10S/2 adapter requires a PCIe x8 PC. Warning The adapter is being installed in a system that operates with voltages that can be lethal. Before you remove the cover of your system, you must observe the following precautions to protect yourself and to prevent damage to the system components. -
Page 31: Figure 6: Removing The Pc Cover
AT-ANC10S/2 Adapter Installation and User’s Guide Figure 6. Removing the PC Cover 3. Select an empty, non-shared PCIe slot and remove the faceplate. Note If you cannot locate or do not know how to find an appropriate PCIe slot, refer to the documentation that came with your system. -
Page 32: Figure 8: Inserting The Adapter With A High-Profile Bracket
Chapter 2: Installing the Hardware 4. Remove the network adapter card from the shipping package and store the packaging material in a safe location. 5. Applying even pressure at both corners of the card, push the adapter card until it is firmly seated in the appropriate PCIe slot. Refer to Figure 8. -
Page 33: Figure 9: Securing The Adapter With A High-Profile Bracket
Figure 9. Securing the Adapter with a High-profile Bracket 7. Replace the system’s cover and secure it with the screws removed in step 2. 8. Go to “Installing SFP+ Transceivers in the AT-ANC10S/2 Adapter” on page 34. 9. Power on the system. -
Page 34: Installing Sfp+ Transceivers In The At-Anc10S/2 Adapter
The cable specifications for the SFP+ transceivers are found in the installation guides that ship with the devices. Note For information about cleaning a fiber optic connector on the AT-ANC10S adapter, see Appendix B “Cleaning Fiber Optic Connectors” on page 119. -
Page 35: Chapter 3: Installing Broadcom Boot Agent Driver Software
Chapter 3 Installing Broadcom Boot Agent Driver Software This chapter provides information about how to install the Broadcom Boot Agent Driver Software and discusses the following topics: “Overview” on page 36 “Setting Up MBA in a Client Environment” on page 37 ... -
Page 36: Overview
Chapter 3: Installing Broadcom Boot Agent Driver Software Overview The AT-ANC10S/2 network adapter supports Preboot Execution Environment (PXE). Multi-Boot Agent (MBA) is a software module that allows your network computer to boot with the images provided by remote servers across the network. The Broadcom MBA driver complies with PXE 2.1 code. -
Page 37: Setting Up Mba In A Client Environment
CTRL-S prompt and NIC setup menu. Note The message prompting you to press CTRL+S is displayed only once even if the computer has more than one AT-ANC10S Interface Adapter. After you press CRTL+S, the Broadcom Comprehensive Control Manager displays all the Broadcom devices that are installed in the computer and that you can configure. -
Page 38: Setting Up Mba In A Server Environment: Red Hat Linux Pxe Server
Server on Linux. However, the Initrd.img file distributed with some Red Hat Enterprise Linux distributions does not have a Linux network driver for the AT-ANC10S/2 network adapter. These distributions require a driver disk for drivers that are not part of the standard distribution. You download the driver software... -
Page 39: Chapter 4: Installing The Linux Drivers
Chapter 4 Installing the Linux Drivers The procedures in this chapter explain how to install the Linux drivers for the adapter. This chapter discusses the following topics: “Overview” on page 40 “Installing Linux Driver Software” on page 41... -
Page 40: Overview
Chapter 4: Installing the Linux Drivers Overview This chapter discusses the Linux drivers for the AT-ANC10S/2 network adapter and describes how to install them. For a description of the drivers, see Table 3. Table 3. Linux Driver for the AT-ANC10S/2 Network Adapter... -
Page 41: Installing Linux Driver Software
AT-ANC10S/2 Adapter Installation and User’s Guide Installing Linux Driver Software There are two ways to install the Linux driver software — from the Source RPM Package or by building the driver from the source TAR file. See the following sections: ... -
Page 42: Building The Driver From The Source Tar File
Chapter 4: Installing the Linux Drivers version rpm -ivh RPMS/i386/bnx2x- .arch.rpm If you are installing over an existing distribution that may already contain an older version of the driver, the —force option is needed. Depending on the kernel, the driver is installed to one of the following paths: For 2.4.x kernels /lib/modules/kernel_version/kernel/drivers/net/bnx2x.o... -
Page 43: Unloading The Linux Driver
