- Page 1 XOMAX Users Manual XM-RSU221BT Version 1.0 ENGLISH...
- Page 2 XOMAX XM-RSU221BT Thank you for purchasing one of our Xomax products! We appreciate your confidence. Enjoy your brand new multimedia unit! Please read the following manual carefully before you install and use the unit. Please save this manual in case you will need to clarify further possible ques- tions regarding installation and usage of our product.
-
Page 3: Table Of Contents
TA function ..22 (Traffic Announcement) Startup operations TA volume ........22 Usage of the remote control ....17 AF function ..23 (Alternative Frequency) Replacement of the battery .....17 Unit on/off ........18 XOMAX X M - R S U 2 2 1 B T... - Page 4 Make / take a call / redial ....27 End / reject a call ......27 Bluetooth music Common information .....27 Start Bluetooth music ....27 Common solutions Disposal / recycling information Disposal of an old unit ....30 XOMAX X M - R S U 2 2 1 B T...
-
Page 5: Safety Instructions And Precautions
Do not use the unit any further since you detect any kind of technical problems. Leave all the repair opera- XOMAX X M - R S U 2 2 1 B T... - Page 6 To avoid the danger of fire or the electric shock do not put the unit in to the moist environment (e.g. adverse weather conditions, inappropriate wet cleaning etc.) XOMAX X M - R S U 2 2 1 B T...
-
Page 7: Introduction
Specifications Common data Description Operating voltage ......12V DC The XOMAX XM-RSU221BT is a flash XO Backlight color ....Multicolor (7 colors) 1DIN-sized multimedia car radio. Instalation size ..1DIN (shortened depth) A flash XO car radio is a contemporary... -
Page 8: Package Content
1DIN installation frame Fixation metall sheet ISO port adapter cable extraction key Please check the accessories on completeness. The images serve as example. Optically the may vary from the original. XOMAX X M - R S U 2 2 1 B T... -
Page 9: Operating Elements
Subsequently long long press [Radio mode] switches to the press the button to confirm the storage. manual frequency scan forwards. XOMAX X M - R S U 2 2 1 B T... -
Page 10: Additional Information
The micro SD card slot is added for reading of micro SD-, micro-SDHC and micro SDXC-cards in following formats only: FAT32- or exFat- file system. Maximal supported volume: 32 GB. XOMAX X M - R S U 2 2 1 B T... -
Page 11: Remote Control
To step through menus start the search and AMS [Radio] Š > store the found stations next/previous track [Playback] automatic station search [Radio] Play/Pause /TOP RDM [Playback] Random playback on/off XOMAX X M - R S U 2 2 1 B T... -
Page 12: Installation
The detailed installation manual » The connection cables may not be cutted you can find on our homepage www. or short-circuited. Otherwise the warranty xomax.de. becomes invalid. The printed version of a common » Before the installation please make installation manual you can find in sure that your vehicle has the 12 Volt the package. - Page 13 » To avoid a rogue and hazardous short circuit do not lay the yellow cable XOMAX X M - R S U 2 2 1 B T...
-
Page 14: Connection Schedule - Cinch
Topic: Connection schedule – cinch Connection schedule – cinch radio-aerial passiv loud speakers front left e.g. front right ampliefe r rear right optional rear left XOMAX X M - R S U 2 2 1 B T... -
Page 15: Connection Schedule - Iso Plug / Socket
Connection schedule – ISO plug / socket Connection schedule – ISO plug / socket phantom power radio-aerial active ignition permanent current rear right front right front left rear left XOMAX X M - R S U 2 2 1 B T... -
Page 16: Iso Plug / Socket Pin Assignment
If these problems appear the connec- tions A4 and A7 should be interchanged. may lead to grievous errors. XOMAX X M - R S U 2 2 1 B T... -
Page 17: Startup Operations
3. Insert the battery compartment back CR-2025 Lithium battery. into the remote control till it clicks into place. As soon as the remote control does not work proper the battery should be replaced. XOMAX X M - R S U 2 2 1 B T... -
Page 18: Unit On/Off
The playback control can be achieved via external device only. Following music formats are supported: »» MP3 (with ID3 tags as well) »» WMA XOMAX X M - R S U 2 2 1 B T... -
Page 19: Basic Functions
EQ preset off first. Treble settings* (prompt " " on the screen) Balance settings (prompt " " on the screen) Fade settings (prompt " " on the screen) XOMAX X M - R S U 2 2 1 B T... -
Page 20: Preset Equalizer
Supported file formats LED color settings Audio » MP3 files (with ID3-support) Press the Rotary button the remote till the prompt COLOUR 0 » WMA audio format XOMAX X M - R S U 2 2 1 B T... -
Page 21: Radio Mode
If the storing went successful on the display appears a quantity of free Automatic station searching memory cells. Press the button to start the searching into corresponding direction on the frequency scale. XOMAX X M - R S U 2 2 1 B T... -
Page 22: Ams Automatic Frequency Scan
VOL- VOL+ or use the buttons on VOL- VOL+ buttons on the remote to set the the remote to switch between on/off. volume of the announcements. XOMAX X M - R S U 2 2 1 B T... -
Page 23: Af Function (Alternative Frequency)
You can also use for that the button VOL- VOL+ We recommend you to deactivate this function in-city. Otherwise the searching starts each time you drive through the tunnel. XOMAX X M - R S U 2 2 1 B T... -
Page 24: Playback Mode
To get to the USB- or SD- mode manually press the button /SRC/T several times till the prompt "USB" or "SD" respectively appears on the screen. XOMAX X M - R S U 2 2 1 B T... -
Page 25: Skip Track For-/Backwards
If it's on, the current track will be played repeatedly. Random playback button on the front panel activates/deactivates the random playback function. If it's on, all the tracks will be played randomly. XOMAX X M - R S U 2 2 1 B T... -
Page 26: Aux-In Audio Input
The Bluetooth function should be "ON" both on the external device and on the unit. XOMAX X M - R S U 2 2 1 B T... -
Page 27: Hand-Free Phone Call
3. take an incomming call End / reject a call To end the active call or to reject the incoming call press the button on the front panel. XOMAX X M - R S U 2 2 1 B T... -
Page 28: Common Solutions
Common solutions Common solutions The following advices are generally valid and refer to diverse Xomax models with the similar characteristics. Please note that some articles may refer not to your model exactly and may contain the describtion of features and functions that your model does not support. - Page 29 Though the design of ISO port is standardized, it's pin assigment is not and may vary. Thus in case of mismatch of connections due to different pin assignments a simple plug'n'play connection may lead to grievous errors. XOMAX X M - R S U 2 2 1 B T...
-
Page 30: Disposal / Recycling Information
Purchase XOMAX car radio online: the domestic waist. https://www.carmediashop.de Please hand these products for recy- cling at municipal collection points free XOMAX in the world wide web of charge. XOMAX manufacturer's information: The proper disposal of these products http://www.xomax.de contributes to environment protection.
