EverFocus EPHD16+U User Manual page 10

IR Remote *Currently
Control Reserved Mouse / USB Memory Stick
Power
eSATA HDD Expansion
Supply
(EDA450)
Alarm RS-485 Device
In / Out (PTZ Camera)
* The upper USB port on the front panel is currently reserved. To use the USB device, please
connect to the lower port on the front panel or the USB port on the rear panel.
**The HDMI and VGA port can be all used as the Main monitor outputs and share the identical
functionality.
EPHD16+U System Diagram
Internal 3.5" HDDs (Optional)
HD-SDI or Analog Camera 1~16
Call
Line Level
Monitor
Audio In 1~8
(CVBS)
2
EPHD16+U Universal DVR
**Main
**Main Mouse
or USB
Monitor
Monitor
(VGA)
(HDMI)
Web Remote
Client
Line Level
Audio Out
Network
Genie
PowerVideo
XMS
Plus (CMS)
