4 Button Remote Start Security System With
Plug-In Shock Sensor & Starter Disable
IMPORTANT ! In order to provide you with the highest level of security to your
vehicle, this system is equipped with selectable manual override circuitry. It is
possible that you will need to override you security system if the transmitter
becomes lost, or inoperative due to battery failure. Reading the sections on
"Manually Overriding Your System" is necessary to fully understand the procedure
required to enable your vehicle in such situations. In addition, the chart on the last
page of this manual has a section for the particular features and options installed
in your vehicle as well as the override method selected. Although the default
mode is "Valet Switch" operation, the system can be configured for "Custom
Code" operation for enhanced security. Confirm the override mode selected on
the last page of this manual, and familiarize yourself with the section on it's opera-
tion.
FEATURES :
w 1 Two Way 5 Button Remote Control And 1 One Way 5 Button Remote Control
w Six Channel Code Learning Programmable Receiver
w External Superheterodyne Transceiver Antenna
w Single Or Two User Programmable W/Separate Control Outputs
w Single Button Lock/Unlock or Separate Button Lock/Unlock or Both
w Remote Keyless Entry With Optional Access Guard (must have power door
locks)
w Selectable Manual Override Mode
w New Enhanced Panic Feature (Any button other than unlock stops siren, no
change to the units state)
w Smart Disarm (If triggered, elect to shut off siren, or disarm entire unit )
w Adjustable Shock Sensor Via The Transmitter (Pre-Detect Off, Pre & Full Detect
Off, City Mode)
w Safe Start Output Controlled From Channel 3 (Option Channel 3 For Trunk, Or
For R/S)
w 24 Hour Time Start Mode
w Cold Temperature Start Mode
w 2 or 4 Hour Automatic Start Mode
w Parking Meter Count Down Timer On LCD Remote
w Additional Count Down Timer Mode
w Remote Panic In All Modes (Press & Hold Lock /Unlock Button For 3 Seconds
To Engage)
w Improved Custom Code Override, User Selectable and Programmable
Model APS-998
Owner's Manual
Page 1
128-7404
1 of 24
Advertisement
Table of Contents
Related Manuals for Audiovox Prestige Platinum APS-998
Summary of Contents for Audiovox Prestige Platinum APS-998
- Page 1 Additional Count Down Timer Mode w Remote Panic In All Modes (Press & Hold Lock /Unlock Button For 3 Seconds To Engage) w Improved Custom Code Override, User Selectable and Programmable Model APS-998 Owner’s Manual Page 1 128-7404 1 of 24...
-
Page 2: Your "Code Hopping" Transmitters
w Protected Push Button Valet/Override Switch w 7-Function LED-Arm / Disarm / Zone 1 / Zone 2 / Zone 3 / Valet / Arming w Intrusion Alert With Memory w Instant Siren Activation w Starter Disable Output w Additional Engine Immobilizer Output, (Optional Relay Required) w True Last Door Arming (Hardwire Only) w Defective Zone By-Pass w Defective Zone Chirp Confirmation (Unit Chirps To Report Zone Cleared) -
Page 3: Arming The System - Active
known as a code grabber, which will receive and store the signal from your keychain transmitter and re-transmit at a later time to disarm your system. Your Keeloq Code Hopping transmitters will change their signal every time the button is pressed, so when a thief grabs then re-transmits your signal, the alarm system will not respond. -
Page 4: Arming The System - Passive (Automatic)
þ The dash mounted LED begins to flash slowly. þ Parking Lights flash one time. þ Siren will not sound. If the siren "chirped" three times, sometime after arming, the exclusive delayed dome light learn circuit has been programmed and the system detected a open entry point after the learned delay expired. -
Page 5: Disarming The System
þ Any mild impact to the vehicle’s glass will cause the alarm to sound a short series of warning tones. þ Any strong impact to the vehicle’s glass will cause the alarm to trigger for the full 30 second alarm cycle. NOTE: If the optional interior illumination circuit was installed, the interior light will flash as well for the full 30 second alarm cycle. -
Page 6: While The System Is Sounding
þ Parking Lights flash two times. If the parking lights flashed three times, then the alarm was triggered in your absence. Before turning the key on, examine the LED to identify which zone was triggered. þ Siren will not sound. If the siren sounds 4 chirps, then the alarm was triggered in your absence. -
Page 7: Programming Your Custom Override Code
3. To return to normal operation, press and release the pushbutton switch any time the ignition is on. NOTE: Always remember to return the system to normal operation. This will ensure that the vehicle remains protected at all times. MANUALLY OVERRIDING YOUR SYSTEM: USING THE VALET SWITCH MANUAL OVERRIDE Your Security System can be disarmed without the use of the keychain transmitter. -
Page 8: Eliminating The Normal Arm / Disarm Chirps
