USER MANUAL
Dishwasher
WSF6606

Advertisement

Table of Contents
loading

  Also See for Westinghouse WSF6606

  Summary of Contents for Westinghouse WSF6606

  • Page 1 USER MANUAL Dishwasher WSF6606...
  • Page 2: Table Of Contents

    CONGRATULATIONS CONTENTS Congratulations and thank you for choosing our product Important safety instructions We are sure you will find your new appliance a pleasure Recycling to use and a great asset to your cooking Before you Safety information use the appliance, we recommend you read through the Recommendations whole user manual which provides a description of the Items not suitable for dishwashing...
  • Page 3: Tips And Information Tips & Information

    IMPORTANT SAFETY INSTRUCTIONS • Before commencing the dishwasher installation, be These warnings have been provided in the interest of safety sure that the machine is unplugged You MUST read them carefully before installing or using the appliance • Check whether the indoor electrical fuse system is connected according to the regulations The symbols you will see in this booklet have these meanings: •...
  • Page 4: Recommendations

    SAFETY INFORMATION AND RECOMMENDATIONS For your children’s safety WARNING WARNING • After removing the machine’s packaging, make sure Some dishwasher detergents are strongly alkaline They that the packaging material is out of reach of children can be extremely dangerous if swallowed Avoid contact •...
  • Page 5: Australian Standard As/Nz 60335 2

    DESCRIPTION OF YOUR APPLIANCE Worktop Detergent and rinse-aid dispenser Upper basket with racks 10 Cutlery basket Upper spray arm 11 Active drying unit Lower spray arm 12 Ceiling spray rose Filters Lower basket Rating plate Control panel TECHNICAL SPECIFICATIONS Capacity 15 place settings •...
  • Page 6: Product View And Parts

    DESCRIPTION OF YOUR APPLIANCE 1. Power button 9. Progress indicator Lights When pressed on, the machine is energized and the Program status can be monitored via the progress indicator power light illuminates lights on control panel • Wash 2. Hygiene button •...
  • Page 7: Quick Start Guide

    QUICK START GUIDE The START/PAUSE button turns Select the program via the Switching on the machine off once the program starts PROGRAM selector button and the WASH light is on Press the POWER button Additonal functions Start the program pressing the START/PAUSE button Once the POWER button is pressed, the START/PAUSE symbol illuminates...
  • Page 8: Installing The Machine

    INSTALLING THE MACHINE Positioning the machine After the connections are made, the tap should be turned on fully and checked for water tightness For the safety of When considering the location for the dishwasher, ensure your machine, make sure to always turn off the water inlet that there is adequate space to enable loading and tap after each wash program is finished unloading of the dishes...
  • Page 9: Electrical Connection

    INSTALLING THE MACHINE WARNING WARNING Electrical Connection The plug of your machine should be connected to an earthed outlet that supplies suitable voltage and current If there is no earthing installation, have a competent electrician carry out an earthing installation In case of usage without earthing installed, our company will not be responsible for any loss of usage that might occur The indoor fuse current value should be 10-16 A...
  • Page 10 INSTALLING THE MACHINE Adjust the machine feet according to the slope of the floor Fit your machine by pushing it undercounter without letting the hoses get crushed or bent WARNING WARNING After removal of worktop, ensure the opening for the dishwasher is according to the following dimensions 820mm INSTALLATION...
  • Page 11: Preparing The Machine For Use

    PREPARING THE MACHINE FOR USE Prior to using the machine for the first time Other tablet detergents contain detergent + rinse aid + various extra functions/additives • Check whether the electricity and water supply specifications match the values indicated by the Generally, combined detergents produce acceptable results under certain usage conditions only These installation instructions for the machine...
  • Page 12: Filling With Rinse Aid And Making The Setting

    PREPARING THE MACHINE FOR USE When you STOP using combined detergents TIPS & INFORMATION TIPS AND INFORMATION • Fill the rinse aid compartments Only use rinse aid suitable for automatic dishwashers • Select a suitable rinse aid setting As rinse aid residues left as a result of overflowing will create extremely high amounts of foam and reduce the Filling with rinse aid and making the setting washing performance, remove the excess amount of rinse...
  • Page 13: Loading Your Dishwasher