AT-ANC10S/2 Adapter Installation and User’s Guide or, for Linux 2.6 kernels: rmmod bnx2x insmod bnx2x.ko 4. Install the driver and man page by entering the following command: make install Note See the “Installing the Source RPM Package” on page 41 for the location of the installed driver. -
Page 44: Patching Pci Files (Optional)
Chapter 4: Installing the Linux Drivers Patching PCI This is an optional procedure that describes how to patch PCI files for identification by other vendors. Files (Optional) For hardware detection utilities, such as Red Hat kudzu, to properly identify bnx2x supported devices, you may need to update a number of files containing PCI vendor and device information. -
Page 45: Checking The Bnx2X Driver Defaults
AT-ANC10S/2 Adapter Installation and User’s Guide preserve the settings across a reboot. Note Some combinations of property values may conflict and result in failures. The driver cannot detect all conflicting combinations. This property is used to disable Message Signal Interrupts (MSI). The property is valid only on 2.6 kernels that support MSI. -
Page 46: Checking Driver Messages
Chapter 4: Installing the Linux Drivers Table 5. Default Values for the bnx2x Driver (Continued) Parameter Default Value Coalesce RX Frames IRQ 6 (range is 0–255) Coalesce TX Microseconds 80 (range is 0–1023) Coalesce TX Microseconds IRQ 80 (range is 0–1023) Coalesce TX Frames 20 (range is 0–255) Coalesce TX Frames IRQ... -
Page 47: Chapter 5: Installing The Windows Drivers
Installing the Windows Drivers This chapter provides procedures to install and remove the driver software for all of the Windows Operating Systems supported by the AT-ANC10S/2 adapter. In addition, it describes how to display and change adapter properties including power management options. This chapter discusses the following topics: ... -
Page 48: Supported Versions Of Microsoft Windows
Supported Versions of Microsoft Windows Table 6 lists the versions of Microsoft Windows supported by the adapter. Table 6. Supported Versions of Microsoft Windows Version of Microsoft Windows AT-ANC10S/2 Operating System Windows Vista 32/64 Windows 7 32/64 Windows Server 2003 32/64... -
Page 49: Installing The Windows Driver Software
Microsoft Windows Server 2012 and 2012 R2 The Windows driver software for all of the Windows Operating Systems is available on the Allied Telesis website at www.alliedtelesis.com/ support/software. After you have accessed this website, enter the model number in the Search by Product Name box and then click Find to display the current list of software drivers. -
Page 50: Using The Installer
The Installer has a graphical interactive installation mode. To install the AT-ANC10S/2 driver on a Windows Operating System, do the following: 1. From the driver directory, select the setup.exe file and Run. The Broadcom NetXtreme II Driver Installer - InstallShield Wizard... -
Page 51: Figure 10: Broadcom Netxtreme Ii Driver Installer - Installshield Wizard Page
AT-ANC10S/2 Adapter Installation and User’s Guide Figure 10. Broadcom NetXtreme II Driver Installer - InstallShield Wizard Page 2. Click Next to continue. The License Agreement Page is displayed. See Figure 11 on page 52. -
Page 52: Figure 11: License Agreement Page
Chapter 5: Installing the Windows Drivers Figure 11. License Agreement Page 3. After you review the license agreement, click I accept the terms in the license agreement and then click Next to continue. The Ready to Install the Program Page is displayed. See Figure 12 on page 53. -
Page 53: Figure 12: Ready To Install The Program Page
AT-ANC10S/2 Adapter Installation and User’s Guide Figure 12. Ready to Install the Program Page 4. Click Install. The InstallShield Wizard Completed Page is displayed. See Figure 13 on page 54. -
Page 54: Using Silent Installation
Silent installation provides a command-line silent mode which allows for unattended installation. This section discusses the various ways to Installation perform a silent installation on all of the Windows Operating Systems supported by the AT-ANC10S/2 adapter. See the following sections: “Performing a Silent Install” on page 55 ... - Page 55 AT-ANC10S/2 Adapter Installation and User’s Guide Note User must “Run as Administrator” for Vista when using “msiexec” for “silent” install or uninstall procedures. Note For detailed instructions and information about unattended installs, refer to the Silent.txt file in the DrvInst folder.