1. Disarm the system by use of the transmitter or by use of the emergency override sequence. 2. Turn the ignition switch to the on position. 3. Within 10 seconds, press and release the valet/override switch, 3 times. 4. Within 10 seconds turn the ignition switch off, on, off, on, off, on. (The siren or horn will beep and the lights will flash one time.) 5. -
Page 9: Remote Panic Operation
3. If the chirps were on before you started, then you will hear two chirps indicat- ing they have been turned off. If the chirps were off before you started, then you will hear one chirp indicating they have been turned on. NOTE: Whenever the chirps are bypassed, the 4-chirp intrusion indicator and 3 chirp defective zone indicator will always operate. -
Page 10: Remote Starting The Vehicle
NOTE: Setting the stage of the shock sensor will be effective for one arming cycle only. Once the system has been disarmed, the very next arming cycle will cause the sensor to default to the normal operation stage. To change or adjust the shock sensor, press and release the ARM button of you keychain transmitter. -
Page 11: Operating On Automatic Start Up Timer Mode
To Remote Start The Vehicle: Press and release the programmed channel of your keychain transmitter two times within 2 seconds. The vehicle will start and remain running for the pre- programmed 5, 10, 15, or 20 minutes. As a visual indication, the parking lights will flash or turn on depending on the programming set up by your installation center. - Page 12 CANCELING THE AUTOMATIC START UP TIMER To cancel the automatic start up timer do one of the following; 1. Start the vehicle manually with the use of the ignition key and depress the brake pedal. 2. Remote start the vehicle using your keychain RF transmitter. NOTE: Option button used in combination is only available on the alternate re- mote transmitter and not available on the LCD Transmitter.
-
Page 13: Turbo Timer Mode
o Remote Garage Door Interface To remotely operate the device indicated, momentarily press, or press and hold the appropriate transmitter button(s) as indicated above. ADDITIONAL REMOTE FUNCTION ( CHANNEL 6 ) Channel 6 is an alternate output that can be controlled by the unlock button of the transmitter, or by and independent button or combination of buttons. -
Page 14: Telematic Upgrade
Anytime the engine is running for more than 15 seconds: 1) Place the the gear selector in park. 2) Set the parking, (hand), brake. 3) Be certain your foot is off the brake pedal. 4) Press the program/Push-Button switch 2 times within 5 seconds. The parking lights will flash two times indicating the mode was successfully entered. - Page 15 Note Engine can be started in many modes armed, disarmed, valet, etc... The screen shown is Locked/Armed and running. When Panic Mode has been activated and the system is armed the vehicle's lights, the lock and the siren icon will flash on the LCD screen.
- Page 16 3 times, the lights will flash, and the display will indicate a door trigger as shown on the previous page. In the text mode the word Armed, Door Opened will appear. When the door is closed or the zone clears, the transmitter will chirp 1 time, and the display will clear.
- Page 17 ADDITIONAL REMOTE FEATURES: The two way remote control unit allows you to access status information from the vehicle, check temperature, light the display, toggle the transmitter from beep tones to vibrate mode, initiate daily start timer, and temperature start. Selection of these and other features are shown below: NOTE: Transmitter must be within operating range of the vehicle, approximately 1000 ft.
- Page 18 the transmitter will emit a tone confirming the feature is active. Note: the unit will start once and run for the prescribed time. If you require more frequent starting please refer to auto start up timer mode shown earlier in this guide.
- Page 19 NOTE: Your system is shipped with two transmitters, 1 two way, shown on the left and the one way transmitter, shown right. The one and two way transmitters are programmed from the factory with separate lock & unlock buttons, the trunk/ key icon button operates remote start and remote trunk release where appli- cable.
- Page 20 (j) You can set the Countdown Timer (k) You can set the Alarm Clock (l) You can set the Clock Your transmitter has a battery indicator that is shown in the upper right corner of the screen as shown left. This icon indicates a new battery shown with 3 bars.
- Page 21 Throughout this manual you will find screen shots where they apply if using the two way transmitter. If using the one way transmitter while the two way transmitter is within range of the vehicle, the two way transmitter will update it's screen.
- Page 22 THIS PAGE LEFT BLANK INTENTIONALLY Page 22 128-7404 22 of 24...
- Page 23 SYSTEM FUNCTIONS AT A GLANCE DASH LED INDICATORS RAPID FLASHING REARMING SLOW FLASHING ON SOLID 3 FLASH...PAUSE 2 FLASH...PAUSE 1 FLASH...PAUSE SIREN CHIRP INDICATORS 1 CHIRP * 2 CHIRPS * 3 CHIRPS 4 CHIRPS * These chirps are optional, and can be de - activated. PARKING LAMP INDICATORS 1 FLASH 2 FLASHES...
- Page 24 © 2005 Audiovox Electronics Corp., 150 Marcus Blvd., Hauppauge, NY 11788 128-7404 Page 24 128-7404 24 of 24...
