4 Button Remote Security System
with Dual Stage Shock Sensor
IMPORTANT ! In order to provide the highest possible level of security to your vehicle, this
system is equipped with selectable manual override circuitry. It is possible that you will need
to manually override your security system if the transmitter becomes lost, or inoperative due
to battery failure. Reading the sections on "MANUALLY OVERRIDING YOUR SYSTEM" is
necessary to fully understand the procedure required to enable your vehicle in such
situations. In addition, the chart on the last page of this manual has a section for the particular
features and options installed in your vehicle as well as the override method selected.
Valet Switch manual override is pre-selected from the factory, however, the system
can be configured for "Custom Code" operation. Confirm the override mode selected on the
last page of this manual, and familiarize yourself with the selection on it's operation.
FEATURES :
2 Four Button Programmable RF Transmitters (capable of accepting 4 transmitters)
Five Channel Receiver
Code Hopping Technology
Selectable Manual Override Mode
Remote Panic in all modes
Protected Valet
User Programmable Manual Override Code
7 Function LED (Light Emitting Diode) - Arm / Disarm / Zone 1, 2, 3 / Valet / Arming
Intrusion Alert with Memory
Audible Arm / Disarm / Defective Zone / Tamper Confirmation
Instant Siren Activation
Starter Disable
Additional Engine Immobilizer Output (optional relay required)
True Last Door Arming (hardwire only)
Defective Zone By-Pass
Hardwire or Voltage Sense Selectable
Active or Passive Arming Selectable
Programmable Auto Lock On / Off
Programmable Auto Unlock On / Off
Programmable Door Lock Pulse Duration 1 Second / 3.5 Seconds/1 Sec L/ Dbl. U/L
Programmable Active or Passive Door Locks
User Programmable Permanent Chirp Delete
On Command RF Chirp Delete from Transmitter
6 Tone Multi Tone Siren
RF Inhibit with ignition on
Parking Light Flasher
Plug In Dual Stage Shock Sensor
OPTIONS:
Remote Trunk Release ( must have electronic trunk release )
Remote Keyless Entry ( must have power door locks )
Multiple Vehicle Capable
Remote Starter
Remote Power Window Roll Up
Remote Garage Door Interface
Two Step Unlock Configurable
Headlight Illumination During Arming, Disarming, Or Both
Interior Illumination Upon Disarm
Model AX-500
Owner's Manual
128-7000
1 OF 10
Advertisement
Table of Contents
Related Manuals for Audiovox AX-500
Summary of Contents for Audiovox AX-500
- Page 1 Remote Keyless Entry ( must have power door locks ) Multiple Vehicle Capable Remote Starter Remote Power Window Roll Up Remote Garage Door Interface Two Step Unlock Configurable Headlight Illumination During Arming, Disarming, Or Both Interior Illumination Upon Disarm Model AX-500 Owner’s Manual 128-7000 1 OF 10...
-
Page 2: Arming The System - Active
YOUR “ Code Hopping “ TRANSMITTERS The transmitters included with your new security system use the most advanced and secure form of radio frequency transmission available on any current automotive security system. Some of today’s sophisticated auto thieves use a device known as a code grabber, which will receive and store the signal from your keychain transmitter, and retransmit at a later time to disarm your system. -
Page 3: Arming The System - Passive ( Automatic )
disarm the system to make the correction. Doors Lock - Optional Headlight Illumination - Optional ARMING THE SYSTEM - PASSIVE ( AUTOMATIC ) 1. Turn off the engine, exit the vehicle, and close and lock all doors, hood lid and trunk lid. -
Page 4: Disarming The System
DISARMING THE SYSTEM 1. As you approach the vehicle, press and release the Unlock button on the key- chain transmitter. Dash mounted LED turns off. If passive arming was selected during the installation, then the LED will start flashing rapidly, indicating that the system is rearming auto- matically. -
Page 5: While The System Is Sounding
transmitter button is activated, the drivers door only will unlock, pressing the unlock button a second time will cause all doors to unlock. If your transmitter has a separate lock/unlock buttons, pressing the unlock button anytime after the first unlock command will cause all the vehicle doors to unlock. - Page 6 NOTE: Always remember to return the system to the NON VALET mode, after servicing, to ensure that the vehicle remains protected at all times. MANUALLY OVERRIDING YOUR SYSTEM: USING THE VALET SWITCH MANUAL OVERRIDE Your Security System can be disarmed without the use of the keychain transmitter. This is necessary, since you will need the ability to operate your vehicle if the transmitter is lost or its battery fails.
- Page 7 NOTE: If 15 seconds of inactivity expire, or if the ignition switch is turned off for more then 5 seconds during any of the above steps, the unit will revert back to the last successfully stored code. Custom Code Programming Example: To Change the code from the factory preassigned code of 11 to “52”...
-
Page 8: Eliminating The Normal Arm / Disarm Chirps
ELIMINATING THE NORMAL ARM / DISARM CHIRPS As explained earlier in the manual, you can eliminate the chirps selectively any time you arm or disarm the system simply by holding the ARM / DISARM button for two seconds. If you find the normal arming and disarming chirps annoying, they can be turned off permanently, eliminating the need to hold the ARM / DISARM button for two seconds. -
Page 9: Telematic Upgrade
in succession. Check with your installation center for more information on what accessories were installed and how they are accessed. ADDITIONAL REMOTE FUNCTION ( CHANNEL 4 ) This security system has an additional feature that can be connected to a number of different optional accessories. - Page 10 Passive Arming No Lock in passive mode Hardwire doors, hood, and trunk Custom Code Override Valet Switch Override Illuminated Entry Upon Disarm © 2003 Audiovox Electronic Corporation, 150 Marcus Blvd., Hauppauge, N.Y. 11788 AX-500 PASSIVE ARMING ARMED DISARMED VALET MODE...
