Installation Manual
4 Button Remote Start Security System With
Plug-In Shock Sensor & Starter Disable
IMPORTANT ! In order to provide you with the highest level of security to your
vehicle, this system is equipped with selectable manual override circuitry. It is
possible that you will need to override you security system if the transmitter
becomes lost, or inoperative due to battery failure. Reading the sections on
"Manually Overriding Your System" is necessary to fully understand the procedure
required to enable your vehicle in such situations. In addition, the chart on the last
page of this manual has a section for the particular features and options installed
in your vehicle as well as the override method selected. Although the default
mode is "Valet Switch" operation, the system can be configured for "Custom
Code" operation for enhanced security. Confirm the override mode selected on
the last page of this manual, and familiarize yourself with the section on it's opera-
tion.
FEATURES :
1 Two Way 5 Button Remote Control And 1 One Way 4 Button Remote Control
Six Channel Code Learning Programmable Receiver
External Superheterodyne Transceiver Antenna
Single Or Two User Programmable W/Separate Control Outputs
Single Button Lock/Unlock or Separate Button Lock/Unlock or Both
Remote Keyless Entry With Optional Access Guard (must have power door
locks)
Selectable Manual Override Mode
New Enhanced Panic Feature (Any button other than unlock stops siren, no
change to the units state)
Smart Disarm (If triggered, elect to shut off siren, or disarm entire unit )
Adjustable Shock Sensor Via The Transmitter (Pre-Detect Off, Pre & Full Detect
Off, City Mode)
Safe Start Output Controlled From Channel 3 (Option Channel 3 For Trunk, Or
For R/S)
24 Hour Time Start Mode
Cold Temperature Start Mode
2 or 4 Hour Automatic Start Mode
Parking Meter Count Down Timer On LCD Remote
Additional Count Down Timer Mode
Remote Panic In All Modes (Press & Hold Lock /Unlock Button For 3 Seconds
To Engage)
Improved Custom Code Override, User Selectable and Programmable
Model AX-900
Owner's Manual
128-6995
1 of 20
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Audiovox AX-900
Summary of Contents for Audiovox AX-900
- Page 1 Parking Meter Count Down Timer On LCD Remote Additional Count Down Timer Mode Remote Panic In All Modes (Press & Hold Lock /Unlock Button For 3 Seconds To Engage) Improved Custom Code Override, User Selectable and Programmable Model AX-900 Owner’s Manual 128-6995 1 of 20...
-
Page 2: Your "Code Hopping" Transmitters
Protected Push Button Valet/Override Switch 7-Function LED-Arm / Disarm / Zone 1 / Zone 2 / Zone 3 / Valet / Arming Intrusion Alert With Memory Instant Siren Activation Starter Disable Output Additional Engine Immobilizer Output, (Optional Relay Required) True Last Door Arming (Hardwire Only) Defective Zone By-Pass Defective Zone Chirp Confirmation (Unit Chirps To Report Zone Cleared) 6 Tone Mini Siren... -
Page 3: Arming The System - Active
known as a code grabber, which will receive and store the signal from your keychain transmitter and retransmit at a later time to disarm your system. Your Keeloq Code Hopping transmitters will change their signal every time the button is pressed, so when a thief grabs then retransmits your signal, the alarm system will not respond. -
Page 4: Arming The System - Passive (Automatic)
Parking Lights flash one time. Siren will not sound. If the siren "chirped" three times, sometime after arming, the exclusive delayed dome light learn circuit has been programmed and the sys- tem detected a open entry point after the learned delay expired. Clos- ing the hood, trunk, or doors will correct the problem and you do not need to disarm the system to make the correction. -
Page 5: Disarming The System
not be started. Any mild impact to the vehicle’s glass will cause the alarm to sound a short series of warning tones. Any strong impact to the vehicle’s glass will cause the alarm to trigger for the full 30 second alarm cycle. NOTE: If the optional interior illumination circuit was installed, the interior light will flash as well for the full 30 second alarm cycle. -
Page 6: While The System Is Sounding
rewarming automatically. Open any door to suspend the automatic arming. Parking Lights flash two times. If the parking lights flashed three times, then the alarm was triggered in your absence. Before turning the key on, examine the LED to identify which zone was triggered. Siren will not sound. -
Page 7: Manually Overriding Your System
the parking lights will flash to indicate locking and unlocking. To use the valet mode, the system must first be disarmed either by using your keychain transmit- ter or by activating your personalized manual override code. 1. Enter the vehicle and turn the ignition key to the on position. 2. - Page 8 steps 1 through 7 above considering the following. NOTE: Acceptable digits 10ths or units are 1 through 9. The unit will not recognize a 0 (Zero), or no digit entered in any place, units or tenths. NOTE: If 15 seconds of inactivity expire or if the ignition switch is turned off for more then 5 seconds during any of the above steps, the unit will revert back to the last successfully stored code.
