ARMING THE SYSTEM - ACTIVE
1. Turn off the engine, exit the vehicle, and close all doors,
hood lid and trunk lid.
2. Press and release Lock/Arm button on the keychain trans-
mitter.
The dash mounted LED begins to flash slowly. Parking Lights
flash one time.
Siren sounds one chirp.
If the siren/horn sounds 3 chirps, then you have left a door,
trunk, or hood lid ajar. Simply close the opened entry point
to provide full protection. If the siren "chirped" three times,
sometime after arming, the exclusive, patented, delayed dome light
learn circuit has been programmed and the system detected a open
entry point after the learned delay expired. Again, closing the hood,
trunk, or doors will correct the problem and you do not need to disarm
the system to make the correction. If the siren/horn did not sound
when arming, then the chirps have been turned off and you should refer to the section
titled "ELIMINATING THE ARM/DISARM CHIRPS" in this manual.
NOTE: If selectable feature 9, Chirp Delete From Transmitter, was set to the on position
during installation, then you can selectively defeat the arm & disarm chirps by holding the
transmitters Lock or Unlock button for about 2 seconds.
Note: If Passive Arm Mode was selected on during installation, then 30 seconds after the
last vehicle door is closed, the unit will arm automatically.
PROTECTION WHILE THE SYSTEM IS ARMED
Opening any protected door, hood or trunk lid will cause the alarm to immediately sound. The
alarm will continue to sound for 30 seconds, then stop and continue to monitor all protected entry
points. If the thief left a door opened, the alarm will sound for six 30 second cycles, remain armed
and ignore that triggered zone.\
Whenever the system is armed, the dash mounted LED indicator will slowly flash. This serves as a
visual deterrent to the potential thief. The LED is a very low current bulb and will not cause the
vehicle's battery to drain, even when left unattended for extended periods.
Whenever the system is triggered, the vehicle's parking lights will flash for the full 30 second alarm
cycle, attracting visual attention to the vehicle.
Optional - Whenever the system is armed, the vehicle's starting circuit will be bypassed. If the thief
should choose to ignore the siren, the vehicle can not be started.
Any mild impact to the vehicle's glass will cause the alarm to sound a short series of warning tones.
Any strong impact to the vehicle's glass will cause the alarm to trigger for the full 30 second alarm
cycle.
NOTE: If the optional interior illumination circuit was installed, the interior light will flash as well
for the full 30 second alarm cycle.
DISARMING THE SYSTEM
1. As you approach the vehicle, press and release the Unlock/Disarm button on the keychain
transmitter.
The dash mounted LED turns off. If passive arming is selected on, the LED will start flashing
rapidly, indicating that the system is re-arming automatically. Open any door to suspend the auto-
matic arming. Parking Lights flash two times. If the parking lights flashed three times, then
the alarm was triggered in your absence. Before turning the key on, examine the LED to identify
which zone was triggered. Siren sounds two chirps. If the siren sounds 4 chirps, then the alarm
was triggered in your absence. Before turning the key on, examine the LED and refer to the
INTRUSION WARNING SIGNALS section of this manual to identify which zone was triggered.
If the siren did not sound when disarming, then the chirps have been turned off
and you should refer to the section titled "ELIMINATING THE ARM / DISARM CHIRPS" in this
manual.
Doors Unlock - Optional
NOTE: If the optional Interior illumination feature has been added as an added convenience,
the system will turn on the interior lights when the system is disarmed.
WHILE THE SYSTEM IS SOUNDING
If during a triggered state, you wish to shut off the siren without disarming your security system,
simply press and release any transmitter button other than the Unlock/Disarm button. This action
Model APS-920
Owner's Manual
Page 1
128-7852
1 of 12

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Prestige APS-920 and is the answer not in the manual?

Questions and answers

Summary of Contents for Audiovox Prestige APS-920

  • Page 1 ARMING THE SYSTEM - ACTIVE 1. Turn off the engine, exit the vehicle, and close all doors, hood lid and trunk lid. 2. Press and release Lock/Arm button on the keychain trans- mitter. The dash mounted LED begins to flash slowly. Parking Lights flash one time.
  • Page 2: Intrusion Warning Signals

    will turn off the siren yet leave the vehicle fully armed and protected. This feature is particularly useful if you are aware of children playing near your vehicle that may accidently trigger your security system. In this case you can cancel the siren sounding without disarming your alarm. INTRUSION WARNING SIGNALS This system will inform you if an intrusion attempt has occurred while you were away from the vehicle.
  • Page 3 flash pattern reports the previously stored code, the new code was not entered correctly. Please repeat steps 1 through 7 above considering the following. NOTE: Acceptable digits 10ths or units are 1 through 9. The unit will not recognize a 0 (Zero), or no digit entered in any place, units or tenths.
  • Page 4: Eliminating The Normal Arm / Disarm Chirps

    THE OPTION BUTTON of your transmitter may or may not be used with your system but may be used with a second similar Audiovox Model system that may be installed on a second vehicle in your family. OPERATING ON AUTOMATIC START UP TIMER MODE Your system has the ability to automatically start the vehicle every 2 or 4 hours over a 48 hour period.
  • Page 5 To do this: 1. Turn the ignition key on then off. 2. Within 10 seconds, press and release valet switch three times. 3. If the chirps were on before you started, then you will hear two chirps indicating they have been turned off.
  • Page 6: Turbo Timer Mode

    TURBO TIMER MODE This system provides a means to cool down the vehicles turbo charger, if so equipped, by allowing the vehicle to continue to run for a prescribed period of time every time the vehicle's engine is turned off. This feature requires the system to be set up for turbo timer during installation.
  • Page 7: Battery Replacement

    1) Enter the transmitter program mode of channel 1 as indicated above. 2) Press and hold any transmitter button that has not been programmed into channel 1 until you hear a chirp, then release and immediately press the same button a second time until you hear a long chirp followed by a short chirp.
  • Page 8 Vehicle as Been Started By Remote Control. Vehicle Is Running Under Control of The Remote Start Unit. Alternate Vehicle Mode Is Activated. Toggle feature on and off by pressing Trunk/Key + * buttons for 5 seconds until beep is heard, then press the Lock Button Once. Battery Save Mode Is On.
  • Page 9 Simply dial 1 - 800 - 645 - 4994, and follow the instructions from the operator interface. 9) Mail this form along with your payment to: Audiovox Electronics Corp., 150 Marcus Blvd., Hauppauge, N.Y., 11788 Attn.: TRANSMITTER DEPARTMENT APS620TX Order APS620TXP-300 If Lock &...
  • Page 10 Applies to control modules, relays, transmitters, sensors and sirens. AUDIOVOX CORPORATION (the Company) warrants to the original retail purchaser of this product that should this product or any part thereof, under normal use and conditions, be proven defective in material or workmanship within 36 months from the date of original purchase, such defect(s) will be repaired or replaced with new or reconditioned product (at the Company's option) without charge for parts and repair labor.
  • Page 11 THIS PAGE LEFT BLANK INTENTIONALLY Page 11 128-7852 11 of 12...
  • Page 12: Fcc Notice

    Caution: Changes or modifications not expressly approved by the party responsible for compliance voids the users authority to operate this device. © 2006 Audiovox Electronics Corporation 150 Marcus Blvd. Hauppauge N.Y. 11788 128-7852 Page 12 128-7852 12 of 12...
