Allied Telesis AT-AR027 Datasheet

Datasheet | Port Interface Cards
AT -AR027 FXS-VolP
Port Interface Cards (PICs)
AT -AR027 FXS-VolP
The AT-AR027 FXS (Foreign Exchange Service)
Port Interface Card (PIC) provides low-density,
high-quality, full-duplex, inter-site voice/fax com-
munication over IP. Combined with an Allied
Telesis router or Rapier TM Layer 3 switch it will
allow up to eight telephones or faxes to be
connected to a Local Area Network.
Industry Standard Compatibility
The AT-AR027 fully complies with Industry
Standard Protocols, such as VoIP , H.323 v2, SIP ,
G.711 A/µlaw, G.723.1 and G.729 A/B (optional).
High Quality of Voice
The AT-AR027 also provides support for vari-
ous voice CODECs i.e. G.711 (A/µlaw) vocoder
64Kbps, G.723.1 (5.3 and 6.3Kbps) and G.729
A/B (8Kbps) (optional).
Technical Specifications
Physical Dimensions
Height: 18mm
Width: 84mm
Depth: 120mm
Weight: 0.098kg
Voice CODEC
G.711 A/ì-law, G.723.1, 5K3/6K3, G.729 A/B
(Optional)
FXS Ports
2 x RJ-11 ports per card
LED Indications
Off Hook / Ring, PIC Error, Registered State
OS Minimum Requirement
AlliedWare TM 2.5.3
USA Headquarters | 19800 North Creek Parkway
European Headquarters | Via Motta 24
Asia-Pacific Headquarters | 11 Tai Seng Link
www.alliedtelesis.com
© 2006 Allied Telesis Inc. All rights reserved. Information in this document is subject to change without notice. All company names, logos, and product designs that are trademarks or registered trademarks are the property of their respective owners.
Standards
VoIP
H323v2
SIP
Host Device Occupancy
Device No. of AR027 PICs supported
AT-AR410
AT-AR410S
AT-AR415S
AT-AR440S
AT-AR441S
AT-AR442S
AT-AR720
AT-AR725
AT-AR740
AT-AR745
Rapier 16f
Rapier 16fi
Rapier 24
Rapier 24i
| Suite 200 | Bothell |
| 6830 Chiasso | Switzerland | T: +41 91 69769.00
| Singapore | 534182 | T: +65 6383 3832
One
One
One
One
One
One
Two
Two
Up to a maximum of four
Up to a maximum of four
Up to a maximum of four
Up to a maximum of four
Up to a maximum of four
Up to a maximum of four
WA 98011 | USA | T: +1 800 424 4284
| F: +41 91 69769.11
| F: +65 6383 3830
Key Features
• Cost savings on long distance calls
• Integration of voice and data networks
• Reduction of resource costs
• Use of open standards
• Port Interface Cards supports 2 POTS ports
(RJ-11) per card
• Each PIC supports up to 2 attached analog
devices (i.e. phone, fax)
• Voice compression to 5.3K per call with sup-
port for multiple algorithms
• Compliant with SIP and H.323
• Programmable country specific tones
Ordering Information
AT-AR027
Two VoIP FXS ports
Order number: 990-001356-00
| F: +1 425 481 3895
617-00613-00 Rev. D