-
Page 9: Eliminating The Normal Arm / Disarm Chirps
5. Turn the ignition switch off then on and start the vehicle. NOTE: If you have changed the programmed override code then substitute your new code tenths for step 2 above, and units for step 5 above. ELIMINATING THE NORMAL ARM / DISARM CHIRPS As explained earlier in the manual, you can eliminate the chirps selectively any time you arm or disarm the system simply by holding the ARM or DISARM button for two seconds. - Page 10 1. Normal Operation (default mode) In this mode, any strong vibrations will cause the siren to sound (full detect) for 30 seconds. Any lesser vibration will cause the siren to emit about 6 short warn away chirps, (pre-detect). 2. Stage 1 (Omit pre-detect) In this mode, the warn away chirps created by the lesser vibration will be deleted.
-
Page 11: Remote Starting The Vehicle
REMOTE STARTING THE VEHICLE The system WILL NOT start the vehicle if any one of the following conditions exists: 1. The Vehicle Hood Is Opened. 2. The Gear Selector Is In Any Gear Other Then Park. 3. The Brake Is Depressed. 4. - Page 12 The parking lights will flash and the siren will chirp 4 times indicating the timed start mode is activated. The vehicle, on a 2 or 4 hour interval basis, will automatically start, run for the pre-programmed time (5,10,15 or 20 minutes), and then shut off. will continue for 48 hours.
- Page 13 This security system has an additional feature that can be connected to a number of different optional accessories. Some of the more common uses for this channel are; Remote Car Starter Remote Window Closure Remote Garage Door Interface To remotely operate the device indicated, momentarily press, or press and hold the appropriate transmitter button(s) as indicated above.
-
Page 14: Telematic Upgrade
Controlled By: Trunk/Key Button Option Button Lock + Unlock Buttons Lock + Trunk/Key Buttons Lock & Option Buttons Unlock + Trunk/Key Buttons Unlock & Option Buttons Trunk/Key & Option Buttons Other Transmitter button configurations are also available. Consult your installa- tion center for other configurations not listed above that may have been programmed to operate a specific feature of your system. - Page 15 TRANSCEIVER ICONS AND THEIR INDICATIONS When Disarmed, Press the Arm/Lock button to Lock and Arm the System. The Lock Icon is displayed on the LCD panel & the parking lights flash once. When Armed, Press the Disarm/Unlock button to Unlock and Disarm the System. The Unlock Icon is displayed on the LCD panel &...
- Page 16 icons shown left will appear on the screen. If the alarm system has been triggered, the icon dis- played on the transmitter LCD will indicate the which zone has been activated, as well sound the beep tones, or vibrate dependent upon the setting as shown above. The following trigger patterns will be displayed.
- Page 17 ADDITIONAL REMOTE FEATURES: The two way remote control unit allows you to access status information from the vehicle, check temperature, light the display, toggle the transmitter from beep tones to vibrate mode, initiate daily start timer, and temperature start. Selection of these and other features are shown below: NOTE: Transmitter must be within operating range of the vehicle, approximately 1000 ft.
- Page 18 If you require more frequent starting please refer to auto start up timer mode shown earlier in this guide. NOTE: To insure accurate 24 Hour Start up, it is advisable to reset the start time periodically as time may drift slightly each day. Page Call Out: From within the vehicle, if the valet push button is pressed for three seconds, the alarm unit in the vehicle will transmit to the LCD remote and a beep tone...
- Page 19 128-6995 19 of 20...
- Page 20 4 CHIRPS * These chirps are optional, and can be de - activated. PARKING LAMP INDICATORS 1 FLASH 2 FLASHES 3 FLASHES © 2003 Audiovox Electronics Corp., 150 Marcus Blvd., Hauppauge, NY 11788 AX-900 PASSIVE ARMING/ACTIVE ARMED DISARMED VALET MODE...
