Figure 2 Installation flow
Start
Rack-mounting
Workbench-mounting
Determine the
installation position
Mount the router on a
Mount the router in a rack
workbench
Ground the router
Install interface modules
Connect interface cables
Connect the router to a
configuration terminal
Connect the power cord
Verify the installation
Power on the router
Troubleshoot the router
Operating correctly?
Power off the router
No
Yes
End