    LOADING YOUR DISHWASHER Correctly loaded dishes will result in the best energy consumption, washing and drying performance There are two separate baskets for you to load your dishes into your machine You can load into the lower basket round and deep items as pots with long handles, pot lids, plates, salad plates, and cutlery sets The upper basket has been designed for tea plates, dessert plates, salad bowls, cups and glasses When...
  • Page 14 LOADING YOUR DISHWASHER Spoon rack/Glass Support It allows your long-stemmed glasses to be washed safely as well as providing a convenient alternative location to wash spoons and forks Do not lean your long-stemmed goblets and glasses against each other but towards the spoon rack, so that during the washing cycle this prevents glasses and goblets from being damaged There are 4 different positions for your spoon rack...
  • Page 15 LOADING YOUR DISHWASHER Lower Basket Folding Racks Folding tines (prongs) consisting of four parts that are located on the lower basket of your machine are designed in order to let you place big items easier such as pots, pans, etc If required, each rack can be folded separately, or all of them can be folded and larger spaces created You can use folding tines (prongs) in the upright position, or by folding...
  • Page 16 LOADING YOUR DISHWASHER Alternate cutlery basket An alternate cutlery basket has been provided for convenience The cutlery basket handle is adjustable - position (a) or (b) The basket can be used in the upper or lower dishwasher basket as required Alternative cutlery basket positions By placing your modular cutlery basket in different places of the upper or lower basket, you can create suitable...
  • Page 17: Alternative Basket Loads

    LOADING YOUR DISHWASHER Alternative modular basket position Alternative basket loads Lower Basket LOADING...
  • Page 18: Standard Loading And Test Data

    LOADING YOUR DISHWASHER Top Basket TIPS AND INFORMATION TIPS & INFORMATION Examples of incorrect loading Information for test laboratories For all the necessary information for performance testing, send an email to: dishwasher@standardtest info In your mail please provide the model number and PNC number (9 digits) that is on the rating plate on the appliance door LOADING...
  • Page 19: Program Descriptions

    PROGRAM DESCRIPTIONS Program items NAME OF RINSE** FAST 30 ECO* TIME SAVE HEAVY INTENSIVE PROGRAM WASHING 40ºC 50ºC 65ºC 60ºC 65ºC TEMPERATURE TYPE OF FOOD Pre wash to Fresh Fresh Baked Fresh Dishes with SOILS rinse and coffee, coffee, on soup, coffee, dense dried loosen food...
  • Page 20: Switching On The Machine And Selecting A Program

    SWITCHING ON THE MACHINE AND SELECTING A PROGRAM Switching on the machine Press the POWER button You can choose an Select the program suiting your dishes additonal function via the PROGRAM button Start the program by pressing the START/PAUSE key Progress indicator You can follow the program flow using the progress indicator lights located on the control panel...
  • Page 21: Changing A Program With Resetting

    Cancelling a program If you would like to cancel a program while a washing program is in progress Press and hold the START/PAUSE button for approx 3 sec until END light blinks After END light starts blinking, the water inside is discharged for approx 30 sec Once END light comes on, it means that the cycle has been cancelled Switching the machine off...
  • Page 22: Maintenance And Cleaning

    MAINTENANCE AND CLEANING Swtich off the power supply or disconnect the product before any maintenance or cleaning operation Cleaning the machine at regular intervals prolongs the machine’s service life Oil and lime may accumulate in the machine’s washing section To clean the machine: Fill the detergent compartment with detergent, do not load any dishes into the machine, select a program that runs at high temperature, and start the machine Alternatively,...
  • Page 23: Spray Arms

    MAINTENANCE AND CLEANING Spray arms Check whether the holes for the upper and lower spray arms are clogged If there is any clogging, remove the spray arms and clean them under water You can remove the lower spray arm by pulling it upwards, while the upper spray arm can be removed by turning the lock nut to the left Be sure that the nut is perfectly tightened when refitting the upper spray arm...
  • Page 24: Failure Codes And What To Do In Case Of Failure

    FAILURE CODES AND WHAT TO DO IN CASE OF FAILURE ERROR CODE ERROR DESCRIPTION CONTROL Leak detection • Switch off the dishwasher and close the tap • Contact the service centre Draining fault • Cancel program and power off machine, then check the following •...
  • Page 25: Troubleshooting

    TROUBLESHOOTING PROBLEM SOLUTION If one of program monitor lights is on • Your machine’s door is open, shut the door and start/pause light is flashing If the program won’t start • Check if the plug is connected • Check your indoor fuses •...
  • Page 26: Notes

    NOTES NOTES...
  • Page 27: Warranty

    Warranty FOR SALES IN AUSTRALIA AND NEW ZEALAND APPLIANCE: DISHWASHER This document sets out the terms and conditions of the product You may not make a claim under this warranty unless the defect claimed warranties for Electrolux Appliances. It is an important document. is due to faulty or defective parts or workmanship.
  • Page 28 Top Service encompasses the after sales service provided by The Electrolux Group to consumers including delivery, home service and spare parts Westinghouse. We are part of the Electrolux family. Share more of our thinking at www.electrolux.com.au P/No: 5208 2280 Issue: E ©...