- Page 56 Chapter 5: Installing the Windows Drivers msiexec /x "{F0DA8A3F-1457-419E-96F4-235DD3EF41E1}" / Note The hexadecimal number above may differ from your current installer. Check the Key name in HKLM\Software\Microsoft\ Windows\CurrentVersion\Uninstall for the correct hexadecimal number. Performing a Silent Reinstall To perform a silent reinstall of the same installer, enter: setup /s /v"/qn REINSTALL=ALL"...
-
Page 57: Removing The Device Drivers
Device Driver Rollback feature that replaces a device driver with one that was previously installed. However, the complex software architecture of the AT-ANC10S/2 network adapter may present problems if the rollback feature is used on one of the individual components. Therefore, Allied Telesis recommends that changes to driver versions be made only through the use of a driver installer. - Page 58 Chapter 5: Installing the Windows Drivers...
-
Page 59: Chapter 6: Setting Advanced Properties
Chapter 6 Setting Advanced Properties For all of the Windows operating systems, you access the Windows Advanced Properties from the Advanced Tab. Although the default values of the Advanced Properties are appropriate in most cases, you can change any of the available options to meet the requirements of your system. This chapter discusses the following topics: ... -
Page 60: Advanced Features
Table 7 lists the advanced network adapter features in Microsoft Windows that are supported by the AT-ANC10S/2 Adapter. Default values are marked with an asterisk. Table 7. Advanced Features in Microsoft Windows Supported by the AT-ANC10S/2 Adapter Windows Server Windows Server... -
Page 61: Table 8. Advanced Features In Microsoft Windows
AT-ANC10S/2 Adapter Installation and User’s Guide Table 7. Advanced Features in Microsoft Windows Supported by the AT-ANC10S/2 Adapter Windows Server Windows Server Windows Server Feature 2008 32/64 2008 R2 2012 and 2012 R2 Receive Buffers 0* to 3000 in 0* to 3000 in... -
Page 62: Accessing The Advanced Tab
Chapter 6: Setting Advanced Properties Accessing the Advanced Tab To modify the configuration properties of the Windows Operating systems, you must access the Advanced Tab. Depending on your operating system, there are several ways to do this. See the following procedures: ... -
Page 63: Selecting The Advanced Tab In Windows Server 2012
AT-ANC10S/2 Adapter Installation and User’s Guide The Device Manager window is displayed. See Figure 15. Figure 15. Device Manager Window 3. Open the Network Adapters folder. The list of installed adapters is displayed. 4. Right click on the BCM57810NetXtreme II 10 GigE adapter. -
Page 64: Figure 16: Windows Server 2012 Desktop
Chapter 6: Setting Advanced Properties Figure 16. Windows Server 2012 Desktop 2. From the Start Menu, select Run. The Windows Server 2012 Run window is displayed. See Figure 17. Figure 17. Windows Server 20112 Run Window 3. Enter the following command in the Run window: mmc devmgmt.msc The Device Manager window is displayed. -
Page 65: Modifying The Advanced Properties
AT-ANC10S/2 Adapter Installation and User’s Guide Modifying the Advanced Properties After you have installed the driver software, you can use Table 8 to verify or change the adapter properties: Note After you upgrade the driver software, the Advanced Properties may change. - Page 66 This property is only available for the AT-ANC10S/2 network adapter. Frame size is set at 1500 bytes by default. To increase the size of the received frames, raise the byte quantity in 500-byte increments.
- Page 67 AT-ANC10S/2 Adapter Installation and User’s Guide Table 8. Advanced Features in Microsoft Windows Feature Description Configuration Steps IPv4 Large Send Normally, the TCP segmentation is 1. In Microsoft Windows, Offload done by the protocol stack. When right-click the Network Adapter...
- Page 68 Packet value. jumbo frames. This property is only available for the AT-ANC10S/2 network adapter. Frame size is set at 1500 bytes by default. To increase the size of the received frames, raise the byte quantity in 500-byte increments.
- Page 69 AT-ANC10S/2 Adapter Installation and User’s Guide Table 8. Advanced Features in Microsoft Windows Feature Description Configuration Steps Locally The Locally Administered Address 1. In Microsoft Windows, Administered is a user-defined MAC address right-click the Network Adapter Address that is used in place of the MAC...
