5.1.1.2 Video Settings

Item Description
Record Enable / Disable recording of a channel.
Resolution Recording resolution selection.
FPS Select recording frame rate from 1 to 30.
Quality Recording quality from 10 to 100. The larger number means the
better quality.
Pre-Alarm Set the record seconds before the event, from 0 to 5.
Post-Alarm Set the playback seconds after the event, from 0 to 100.
Note: Different models have different resolution settings.
Input Setting
NTSC (HD)
NTSC (960H)
NTSC (D1)
PAL (HD)
PAL (960H)
PAL (D1)
Resolution
1920 x 1080
944 x 480
704 x 480
1920 x 1080
944 x 576
704 x 576
52
EPHD16+U Universal DVR
*Note
1280 x 720
704 x 480
704 x 240
1280 x 720
704 x 576
704 x 288
640 x 360
472 x 240
352 x 240
640 x 360
472 x 288
352 x 288