- Page 70 Chapter 6: Setting Advanced Properties Table 8. Advanced Features in Microsoft Windows Feature Description Configuration Steps Priority and VLAN The options are listed here: 1. In Microsoft Windows, right-click the Network Adapter Priority & VLAN Enabled in Network Connections and, (default) - Allows for packet then click Properties.
- Page 71 AT-ANC10S/2 Adapter Installation and User’s Guide Table 8. Advanced Features in Microsoft Windows Feature Description Configuration Steps Receive Side This parameter allows configuring 1. In Microsoft Windows, Scaling network load balancing across right-click the Network Adapter multiple CPUs. The default setting in Network Connections and for this property is Enabled.
- Page 72 Chapter 6: Setting Advanced Properties Table 8. Advanced Features in Microsoft Windows Feature Description Configuration Steps Speed and Duplex The Speed & Duplex property sets 1. In Microsoft Windows, Mode the connection speed and mode to right-click the Network Adapter that of the network.
- Page 73 AT-ANC10S/2 Adapter Installation and User’s Guide Table 8. Advanced Features in Microsoft Windows Feature Description Configuration Steps TCP/UDP Normally, the checksum function is 1. In Microsoft Windows, Checksum Offload computed by the protocol stack. right-click the Network Adapter (IPv4) When you select one of the...
- Page 74 Chapter 6: Setting Advanced Properties Table 8. Advanced Features in Microsoft Windows Feature Description Configuration Steps Transmit Buffers The number of transmit buffers. 1. In Microsoft Windows, (0=Auto) Transmit buffers are data right-click the Network Adapter segments that allow the network in Network Connections and adapter to monitor transmit then click Properties.
-
Page 75: Chapter 7: Installing Cim And Snmp For Manageability
Chapter 7 Installing CIM and SNMP for Manageability Both Common Information Model (CIM) and Simple Network Management Protocol (SNMP) are information models that allow you to monitor and manage a PC or a network. Both CIM and SNMP are supported on the Windows Server 2008, Windows Server 2008 R2, and Windows Server 2012 Operating Systems. -
Page 76: Installing Cim
Chapter 7: Installing CIM and SNMP for Manageability Installing CIM The Common Information Model (CIM) is an industry standard defined by the Distributed Management Task Force (DMTF). Microsoft implements CIM on Windows platforms. Also, Broadcom supports CIM on the Windows Server 2008, Windows Server 2008 R2, and Windows Server 2012 platforms. -
Page 77: Loading The Cim Libraries
CIM libraries. You need to select this option. Libraries To load the CIM libraries on your PC, do the following: 1. Download the BACS utility from the Allied Telesis website. This utility is available from the www.alliedtelesis.com/support/software website. After accessing the website, enter the model number in the Search by Product Name box and click Find to view the current list of available files. -
Page 78: Figure 18: Bacs Cim Option Window
Chapter 7: Installing CIM and SNMP for Manageability Figure 18. BACS CIM Option Window 4. Select CIM Provider. 5. Select one of the following: This feature will be installed on local hard drive. This feature, and all subfeatures, will be installed on local hard drive. -
Page 79: Installing Snmp
To monitor this information, an SNMP manager must load the Broadcom BASP MIB database files to allow monitoring of the information described above. The following files are posted on the Allied Telesis web site: baspcfg.mib ... -
Page 80: Loading The Snmp Libraries
Chapter 7: Installing CIM and SNMP for Manageability The extensible-agent allows the SNMP manager software to actively monitor the configurations of the AT-ANC10S/2 network adapter. It supplements the information already provided by the standard SNMP Management Network Interface information. The extensible-agent provides in-depth information about the AT-ANC10S/2 network adapter including: ... -
Page 81: Figure 19: Bacs Snmp Option Window
AT-ANC10S/2 Adapter Installation Guide The BACS SNMP Option Window is displayed. See Figure 18. Figure 19. BACS SNMP Option Window 5. Select one of the following: This feature will be installed on local hard drive. This feature, and all subfeatures, will be installed on local hard drive. - Page 82 Chapter 7: Installing CIM and SNMP for Manageability...
-
Page 83: Chapter 8: Installing Management Applications
Chapter 8 Installing Management Applications This chapter provides information about prerequisites for installing management applications as well as procedures instructions. This chapter discusses the following topics: “Installing Broadcom Advanced Control Suite 4 and Related Management Applications” on page 84 ... -
Page 84: Installing Broadcom Advanced Control Suite 4 And Related Management Applications
Chapter 8: Installing Management Applications Installing Broadcom Advanced Control Suite 4 and Related Management Applications The Broadcom Advanced Control Suite 4 (BACS 4) software and related management applications can be installed from the source-file directory or by using the silent install option. See the following: ... -
Page 85: Using The Installer
Starting BACS 4 without .NET Framework installed on your system results in an error. Using the The driver software is available for download from the Allied Telesis web site at www.alliedtelesis.com/support. After accessing this website, Installer enter the model number in the Search by Product Name box and then click Find to view the current list of available software drivers. - Page 86 Chapter 8: Installing Management Applications “Performing a Silent Install from Within a Batch File” on page 87 Note All commands are case sensitive. Note User must “Run as Administrator” for Vista when using “msiexec” for “silent” install/uninstall(s). Performing a Silent Install from the Installer Source Folder To perform a silent install (or upgrade) from within the installer source folder, enter: setup /s /v/qn...
- Page 87 AT-ANC10S/2 Adapter Installation and User’s Guide Note After performing a silent uninstall, it is necessary to reboot the system before reinstalling this installer. If you do not perform a reboot, BASP does not install correctly. Performing a Silent Install by Feature on IA32 Platforms...
-
Page 88: Modifying Management Applications
Chapter 8: Installing Management Applications Modifying Management Applications To modify the management applications, do the following: 1. In Control Panel, double-click Add or Remove Programs. 2. Click Broadcom Management Programs and then click Change. 3. Click Next to continue. 4. Click Modify to change program features. 5. -
Page 89: Repairing Management Applications
AT-ANC10S/2 Adapter Installation and User’s Guide Repairing Management Applications To repair or reinstall the management applications, do the following: 1. In Control Panel, double-click Add or Remove Programs. 2. Click Broadcom Management Programs, and then click Change. 3. Click Next to continue. -
Page 90: Removing Management Applications
Chapter 8: Installing Management Applications Removing Management Applications To remove all management applications, do the following: 1. In Control panel, double-click Add or Remove Programs. 2. Click Broadcom Management Programs, and then click Remove. 3. Reboot your system to complete the removal of the management applications. -
Page 91: Chapter 9: Troubleshooting
Within the chapter there are several references to the Broadcom Advanced Control Suite 4 User Guide. You can download this manual from the Allied Telesis website at www.alliedtelesis.com/support/software. After accessing the website, enter the model number in the Search by Product Name box and then click Find to view the current list of documents. -
Page 92: Checking Hardware Diagnostics
For instructions and information on running tests in an MS-DOS environment, see Chapter 10, “User Diagnostics” on page 105. For Windows environments, see “Running Diagnostic Tests” in the Broadcom Advanced Control Suite 4 User Guide which you can download from the Allied Telesis website. -
Page 93: Checking Port Leds
AT-ANC10S/2 Adapter Installation and User’s Guide Checking Port LEDs To check the state of the network links and activities on the ports, refer to Table 2 on page 20:... -
Page 94: Consulting The Troubleshooting Checklist
Before you open the cabinet of your server to add or remove the adapter, see “Reviewing Safety Precautions” on page 25. The following checklist provides recommended actions to resolve problems installing or running the AT-ANC10S/2 adapter in your system: Inspect all cables and connections. Verify that the cable connections at the network adapter and the switch are attached properly. -
Page 95: Running A Cable Length Test
AT-ANC10S/2 Adapter Installation and User’s Guide Linux To verify that the bnx2x.o (or bnx2x.ko) driver is loaded properly, enter: lsmod If the driver is loaded, a line similar to one Table 9 is displayed, where size indicates the size of the driver in bytes, and number is the number of adapters configured. - Page 96 Chapter 9: Troubleshooting 3. If you are performing the ping command at the system where the new adapter is installed, type ipconfig /all to verify that the new adapter is operational. 4. Type ping <remote IP address>, and then press Enter. If you are performing the ping command at the system where the new adapter is installed, specify the IP address of a remote device the adapter is to ping.
-
Page 97: Solving Microsoft Windows Server 2008 R2 Hyper-V Issues
Ensure that Integrated Services, which is a component of Hyper-V, is installed in the guest operating system (child partition) for full functionality. Single Network When configuring an AT-ANC10S network adapter for Hyper-V, be aware of the following: Adapter An adapter that is bound to a virtual network should not be configured for VLAN tagging through the driver's advanced properties. -
Page 98: Teamed Network Adapters
Link Aggregation (IEEE 802.3ad LACP) Generic Trunking (FEC/GEC) 802.3ad Draft Static When configuring a team of AT-ANC10S network adapter on a Hyper-V system, be aware of the following: Create the team prior to binding the team to the Hyper-V virtual network ... - Page 99 When applying network properties through an answer file for an AT-ANC10S/2 network adapter where the PnP iD is the identifier, do the following: For a BCM57810 Netxtreme II 10GigE - InfId = "b06bdrv\l2nd&pci_168e14e4"...
-
Page 100: Solving Broadcom Boot Agent And Broadcom Advanced Server Program (Basp) Issues
Chapter 9: Troubleshooting Solving Broadcom Boot Agent and Broadcom Advanced Server Program (BASP) Issues This section discusses issues with the Broadcom Boot Agent and Broadcom Advanced Server (BASP) as well as provides solutions. Problem: Unable to obtain network settings through DHCP using PXE. Solution: For proper operation, make sure that the Spanning Tree Protocol (STP) feature is disabled or that portfast mode (for Cisco switches) is enabled on the port to which the PXE client is connected. - Page 101 AT-ANC10S/2 Adapter Installation and User’s Guide Problem: A Generic Trunking (GEC/FEC) 802.3ad-Draft Static type of team may lose some network connectivity if the driver to a team member is disabled. Solution: If a team member supports underlying management software (ASF/IPMI/UMP) or Wake-On-LAN, the link may be maintained on the switch for the adapter despite its driver being disabled.
-
Page 102: Solving Miscellaneous Issues
Solution: This is a limitation of .NET Framework 2.0. Apply .NET Framework 2.0 SP1 and reboot your system. Problem: The AT-ANC10S network adapter may not perform at optimal levels on some systems if it is added after the system has booted. - Page 103 AT-ANC10S/2 Adapter Installation and User’s Guide Solution: Ensure that the system has at least 2 GB of main memory when using up to four network adapters and 4 GB of main memory when using four or more network adapters.
- Page 104 Chapter 9: Troubleshooting...
-
Page 105: Chapter 10: User Diagnostics
Chapter 10 User Diagnostics This chapter provides user diagnostic information for the MS-DOS platform. This chapter discusses the following topics: “Overview” on page 106 “System Requirements” on page 107 “Performing Diagnostics” on page 108 “Diagnostic Test Descriptions” on page 111... -
Page 106: Overview
Note The diagnostics utility is available from the Allied Telesis web site at www.alliedtelesis.com/support/software. To run Broadcom NetXtreme II User Diagnostics, you must create an MS-DOS 6.22 bootable disk containing the uediag.exe file. -
Page 107: System Requirements
AT-ANC10S/2 Adapter Installation and User’s Guide System Requirements The following system requirements are needed to run user diagnostics: MS-DOS 6.22 Operating System uediag.exe file... -
Page 108: Performing Diagnostics
Table 10. uediag Command Options Command Option Description uediag Performs all tests on all the AT-ANC10S/2 network adapters in your system. uediag -c <devnum> Specifies the adapter (devnum) to test. Use all in place of a specific device number to test all adapters. - Page 109 AT-ANC10S/2 Adapter Installation and User’s Guide Table 10. uediag Command Options (Continued) Command Option Description uediag -fump Specifies the bin file to update the <ump_image> UMP firmware. uediag -help Displays the Broadcom NetXtreme II User Diagnostics, uediag, command options. uediag -I <iteration num>...
- Page 110 Chapter 10: User Diagnostics Table 10. uediag Command Options (Continued) Command Option Description uediag -ver Displays the version of Broadcom NetXtreme II User Diagnostics (uediag) and all installed adapters. uediag -wol <1/0> Enables/disables Magic Packet WOL where: 1 = Enable 0 = Disable WOL is not supported on 10Gbps Ethernet adapters.
-
Page 111: Diagnostic Test Descriptions
AT-ANC10S/2 Adapter Installation and User’s Guide Diagnostic Test Descriptions The diagnostic tests are divided into four groups: Basic Functional Tests (Group A) Memory Tests (Group B) Block Tests (Group C) Ethernet Traffic Tests (Group D). The diagnostic tests are described in Table 11. - Page 112 Chapter 10: User Diagnostics Table 11. Diagnostic Tests (Continued) Test Description Number Name Group B: Memory Tests TXP Scratchpad TPAT Scratchpad RXP Scratchpad COM Scratchpad CP Scratchpad MCP Scratchpad The Group B tests verify all of the memory TAS Header Buffer blocks of the network adapters by writing various data patterns (0x55aa55aa, TAS Payload Buffer...
- Page 113 AT-ANC10S/2 Adapter Installation and User’s Guide Table 11. Diagnostic Tests (Continued) Test Description Number Name RBUF Allocation Verifies the RX buffer (RBUF) allocation interface by allocating and releasing buffers and checking that the RBUF block maintains an accurate count of the allocated and free buffers.
- Page 114 Chapter 10: User Diagnostics Table 11. Diagnostic Tests (Continued) Test Description Number Name DMA Engine Verifies the functionality of the DMA engine block by performing numerous DMA read and write operations to various system and internal memory locations (and byte boundaries) with varying lengths (from 1 byte to over 4 KB, crossing the physical page boundary) and different data patterns...
- Page 115 AT-ANC10S/2 Adapter Installation and User’s Guide Table 11. Diagnostic Tests (Continued) Test Description Number Name PHY Loopback Enables PHY loopback mode in the adapter and transmits 5000 Layer 2 packets of various sizes. As the packets are received by Broadcom NetXtreme II User Diagnostics, they are checked for errors.
- Page 116 Chapter 10: User Diagnostics...
-
Page 117: Appendix A: Technical Specifications
“Power Specifications” on page 118 “Performance Specification” on page 118 Physical Specifications Table 12 contains the dimensions and weight of the adapter card. Table 12. AT-ANC10S/2 Physical Specifications Dimensions 160.0 mm (6.3 in) x 68.9 mm (2.7 in) Weight 78.0 g (2.8 oz) Environmental Specifications Table 13 contains the environmental specifications of the adapter card. -
Page 118: Power Specifications
Appendix A: Technical Specifications Power Specifications Table 14 contains the power specifications of the adapter card: Table 14. Operating Voltages and Maximum Power Consumption Operating Voltage 3.3V and 12V Maximum Power Consumption Performance Specification The adapter card is x8 PCIe v2.0 and v1.1 compliant... -
Page 119: Appendix B: Cleaning Fiber Optic Connectors
Appendix B Cleaning Fiber Optic Connectors The fiber optic connector consists of a fiber optic plug and its adapter. The end of the fiber optic cable is held in the core of the ferrule in the plug. Light signals are transmitted through the core of the fiber. Even minor smudges or dirt on the end face of the fiber, completely invisible to the naked eye, can disrupt light transmission and lead to failure of the component or of the entire system. -
Page 120: Using A Cartridge-Type Cleaner
Appendix B: Cleaning Fiber Optic Connectors Using a Cartridge-Type Cleaner Fiber optic cartridge cleaners are available from many vendors and are typically called “cartridge cleaners.” An example is shown in Figure 22. Figure 22. Cartridge Cleaner Note Do not use compressed air or aerosol air to clean a fiber optic connector. - Page 121 AT-ANC10S/2 Adapter Installation and User’s Guide Note Rub the ferrule tip on the cleaning surface in one direction only. 3. When you reach the end of the cleaning surface, pick up the ferrule tip, rotate and place it at the top and rub downwards at least 2 times.
-
Page 122: Using A Swab
Appendix B: Cleaning Fiber Optic Connectors Using a Swab Specially treated swabs, known as stick cleaners, are available for cleaning inside connector adapters or hard-to-reach ferrule tips. These swabs, often referred to as “lint free” or “alcohol free” swabs, are available from many vendors. - Page 123 AT-ANC10S/2 Adapter Installation and User’s Guide 3. If a fiber inspection scope is available, use the scope to inspect the connector to make sure that it is clean and to check for scratches, pits, or other problems that may affect performance.
- Page 124 Appendix B: Cleaning Fiber Optic Connectors...
